4 Product Features

Échelon Model BI2115 Ice Maker
The BI2115 Ice Maker will produce and store up to 25 lbs
(11.3 kg) of ice per day. It conserves on water, using only
2-3/4 gallons (10.4 L) to produce approximately 22 lbs (10
kg) of ice, and features a clear removable ice bucket.
Manual defrosting will be occasionally required.
Exclusive Features of Échelon
• Self-closing door hinges engage when the door is open
approximately 8-10 in. (20-25 cm), ensuring a positive
door seal and preventing door bounce back.
• Black and white models have vinyl clad steel cabinets
that provide a rich textured look, and resist scratching,
peeling, or flaking. They feature a slightly contoured,
across the top, integrated door handle design that
permits the door to be easily reversed. The door comes
standard with a factory-installed flush panel, and will
accommodate a 1/4 in. (0.66 cm) thick custom panel to
achieve a custom, built-in look by matching
surrounding cabinets.
• All stainless steel models have a stainless steel full wrap
cabinet, door, sculpted handle and hinges.
• Stainless steel doors are not field reversible.
• Stainless steel models are deemed suitable for outdoor
use by UL.
• An optional full overlay door panel kit for black and
white units, using a customer provided 3/4 in. (1.9 cm)
thick panel, is available that provides a fully integrated
appearance with surrounding cabinets. Overlay panel
is easily attached to the door.
Features and specifications are subject to change without
notice.
6

5 Operation

Proper air flow (Figure 2) is required for your unit to
operate at its highest efficiently. A grille, located in
the base of the unit, must not be blocked at any
time, or your unit will not perform.

Initial Startup

All U-Line units are shipped with controls that are preset.
No initial adjustments are required.
It is possible that dirt or scale will dislodge in the
water line. Always throw away all ice cubes made
during the first two to three hours of operation.
Open the door to access the power switch. It is located on
the lower front panel (Figure 2, 1).
Depress the ON/OFF switch as required to turn the unit on
or off.

Temperature Control

Adjusting Temperature
Many factors can affect the internal temperatures of the
cabinet. They include:
• Temperature setting.
• Ambient temperature where installed.
• The number of times and length of time the door is
opened and closed.
• Installation in direct sunlight or near a heat source.
To adjust the temperature setting:
1. Remove the front grille (two screws) (Figure 2, 2).
BI2115
2 1
ULIN_0132_A
Figure 2
