Door Reversal
Figure 16
All U-Line black or white units may be left- or right-hand
opening. Stainless steel unit doors cannot be reversed.
The doors are easily reversed by moving the hinge
hardware to the opposite side. The top hinge hardware
will be used on the bottom of the other side and the
bottom hinge hardware will be used on the top of the
other side (Figure 16).
To reverse the door:
1
Figure 17
1. Remove top hinge screw pin (Figure 17, 1) from door
using a Phillips screwdriver. Remove door by tilting
forward and lifting off bottom hinge pin.
ULIN_0202_A
2
ULIN_0003_A
2. Remove plastic screw plugs (three each, top and
bottom) (Figure 18, 1) from new hinge location. Do
not discard.
3. Remove top hinge (three screws) (Figure 17, 2) and
reinstall hinge screw pin (Figure 17, 1).
4. Install the removed top hinge mount on opposite side
BOTTOM (Figure 19).
BI2115
1
ULIN_0002_A
Figure 18
1
ULIN_0005_A
Figure 19
1
ULIN_0004_A
Figure 20
