Swing Seats
IMPORTANT!
Prior to installation of any components, refer to the "Owner/Operator Manual". This
manual will provide important information pertaining to site preparation, footings, system stabilization and
other necessary information vital to the success of your installation.
Models included in this installation guide:
MODEL
284
2840
2841
299
2990
2740
2741
2760
Note:
•
Deck Systems are NOT included in these assemblies.
•
An (*) by part numbers indicate: Color Code Required.
•
Please refer to Construction Drawings for the model particular to your system.
1. Concrete for footings, wheelbarrow or mixer, 5 gallon bucket, water supply
2. Digging equipment for footings (spade shovel, post hole digger, auger)
3. Bracing materials (2x4s, wood pieces, concrete blocks, bricks, sawhorses, jack stands,
etc.)
4. Open end wrench set, Allen and 6-lobe wrenches or bits, socket set, screwdrivers
5. Step ladder(s)
6. Tape measure and level
7. Adult installer
Installation Guide
DESCRIPTION
Slashproof Seat w/Shackles - 10'
Slashproof Seat w/Chain - 8'
Slashproof Seat w/Chain - 10'
Tot Seat 360° w/Clevis
Tot Seat 360° w/Chain - 8'
Inclusive Swing Seat w/Chain - 8'
Inclusive Swing Seat w/Chain - 10'
Generation Swing Seat Assembly MREC
TOOLS AND EQUIPMENT REQUIRED
Refer to "Installations 101"
24APR23
Rev. AL
PAGE
2
2
2
2
2
2
2
2
Page 1 of 7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Miracle 284
Summary of Contents for Miracle 284
- Page 1 Installation Guide 24APR23 Rev. AL Swing Seats IMPORTANT! Prior to installation of any components, refer to the "Owner/Operator Manual". This manual will provide important information pertaining to site preparation, footings, system stabilization and other necessary information vital to the success of your installation. Models included in this installation guide: MODEL DESCRIPTION...
- Page 2 24APR23 Rev. AL Swing Seats 299 and 2990 284, 2840 2841 360° Tot Seat Slashproof Seat Note: Chains NOT shown. 2740 and 2741 2760 Inclusive Swing Seat Generation Swing Seat Note: Chains NOT shown. Page 2 of 7...
- Page 3 2a. Attach seat to chains using two (2) "D" shackles with bolts. Depending on your installation, the chains may need to be shortened to ensure the correct seat height. i. For Models 284, 2840, 2841: ii. For Models 299, 2990:...
- Page 4 24APR23 Rev. AL Swing Seats STEP 3 ATTACH SEAT WITH CLEVIS SWING HANGER iii. For Models 2740, 2741 and 2760: Note: The correct height of the seats above finished grade when a user is sitting in the seat is: • 12" minimum for pre-school age children •...
-
Page 5: Final Step
24APR23 Rev. AL Swing Seats STEP 4 CHECK FRICTION IN YOKE ***IMPORTANT NOTES*** 1. After assembly is complete and seat is hanging from top rail, verify that the friction in yoke allows it to maintain its position regardless of where it is in its range of motion or whether user load is present. -
Page 6: Bill Of Material
24APR23 Rev. AL Swing Seats Bill of Material SLASHPROOF SEAT Model Component Quantity Description 990931* PARTS CARTON, S/P SEAT W/SHACKLES Model Component Quantity Description 2840 (For 8' Top Rail) 990932 PARTS CARTON - (2) - 71" CHAINS 990931* PARTS CARTON, S/P SEAT W/SHACKLES Model Component Quantity... - Page 7 24APR23 Rev. AL Swing Seats REPLACEMENT KITS FOR MAINTENANCE 2740 2741 - Inclusive Swing Seat ITEM QUANTITY DESCRIPTION 923422 AS NEEDED INCL SWG SEAT RES REPLACEMENT KIT COMPONENT QUANTITY DESCRIPTION 304262 YOKE FRICTION SPACER 200097726 SCREW MACH BUTTONHEAD M10 X 1.5 X 38MM ITEM QUANTITY DESCRIPTION...
