Miracle SWING SEAT Manual

STRUCTURE: ____________________
Doc No. F-01B
MIRACLE: ______________________
Item Description
1 Swing Seat – Strap or Infant *
2 8mm S Hook *
3 Swing Chain – Senior or Junior *
'D' Shackles M12
Bolts
Locknuts
Application:
Installation Instructions:
1. Secure Swing Seat to swing chain using S Hooks.
2. Ensure that the S Hooks are fully closed and secure.
3. Height of swing seat surface is minimum 455mm &
maximum 600mm.
Please Note:
reuse it. They must be replaced.
VERY IMPORTANT:
Do not hang Swing Chains/ Seats until pit has been back filled with
approved softfall.
DATE: ___________
DATE: ___________
SWING SEAT
TO FIX TO OVERHEAD
M12
M12
Once an S Hook has been closed, never open and
Qty Specifications
1
2 Materials:
2
Colour: Optional
2 Finish: Powdercoat
2
2
Fasteners:
Stainless Steel
Maintenance
All fasteners should be regularly
checked and retightened, if necessary,
1 week after installation.
Ongoing maintenance intervals will vary
according to the amount of use the
equipment receives.
Recommend inspection intervals every 3
months.
* Wear Item - Refer Warranty
Safety Area
Age Groups:
3-7 Years
7-15 Years
