- Page 1 INSTALLATION INSTRUCTIONS W 4302 / W 4303 Four-Way Wedge with Log Stripper Revision: Feb-2025 Document number: Z97860_En...
-
Page 2: Table Of Contents
2.1 Safety Alert Symbol ..........4 2.2 Why Safety is Important ..........4 2.3 Signal Words ............4 3. Accessory Components ........5 3.1 W4302 Components ..........5 3.2 W4303 Components ..........5 4. Install a Wedge and Log Stripper ......6 4.1 Preparation ............... 6 4.2 Tools ................ -
Page 3: Introduction
• WXT20V Illustrations are provided for reference only. It is possible that some details are not shown. For support or service, contact your local dealer or Wallenstein Equipment. Units of measurement in Wallenstein technical manuals are written as: US Customary (SI metric) This manual is subject to change without notice. -
Page 4: Safety
• Accidents are preventable. You are responsible for the safe operation and maintenance of your Wallenstein Equipment product. You must make sure that you and anyone who uses, maintains, or works around the machine is familiar with the operation and maintenance procedures and related safety information in this manual. -
Page 5: Accessory Components
Inspect the components to confirm that no damage occurred during shipment. W4302 Components W4303 Components W4303 large four-way wedge with log stripper Figure 1 – W4302 four-way wedge with log stripper Figure 2 – Item Part Number Description Quantity... -
Page 6: Install A Wedge And Log Stripper
W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper 4. Install a Wedge and Log Stripper WARNING! Read and obey all the installation and setup instructions. Do not change this equipment and install the equipment correctly. Incorrect installation or changes to the equipment can cause serious injury or machine damage, and immediately void the warranty. -
Page 7: Procedure
However, the installation procedure for the W4303 wedge and log stripper is the same. To install a W4302 or W4303 on your log splitter, do the following: Step 1 Remove the bolt and nut that connect the wedge assembly to the hydraulic-cylinder rod. - Page 8 W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper Step 3 Loosen the two bolts that hold the wedge on the assembly. Keep the two bolts with the wedge for future installation. Step 4 Carefully, lift the wedge off the wedge assembly.
- Page 9 W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper Step 5 Carefully, put the new wedge on the wedge assembly. Step 6 Install the two bolts that were included with the new wedge. For more information, see item 2 in Figure 1 on page 5 or Figure 2 on page 5.
- Page 10 W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper Step 8 Align the four holes in the log stripper with the four holes in the hydraulic-cylinder support plate. Step 9 Install the four bolts, eight washers, and four nuts that were removed at step 7.
-
Page 11: Specifications
W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper 5. Specifications Specifications are provided for reference and are subject to change without notice. Accessory Specifications Parameter W4302 W4303 Weight 26.7 lb (12.1 kg) 29.5 lb (13.4 kg) Dimensions 9” x 14-9/16” x 9-7/16”... -
Page 12: Bolt Torque
W4302 / W4303 Installation Instructions Four-Way Wedge with Log Stripper Bolt Torque Imperial Bolt Torque Specifications IMPORTANT! If you replace hardware, use fasteners Torque Bolt of the same grade. SAE Gr. 2 SAE Gr. 5 SAE Gr. 8 Diameter lbf•ft N•m... -
Page 13: Limited Warranty
Four-Way Wedge with Log Stripper 6. Warranty LIMITED WARRANTY Wallenstein products are warranted to be free of defects in materials and workmanship under normal use and service, for a period of Five Years for Consumer Use Two Years for Commercial/Rental Use from the date of purchase, when operated and maintained in accordance with the opera�ng... - Page 14 WallensteinEquipment.com...
