- Page 1 FlameSpec IR3 H2 HD User Manual Doc. No. F140V0020.11 FlameSpec IR3-H2-HD 2570 E. Cerritos Ave, Anaheim, CA 92806, USA T: (+1) 714-671-8500 support@fg-detection.com www.fg-detection.com ·...
- Page 2 Information FlameSpec-IR3-H2-HD Triple IR HD Flame Detector User Guide, June 2024 Copyright © Fire & Gas Detection Technologies Inc. All rights reserved. The owner or authorized user of a valid copy of this manual may reproduce this publication for the purpose of learning to use the specified equipment.
-
Page 3: Table Of Contents
FlameSpec IR3 H2 HD User Manual Doc. No. F140V0020.11 Table of Contents Introduction .........................1 Key Features..........................1 Model Number Description ...................... 2 Internal tests ..........................2 Product Overview ........................3 Accessories ..........................4 Installation...........................8 General Considerations ......................8 Preparations for Installation ....................10 Required Tools ........................ - Page 4 Testing ........................... 26 Flame Simulator ........................26 Maintenance........................27 Cleaning Procedure ........................ 27 Troubleshooting .........................28 Servicing ..........................29 FGD Communicator Software ....................29 Specifications ........................30 Fire Detection ......................... 30 Video Functionality ........................ 30 Electrical Specifications ......................30 Outputs ..........................31 Mechanical Specifications ...................... 31 Environmental Specifications ....................
- Page 5 FlameSpec IR3 H2 HD User Manual Doc. No. F140V0020.11 List of Figures Figure 1 - Front view of the FLS-IR3-H2-HD ....................3 Figure 2 - Rear view of the FLS-IR3-H2-HD ....................3 Figure 3 - Tilt mount ............................. 4 Figure 4 - Weather Cover ..........................4 Figure 5 - Pole Mount ...........................
-
Page 6: Introduction
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1 Introduction The FlameSpec-IR3-H2-HD flame detector will detect hydrogen and other “energy transition” fires quickly allowing actions to be initiated to minimize the extend of the fire. The detector addresses slow growing fires as well as fast eruptions of fire using improved IR3 technology. The detector operates in all weather and light conditions. -
Page 7: Model Number Description
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.2 Model Number Description Model No are defined as follows : FLS-IR3-H2-HD - X Standard (Hydrogen fire), near IR Camera, no HART® and not SIL certified. Standard (Hydrogen fire), near IR Camera. Like model 1 with RGB Camera. Detection of Hydrogen and Hydrocarbon fire , near IR Camera. -
Page 8: Product Overview
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.4 Product Overview 1 - F FLS-IR3-H2-HD IGURE RONT VIEW OF THE 2 - R FLS-IR3-H2-HD IGURE EAR VIEW OF THE For more information & technical support: (+1) 714-671-8500 · support@fg-detection.com... -
Page 9: Accessories
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.5 Accessories 1.5.1 Mounting Bracket The detector should be mounted using the stainless-steel tilt mount part number FLS-TMO-S02. This allows the detector to be securely attached to a wall, pole or other solid surface using appropriate fixings. -
Page 10: Figure 5 - Pole Mount
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.5.3 Pole mount The pole mount enables the detectors to be installed with its tilt mount brackets. The pole mount kit we supply are suitable for 2-inch or 3-inch poles. Part number FLS-PMA-S23. 5 - P IGURE OUNT... -
Page 11: Figure 7 - Flame Simulator Kit
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.5.5 Flame Simulator The FLS-IR3-H2-HD may be tested using the FLS-FSIM-IR3-H2-KIT. The FlameSpec flame simulator family provides a fast and convenient means of periodically testing the detector and control system end-to-end. Maintenance costs can be reduced as the detectors can be tested in situ without needing a hot work permit. -
Page 12: Figure 9 - Duct Mount Dmx-S02
F140V0020.11 FlameSpec IR3 H2 HD User Manual 1.5.6 Duct Mounts Duct Mount DMX-S02 The FLS-DMX-S02 allows a standard (non-HD) detector to be mounted remotely from a potential fire source by allowing the device to look through cut hole in the side of a duct. This duct mount must be use with air shield FLS-ASD-S02. -
Page 13: Installation
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2 Installation This chapter does not attempt to cover all standard practices and codes of installation. Rather, it emphasizes specific points of consideration and provides some general rules for qualified personnel. You must always observe special safety precautions. 2.1 General Considerations This section includes important information. -
Page 14: Figure 11 - Horizontal Field Of View, 90
F140V0020.11 FlameSpec IR3 H2 HD User Manual 11 - H , 90°. IGURE ORIZONTAL IELD OF 12 - V , 80°. IGURE ERTICAL IELD OF For more information & technical support: (+1) 714-671-8500 · support@fg-detection.com... -
Page 15: Preparations For Installation
F140V0020.11 FlameSpec IR3 H2 HD User Manual Environment Environmental conditions including but not limited to dust, snow or rain can reduce the detectors sensitivity and require additional consideration. Hot Work Arc welding should not be performed within 12 ft. (3.5m) of the detector. It is recommended that the system be inhibited during welding operations in situations where the possibility of a false alarm cannot be tolerated. -
Page 16: Required Tools
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.3 Required Tools The detector can be installed using the following tools: Tool Function Hex. KEY 6 mm Vertical alignment Hex. KEY 10 mm Horizontal alignment Wrench 13 mm Mounting the detector Flat Screwdriver 6 mm Ground screw connection Flat screwdriver 3.5mm Terminal connection... -
Page 17: Mounting The Tilt Mount
F140V0020.11 FlameSpec IR3 H2 HD User Manual • The internal terminals are suitable for connection of a wire equal to or greater than the power input wiring and at a minimum of 1mm / 17AWG conductor. 2.5 Mounting the Tilt Mount The tilt mount enables the detector to be rotated up to 45 degrees (horizontal/vertical) in all directions. -
Page 18: Mounting The Detector
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.6 Mounting the detector Use the following steps to connect the detector to the tilt mount, referring to Figure 15 : a) Place the detector, with its cable/conduit entries pointing down, on the holding plate of the tilt mount (item 2). -
Page 19: Electrical Wiring
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.7 Electrical Wiring Warning • The sensor module in the front half of the detector contains no serviceable components and should never be opened. Opening will invalidate the warranty of the detector. The terminal compartment at the back is the only part of the housing that should be opened by the user. -
Page 20: Table 1: Terminal Connections
“24 VDC (-)” terminals (2 or 12)”. See 3.11 Manual BIT – Alarm Output Test for more details. RS 485 (+) RS-485 Modbus communication (used by the “FGD Communicator” software) RS 485 (-) Ethernet TX+... -
Page 21: Current Output (0-20Ma) Wiring
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.8 Current Output (0-20mA) Wiring The detector’s 0-20mA current output can act as both a source or a sink transmitter and can be 3-wire or 4-wire connected. The following drawing shows how to wire the detector to act as a current source isolated transmitter (4-wire connection): 17 –... -
Page 22: Figure 19 - Source 3-Wire Scheme
F140V0020.11 FlameSpec IR3 H2 HD User Manual The following drawing shows how to wire the detector to act as a current source non-isolated transmitter (3-wire connection): 19 – S IGURE OURCE CHEME Note: Link between 3 and 11 to be wired on site The following drawing shows how to wire the detector to act as a current sink non-isolated transmitter (3- wire connection): 20 –... -
Page 23: Wire Relay Connection
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.9 4 Wire Relay Connection This wiring option uses the fault and alarm relay and are connected to fire alarm panels. This connection allows to connect several detectors on 4 wires in a single loop. On the last detector there is a connected EOL resistor in the connection box. -
Page 24: Rs-485 Communication Network
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.10 RS-485 Communication Network Using the RS-485 network capability of the detector and communicator software, it is possible to connect up to 32 detectors in an addressable system with only 4 wires (2 for power and 2 for communication). Using repeaters, the number of detectors can be much larger (32 detectors for each repeater) up to 247 on the same 4 wires. -
Page 25: Cabling Recommendations
F140V0020.11 FlameSpec IR3 H2 HD User Manual 2.11 Cabling Recommendations The cable used should be appropriate for the hazardous area classification and meet local, national and company regulations. In order to comply with EMC regulations, the cable must be shielded and the detector grounded. The use of industrial grade, suitably armored field cable is recommended). -
Page 26: Configuration Options
Some functions of the detector can be configured using an RS-485 modem connected to a computer with the “FGD communicator” software. For details of how to download the software please contact technical support on: (+1) 714-671-8500 or via email at support@fg-detection.com. -
Page 27: Sensitivity
F140V0020.11 FlameSpec IR3 H2 HD User Manual 3.1 Sensitivity The detector can be configured to one of five sensitivity levels: very low, low, medium, high and extreme. The following table lists for each sensitivity setting the maximum distance, in which a standard H fire would be reliably detected. -
Page 28: Auxiliary Relay
NTSC or PAL format, depending on the “Video analog output” setting. 3.10 Modbus Address The detector can communicate with the FGD communicator software using a Modbus RTU compatible protocol on RS-485. This protocol allows for a network of detectors to be connected, each with a unique Modbus address. -
Page 29: Manual Bit - Alarm Output Test (Full Loop Test)
F140V0020.11 FlameSpec IR3 H2 HD User Manual 3.11 Manual BIT – Alarm Output Test (Full loop test) When enabled, the alarm outputs are activated when a Manual BIT is initiated. See section 4.2 for details. WARNING Make sure all fire extinguishing actions or alarms connected to the detector are DISABLED when the manual BIT is initiated and the “Manual BIT –... -
Page 30: Operation
F140V0020.11 FlameSpec IR3 H2 HD User Manual 4 Operation The FlameSpec-IR3-H2-HD is a triple-IR flame detector that includes a built-in high-definition video camera module. The video module automatically records video of alarm events and can provide live video of the detection zone to a screen in the control room. -
Page 31: Testing
The BIT process runs automatically at startup and periodically during the operation of the detector. The BIT can also be initiated manually by connecting the “Manual BIT” terminal and the “24 VDC (-)“ terminal for one second (see Table 1) or by using the FGD communicator software (connected through RS-485). -
Page 32: Maintenance
F140V0020.11 FlameSpec IR3 H2 HD User Manual 5 Maintenance After powering up, the detector should work maintenance free. Regular checks should be in the form of a physical inspection and to periodically ensure the optical surfaces are clean (windows and reflective mirror). It is also recommended to perform a function test annually or in line with local requirements, whichever is the sooner. -
Page 33: Troubleshooting
F140V0020.11 FlameSpec IR3 H2 HD User Manual 6 Troubleshooting Use the table below to help troubleshoot any detector operational issues. Detector Status Possible Cause Corrective Action LEDs Off No power to the unit • Check that the power is connected to the detector. -
Page 34: Servicing
Refer to the detector warranty statement in section 12. 8 FGD Communicator Software The FGD Communicator software can be used to configure and monitor the FlameSpec-IR3 flame detector. The software communicates using Modbus over an RS-485 port to the detector. Modbus commands enable the user to configure parameters and monitor the status of the detector. -
Page 35: Specifications
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9 Specifications 9.1 Fire Detection • Detection time and distance: o 40ms - for fast fire burst or explosion. o 1.5s - for 32″ (0.8m) hydrogen fire at 0–66ft. (0–20m). o 4s - for 32″ (0.8m) hydrogen fire at 66–100ft. (20–30m). •... -
Page 36: Outputs
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9.4 Outputs • Relays: Volt-free contacts rated 2A at 30 VDC o Alarm: Normally open. o Auxiliary: state selectable. o Fault : Closed when detector is operating without fault. • 0-20mA current output: o 3 wire or 4 wire (isolated) configurations, both sink or source. -
Page 37: Product Labelling
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9.7 Product Labelling 9.7.1 Ex db 9.7.2 Ex db eb For more information & technical support: (+1) 714-671-8500 · support@fg-detection.com... -
Page 38: Warning Label
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9.7.3 Warning Label For more information & technical support: (+1) 714-671-8500 · support@fg-detection.com... -
Page 39: Approvals
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9.8 Approvals Note: All items are designed and tested to meet the relevant requirements. • Explosion proof: o ATEX: II 2 G D Ex db IIC T6 Gb or Ex db eb IIC T6 Gb and Ex tb IIIC T80°C Db -55°C≤Ta≤60°C Ex db IIC T5 Gb or Ex db eb IIC T5 Gb and Ex tb IIIC T95°C Db -55°C≤Ta≤75°C Ex db IIC T4 Gb or Ex db eb IIC T4 Gb and Ex tb IIIC T105°C Db -55°C≤Ta≤85°C o UKCA... -
Page 40: Electromagnetic Compatibility
F140V0020.11 FlameSpec IR3 H2 HD User Manual 9.9 Electromagnetic Compatibility The detector fully complies with EMC directive 2014/30/EU and protected against interference caused by RFI and EMI. The cables to the detector must be shielded and the detector must be grounded in order to comply to the EMC directive. - Page 41 F140V0020.11 FlameSpec IR3 H2 HD User Manual Syngas 32-in Plume 13 (4) *Syngas mixture: 30% volume methane (CH ), 70% volume hydrogen (H 10.1.2 FLS-IR3-H2-HD-ASX3, FLS-IR3-H2-HD-ASX4. Extreme Sensitivity Fuel Pan Size Distance ft (m) Average Response Time (Seconds) n-Heptane 1X1 ft 180 (55) Kerosene 1X1 ft...
- Page 42 F140V0020.11 FlameSpec IR3 H2 HD User Manual 32-in Plume 20 (6) 32-in Plume 33 (10) Methane 32-in Plume 26 (8) Very Low Sensitivity Fuel Pan Size Distance ft (m) Average Response Time (Seconds) n-Heptane 1X1 ft 25 (7.5) Kerosene 1X1 ft 13 (4) Jet fuel 1X1 ft...
-
Page 43: False Alarm Immunity
F140V0020.11 FlameSpec IR3 H2 HD User Manual 10.2 False Alarm Immunity The following table shows test results of false alarm immunity for detectors configured to “Extreme” sensitivity. For each radiation source a distance is listed. This is the minimum tested distance, from which the detectors did not alarm when exposed to the radiation source (either modulated or non-modulated). - Page 44 F140V0020.11 FlameSpec IR3 H2 HD User Manual 10.2.2 False Stimuli only at Extreme Sensitivity - FLS-IR3-H2-HD-ASX3, FLS-IR3-H2-HD-ASX4. False Alarm Source Minimum alarm distance ft (m) Sunlight, Direct, Reflected N.R. Sunlight, Direct, reflected with water N.R. drops on sensors Incandescent frosted glass light, 300W N.R.
-
Page 45: Ordering Information
11 Ordering Information Part Number Description Flame Detector FLS-IR3-H2-HD-AS11 FlameSpec IR3-H2-HD, ATEX, FMus, FMc and IECEx certified, 316SS, M25 Entries with Near IR camera FLS-IR3-H2-HD-AS21 FlameSpec IR3-H2-HD, ATEX, FMus, FMc and IECEx certified, 316SS, 3/4”NPT Entries with Near IR camera... -
Page 46: Warranty
F140V0020.11 FlameSpec IR3 H2 HD User Manual 12 Warranty FIRE & GAS DETECTION TECHNOLOGIES INC. agrees to extend to Purchaser/Distributor a warranty on the FIRE & GAS DETECTION TECHNOLOGIES INC. supplied components of the FlameSpec products. FIRE & GAS DETECTION TECHNOLOGIES INC. warrants to Purchaser/Distributor that the products are free from defects in materials and workmanship for a period of five (5) years, commencing with the date of delivery to Purchaser/Distributor.
