Page 5
FlameSpec IR3 User Manual Doc. No. F120V0020.05 List of Figures Figure 1: Tilt Mount Base - Rear View ......................7 Figure 2: Tilt mount base – Side View ......................8 Figure 3: Detector on Tilt Mount – Side View ....................9 Figure 4 –...
FlameSpec IR3 User Manual F120V0020.05 1. Introduction The FlameSpec-IR3 flame detector provides ultra-fast response, high performance and reliable detection of all types of hydrocarbon fires (visible and non-visible). The detector addresses slow growing fires as well as fast eruption of fire using improved Triple IR (IR3) technology. It operates in all weather and light conditions with highest immunity to false alarms.
FlameSpec IR3 User Manual F120V0020.05 1.3 Internal tests During normal operation, the flame detector performs self-tests of its optics, electronics and software. These include a periodic BIT (Built-In-Test) in which the sensors and window cleanliness are tested. Any detected fault is indicated as shown in Table 4 (in section 5.1).
FlameSpec IR3 User Manual F120V0020.05 2 Installation The detector is intended for use as part of a complex system where many detectors and other devices are integrated with different vendors’ systems and interface communication to a variety of different types and configuration control units and panels including control of instrumentations computers.
Page 9
FlameSpec IR3 User Manual F120V0020.05 Environment ▪ Environmental conditions including but not limited to dust, snow or rain can reduce the detectors sensitivity and require additional maintenance. Welding ▪ Arc welding should not be performed within 15 ft. (5m) of the detector. It is recommended that the system be inhibited during welding operations in situations where the possibility of a false alarm cannot be tolerated.
FlameSpec IR3 User Manual F120V0020.05 2.2 Preparations for Installation The installation must comply with local regulations and standards applicable to flame detectors (e.g., NFPA 72) and all local and common engineering practices. It is recommended to consult with a safety engineer.
Page 11
FlameSpec IR3 User Manual F120V0020.05 • The equipment is certified for use in ambient temperatures in the range of -67°F to +167°F (-55°C to +75°C) or -67°F to +185°F (-55°C to +85°C) and should not be used in temperatures outside this range.
FlameSpec IR3 User Manual F120V0020.05 2.5 Installing the Tilt Mount The tilt mount enables the detector to be rotated up to 45 degrees (horizontal/vertical) in all directions. The following installation instructions show how to use it to support the detector from below (the preferred method).
FlameSpec IR3 User Manual F120V0020.05 The following drawing is a side view of the tilt mount: Figure 2: Tilt mount base – Side View 2.6 Installing the detector Use the following steps to connect the detector to the tilt mount, referring to Figure 3:...
FlameSpec IR3 User Manual F120V0020.05 3 Configuration options Some functions of the detector can be configured using an RS-485 modem connected to a computer with the “FDG communicator” software. These configuration options are listed in the following table along with their factory default values.
3.6 Modbus Address The detector can communicate with the “FGD communicator” software using a Modbus RTU compatible protocol on RS-485. This protocol allows for a network of detectors to be connected, each with a unique Modbus address. The address of the detector can be set to any value in the range 1–247.
See 3.7 Manual BIT – Alarm Output Test for more details. Shield This terminal should be left connected to the housing internal ground screw. RS 485 (+) RS-485 Modbus communication (used by the “FGD Communicator” software) RS485 (-) Fault Relay (NC) Alarm Relay (NC)
FlameSpec IR3 User Manual F120V0020.05 4.2 Current Output (0-20mA) Wiring The detector’s 0-20mA current output can act as both a source or a sink transmitter and can be 3- wire or 4-wire connected. The following drawing shows how to wire the detector to act as a current source isolated transmitter...
FlameSpec IR3 User Manual F120V0020.05 The following drawing shows how to wire the detector to act as a current source non-isolated transmitter (3-wire connection): 24VDC Return Controller Detector 6 – S IGURE OURCE CHEME The following drawing shows how to wire the detector to act as a current sink non-isolated...
(fault, alarm) and to initiate a BIT to each detector individually. The detector communicates via RS-485 with a Modbus RTU compatible protocol. For more details on the communication protocol, please consult with FGD. Figure 8: RS-485 Networking www.acornfiresecurity.com...
FlameSpec IR3 User Manual F120V0020.05 5 Operation The FlameSpec-IR3 is a triple-IR flame detector ready for detecting fire approximately 30 seconds after power up. During this startup time the LED flashes Yellow. If the startup is successful, the indication LED turns to green, the 0-20mA indicates 4mA and the fault relay is closed.
The BIT process runs automatically at startup and periodically during the operation of the detector. The BIT can also be initiated manually by short circuiting the “Manual BIT” terminal and the “24 VDC (-)“ terminal for one second (see Table 3) or by using the FGD communicator software (connected through RS-485).
FlameSpec IR3 User Manual F120V0020.05 c) Where dust, dirt or moisture accumulates on the window, first clean the window with a soft optical cloth and detergent, and then rinse with a clean soft cloth, cotton swab, or tissue. 5.4 Troubleshooting...
FlameSpec IR3 User Manual F120V0020.05 6 Specifications 6.1 Fire Detection • Detection time and distance: o 40ms - for fast fire burst or explosion o 1.5s - for 1ft (0.1m ) N-heptane pan fire at 100 ft (30m) o 4s - for 1ft (0.1m...
FlameSpec IR3 User Manual F120V0020.05 6.7 Approvals Note: All items are designed and tested to meet the relevant requirements. • Explosion proof: o ATEX: II 2 G D Ex db IIC T5 Gb or Ex db eb IIC T5 Gb and Ex tb IIIC T95°C Db -55°C<Ta<75°C Ex db IIC T4 Gb or Ex db eb IIC T4 Gb and Ex tb IIIC T105°C Db -55°C<Ta<85°C...
FlameSpec IR3 User Manual F120V0020.05 7 Warranty FIRE & GAS DETECTION TECHNOLOGIES INC. agrees to extend to Purchaser/Distributor a warranty on the FIRE & GAS DETECTION TECHNOLOGIES INC. supplied components of the FlameSpec products. FIRE & GAS DETECTION TECHNOLOGIES INC. warrants to Purchaser/Distributor that the products are free from defects in materials and workmanship for a period of five (5) years, commencing with the date of delivery to Purchaser/Distributor.
FlameSpec IR3 User Manual F120V0020.05 Appendix A Response Characteristics Response to different fire scenarios The following tables show test results of detection distances and times for different fire scenarios. Each table lists results for a different sensitivity setting. For liquid fires the size of fire refers to the size of the pan, filled with the fuel.
FlameSpec IR3 User Manual F120V0020.05 Medium Sensitivity Fuel Pan Size Distance ft (m) Average Response Time (Seconds) N-Heptane 1 x 1 ft 98 (30) Gasoline 1 x 1 ft 98 (30) Methane 32-in Plume 82 (25) 32-in Plume 98 (30)
Page 31
FlameSpec IR3 User Manual F120V0020.05 False Stimuli only at Extreme Sensitivity False Alarm Source Maximum Distance in ft (m) Sunlight, Direct, Reflected Incandescent frosted glass light, 300W 2 (0.5) Fluorescent, 70W (3x23.3W) 2 (0.5) Electric arc 2 (0.5) Arc welding...
