Sony INZONE H9, INZONE H7, YY2959, YY2960 Manual

Specifications

Headset

Power source:
DC 3.85 V: Built-in lithium-ion rechargeable battery
DC 5 V: When charged using USB
Operating temperature:
0°C to 40°C
Rated power consumption:
3 W
Mass:
YY2959: Approx. 330 g
YY2960: Approx. 325 g

Microphone
Type: Electret condenser
Directivity: Bi directional
Effective frequency range: 100 Hz - 8 000 Hz
Functional difference:

Noise Cancelling
YY2959
YY2960

Included items:
YY2959: Wireless Noise Cancelling Gaming Headset (1)
YY2960: Wireless Gaming Headset (1)
YY2959/YY2960:
USB Type-C® cable (USB-A to USB-C®) (approx. 150 cm) (1)
USB Transceiver (YY2965) (1)

Communication specification

Communication system: Bluetooth Specification version 5.0
Output: Bluetooth Specification Power Class 1
Frequency band:
Bluetooth: 2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Wireless Transmitter Receiver Section: 2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Operating frequency:
|Bluetooth: 2 400 MHz - 2 483.5 MHz
Wireless Transmitter Receiver Section: 2 400 MHz - 2 483.5 MHz
Maximum output power:
YY2959: Bluetooth: < 9.3 dBm
Wireless Transmitter Receiver Section: < 8.2 dBm
YY2960:
Bluetooth: < 8.2 dBm
Wireless Transmitter Receiver Section: < 8.8 dBm
YY2965: Wireless Transmitter Receiver Section: < 8.6 dBm
Design and specifications are subject to change without notice.

System requirements for battery charge using USB
USB AC adaptor

A commercially available USB AC adaptor capable of supplying an output current of 0.5 A (500 mA) or more

Recommended Personal Computer OS version
Windows®: Windows 10 or later
Mac: macOS 11 or later


Do not install the product in a confined space, such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries installed) to excessive heat, such as sunshine, fire or the like, for a long time.
Do not subject the batteries to extreme low temperature conditions that may result in overheating and thermal runaway. Do not dismantle, open, or shred secondary cells or batteries. In the event of a cell leaking, do not allow the liquid to come in contact with the skin or eyes. If contact has been made, wash the affected area with copious amounts of water and seek medical advice.
Secondary cells and batteries need to be charged before use. Always refer to the manufacturer's instructions or product manual for proper charging instructions.
After extended periods of storage, it may be necessary to charge and discharge the cells or batteries several times to obtain maximum performance.
Dispose of properly.
This unit has been tested and found to comply with the limits set out in the EMC regulation using a connection cable shorter than 3 m.
High volume may adversely affect your hearing.
Do not use the unit while walking, driving, or cycling. Doing so may cause traffic accidents.
Do not use in hazardous areas unless the surrounding sound can be heard.
The unit is not waterproof. If water or foreign matter enters the unit, it may result in fire or electric shock. If water or foreign matter enters the unit, stop use immediately and consult your nearest Sony dealer. In particular, be careful in the following cases.

  • When using the unit near a sink or liquid container
    Be careful that the unit does not fall into a sink or container filled with water.
  • When using the unit in the rain or snow, or in humid locations
  • When using the unit while you are perspiring
    If you touch the unit with wet hands, or put the unit in the pocket of a damp article of clothing, the unit may get wet.

For details on the effects of contact with the human body from the mobile phone or other wireless devices connected to the unit, refer to the instruction manual of the wireless device.
Never insert the USB plug when the unit or charging cable is wet. If the USB plug is inserted while the unit or charging cable is wet, a short circuit may occur due to liquid (tap water, seawater, soft drink, etc.) or foreign matter on the unit or charging cable, and cause abnormal heat generation or malfunction.
This product (including accessories) has magnet(s) which may interfere with pacemakers, programmable shunt valves for hydrocephalus treatment, or other medical devices. Do not place this product close to persons who use such medical devices. Consult your doctor before using this product if you use any such medical device.
There is a danger that small parts may be swallowed. After use, store in a location out of reach of small children.
Note about static electricity
If you use the unit when the air is dry, you may experience discomfort due to static electricity accumulated on your body. This is not a malfunction of the unit. You can reduce the effect by wearing clothes made of natural materials that do not easily generate static electricity.

Precautions

The two-dimensional code or the URL on the cover will help you access the help guide that describes useful notes or procedures in details.

On BLUETOOTH® communications

  • Microwaves emitting from a Bluetooth device may affect the operation of electronic medical devices. Turn off this unit and other Bluetooth devices in the following locations, as it may cause an accident:
    • in hospitals, near priority seating in trains, locations where inflammable gas is present, near automatic doors, or near fire alarms.
  • The audio playback on this unit may be delayed from that on the transmitting device, due to the characteristics of Bluetooth wireless technology. As a result, the sound may not be in sync with the image when viewing movies or playing games.

On charging the unit

  • Be sure to use the supplied USB Type-C cable.
  • After charging is complete, disconnect the USB Type-C cable.
  • While connecting the USB cable, do not apply excessive force to the connection part.
  • When connecting or disconnecting the USB cable, do not apply excessive force, such as by pulling the cable, and connect or disconnect the connector straight to the port to be connected.
  • If the USB cable connector is deformed, such as by it being bent, stop use immediately.

Notes on wearing the unit

  • After use, remove the headphones slowly.
  • Because the headphones achieve a tight seal over the ears, forcibly pressing them against your ears or quickly pulling them off can result in eardrum damage.
    Pressing the headphones against your ears may cause the speaker diaphragm to produce a click sound. This is not a malfunction.

Other notes

  • Do not apply weight or pressure to the unit for long periods, including when it is stored, as it may cause deformation.
  • If you experience discomfort while using the unit, stop using it immediately.
  • Be careful that the boom microphone does not hit your eyes while wearing, removing, and using the unit.
  • If you have any questions or problems concerning this unit that are not covered in this manual, please consult your nearest Sony dealer.
