Preliminary User's Manual

µPD780812

µPD780814

µPD78F0818

8-bit Single-Chip Microcontroller

Hardware

Document No. U13413EE1V0UM00

Date Published April 1998

© NEC Corporation 1998

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the mPD780812 and is the answer not in the manual?

Questions and answers

Summary of Contents for NEC mPD780812

Page 1 Preliminary User’s Manual µPD780812 µPD780814 µPD78F0818 8-bit Single-Chip Microcontroller Hardware Document No. U13413EE1V0UM00 Date Published April 1998 © NEC Corporation 1998...
Page 2 Specific: Aircrafts, aerospace equipment, submersible repeaters, nuclear reactor control systems, life support systems or medical equipment for life support, etc. The quality grade of NEC devices is “Standard“ unless otherwise specified in NEC's Data Sheets or Data Books. If customers intend to use NEC devices for applications other than those specified for Standard quality grade, they should contact NEC Sales Representative in advance.
Page 3: Regional Information
Some information contained in this document may vary from country to country. Before using any NEC product in your application, please contact the NEC office in your country to obtain a list of authorized representatives and distributors. They will verify: •...
Page 4 µPD780812, µPD780814, µPD78F0818 Introduction Readers This manual has been prepared for user engineers who want to understand the functions of the µPD780814 subseries and design and develop its application systems and programs. µPD780814 Subseries: µPD780812, µPD780814, µPD78F0818 Purpose This manual is intended for users to understand the functions described in the Organization below. Organization The µPD780814 subseries manual is separated into two parts: this manual and the instruction edition (common to the 78K/0 series).
Page 5 µPD780812, µPD780814, µPD78F0818 Chapter Organization This manual devides the descriptions for the subseries into different chapters as shown below. Read only the chapters related to the device you use. Chapter µPD780812 µPD780814 µPD78F0818 ‰ ‰ ‰ Chapter 1 Outline (µPD780814 Subseries) ‰...
Page 6 µPD780812, µPD780814, µPD78F0818 Related Documents The related documents indicated in this publication may include preliminary versions. However, preliminary versions are not marked as such. • Related documents for µPD780814 subseries D ocum ent N o. D ocum ent nam e Japanese English µPD 780814 Prelim inary Product Inform ation...
Page 7 C10943X IEI-1213 Semiconductor Device Mounting Technology Manual C10535J C10535E Quality Grade on NEC Semiconductor Devices C11531J C11531E Reliability Quality Control on NEC Semiconductor Devices C10983J C10983E Electric Static Discharge (ESD) Test MEM-539 — Semiconductor Devices Quality Assurance Guide MEI-603 MEI-1202...
Page 8: Table Of Contents
µPD780812, µPD780814, µPD78F0818 Contents Chapter 1 Outline (µPD780814 Subseries) ..................Features ..........................Application ........................... Ordering Information ......................Pin Configuration (Top View) ....................78K/0 Series Development ....................Block Diagram ........................Overview of Functions ......................Differences between Flash and Mask ROM version ............Chapter 2 Pin Function (µPD780814 Subseries) ................
Page 9 µPD780812, µPD780814, µPD78F0818 Processor Registers ......................3.2.1 Control registers ...................... 3.2.2 General registers ...................... 3.2.3 Special function register (SFR) ................Instruction Address Addressing ..................3.3.1 Relative addressing ....................3.3.2 Immediate addressing ..................... 3.3.3 Table indirect addressing ..................3.3.4 Register addressing ....................Operand Address Adressing ....................
Page 10 µPD780812, µPD780814, µPD78F0818 Chapter 6 Clock Generator ......................Clock Generator Functions ....................Clock Generator Configuration .................... Clock Generator Control Register ..................System Clock Oscillator ...................... 100 6.4.1 Main system clock oscillator .................. 100 6.4.2 Subsystem clock oscillator ..................101 6.4.3 When no subsystem clocks are used ..............
Page 11 µPD780812, µPD780814, µPD78F0818 Chapter 10 8-Bit Timer/Event Counters 50 and 51 ................ 158 10.1 8-Bit Timer/Event Counters 50 and 51 Functions .............. 158 10.1.1 8-Bit Operation Modes ..................... 159 10.1.2 16-Bit Operation Modes ................... 161 10.2 8-Bit Timer/Event Counters 50 and 51 Configurations ............. 162 10.3 8-Bit Timer/Event Counters 50 and 51 Control Registers ..........
Page 12 µPD780812, µPD780814, µPD78F0818 Chapter 14 A/D Converter ........................ 204 14.1 A/D Converter Functions ..................... 204 14.2 A/D Converter Configuration ....................205 14.3 A/D Converter Control Registers ..................207 14.4 A/D Converter Operations ....................210 14.4.1 Basic operations of A/D converter ................210 14.4.2 Input voltage and conversion result ...............
Page 13 µPD780812, µPD780814, µPD78F0818 Chapter 18 CAN Controller ......................259 18.1 Protocol ..........................260 18.1.1 Protocol mode function ................... 260 18.1.2 Message format ......................260 18.1.3 Data frame/remote frame ..................261 18.1.4 Error frame ....................... 266 18.1.5 Overload frame ......................267 18.2 Function ..........................
Page 14 µPD780812, µPD780814, µPD78F0818 18.18 Functional Description by Flowcharts ................322 18.18.1 Initialization ......................322 18.18.2 Prepare transmit ....................323 18.18.3 Abort transmit ....................... 324 18.18.4 Handling by the DCAN ..................325 18.18.5 Receive event oriented ..................326 18.18.6 Receive task oriented ................... 327 Chapter 19 Interrupt Functions .......................
Page 15 µPD780812, µPD780814, µPD78F0818 Chapter 23 µPD78F0818 ........................368 23.1 Memory Size Switching Register (IMS) ................369 23.2 Internal Extension RAM Size Switching Register .............. 370 23.3 Flash Memory Programming ....................371 23.3.1 Selection of transmission method ................371 23.3.2 Initialization of the programming mode ..............371 23.3.3 Flash memory programming function ..............
Page 16 µPD780812, µPD780814, µPD78F0818 Contents of Figures Figure No. Title Page Pin Configuration ......................Block Diagram ........................ Connection of IC Pins ..................... Pin Input/Output Circuits (2/2) ..................Memory Map (µPD780812) ..................... Memory Map (µPD780814) ..................... Memory Map (µPD78F0818) ................... Data Memory Addressing (µPD780812) ................Data Memory Addressing (µPD780814) ................
Page 17 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page Block Diagram of Clock Generator .................. Processor Clock Control Register Format ............... External Circuit of Main System Clock Oscillator ............100 External Circuit of Subystem Clock Oscillator ..............101 Examples of Oscillator with Bad Connection (3/3) ............102 Main System Clock Stop Function (1/2) ................
Page 18 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page Timer 0 (TM0) Block Diagram ..................148 16-Bit Timer Mode Control Register (TMC2) Format ............150 Capture Pulse Control Register (CRC2) Format ............... 151 Prescaler Mode Register (PRM2) Format ................ 152 Configuration Diagram for Pulse Width Measurement by Using the Free Running Counter....................
Page 19 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page 13-1 Remote Controlled Output Application Example .............. 199 13-2 Clock Output Control Circuit Block Diagram ..............200 13-3 Clock Output Selection Register (CKS) Format ............... 201 13-4 Port Mode Register 2 Format ..................202 14-1 A/D Converter Block Diagram ..................
Page 20 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page 18-1 Data Frame ........................261 18-2 Remote Frame ........................ 261 18-3 Data Frame ........................262 18-4 Arbitration Field/Standard Format Mode ................262 18-5 Arbitration Field/Expanded Format Mode ................ 262 18-6 Control Field ........................263 18-7 Data Field ........................
Page 21 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page 18-46 Receive Message Register ..................... 315 18-47 Mask Control Register ....................316 18-48 Redefinition Control Register ................... 318 18-49 Initialization Flow Chart ....................322 18-50 Transmit Preparation ....................... 323 18-51 Transmit Abort, Software Flow ..................324 18-52 Handling of Semaphore Bits by DCAN-Module ..............
Page 22 µPD780812, µPD780814, µPD78F0818 Figure No. Title Page 22-1 Block Diagram of RESET Function ................. 362 22-2 Timing of Reset Input by RESET Input ................363 22-3 Timing of Reset due to Watchdog Timer Overflow ............363 22-4 Timing of Reset Input in STOP by RESET Input ............. 363 23-1 Memory Size Switching Register Format ................
Page 23 µPD780812, µPD780814, µPD78F0818 Contents of Tables Table No. Title Page Differences between Flash and Mask ROM version ............Pin Input/Output Types ....................... Non-Port Pins ........................Types of Pin Input/Output Circuits ..................Internal ROM Capacities ....................Vectored Interrupts ......................Special Function Register List (3/3) ................... Implied Addressing ......................
Page 24 µPD780812, µPD780814, µPD78F0818 Table No. Title Page 10-11 8-Bit Timer/Event Counters 51 Square-Wave Output Ranges (8-Bit Timer/Event Counter Mode) ..................176 10-12 8-Bit Timer/Event Counters Interval Times (16-Bit Timer/Event Counter Mode) ....182 10-13 8-Bit Timer/Event Counter 50 Square-Wave Output Ranges (16-Bit Timer/Event Counter Mode) ..................
Page 25 µPD780812, µPD780814, µPD78F0818 Table No. Title Page 18-15 Error Counter ........................271 18-16 Segment Name and Segment Length ................. 272 18-17 CAN Configuration ......................279 18-18 SFR Definitions ........................280 18-19 SFR Bit Definitions ......................280 18-20 Message and Buffer Structure ................... 281 18-21 Transmit Message Structure ....................
Page 26: Chapter 1 Outline (Μpd780814 Subseries)
µPD780812, µPD780814, µPD78F0818 Chapter 1 Outline (µPD780814 Subseries) 1.1 Features • Internal high capacity ROM and RAM Item Data Memory Program Internal Internal Memory Package Part High-Speed Expansion EEPROM (ROM) Number µPD780812 16K bytes 512 bytes 288 bytes 256 bytes 64-pin plastic QFP (fine pitch) µPD780814 32K bytes...
Page 27: Pin Configuration (Top View)
µPD780812, µPD780814, µPD78F0818 1.4 Pin Configuration (Top View) Ý 64-pin plastic QFP (12 x 12 mm) µPD780812GK-XXX-8A8 µPD780814GK-XXX-8A8 µPD78F0818GK-XXX-8A8 Figure 1-1: Pin Configuration Cautions: 1. Connect IC (internally connected) pin directly to V 2. AV pin should be connected to V 3.
Page 28 µPD780812, µPD780814, µPD78F0818 Pin Identifications P00 to P03 : Port0 : Receive Data P10 to P17 : Port1 : Transmit Data P20 to P27 : Port2 : Programmable Clock Output P40 to P47 : Port4 X1, X2 : Crystal (Main System Clock) P50 to P57 : Port5 CL1, CL2...
Page 29: Series Development
µPD780812, µPD780814, µPD78F0818 1.5 78K/0 Series Development These products are a further development in the 78K/0 Series. The designations appearing inside the boxes are subseries names. Products in mass production Products under development Y subseries products are compatible with I C bus.
Page 30: Block Diagram
µPD780812, µPD780814, µPD78F0818 1.6 Block Diagram Figure 1-2: Block Diagram TI00/TO0 16 bit Timer 0 TI01 Port 0 TI20 16 bit Timer 2 TI21 16 K / 32 K TI22 78K/0 512 Bytes / Port 1 1024 Bytes / TI50/TO50 8 bit Timer 50 Core 1024 Bytes...
Page 31: Overview Of Functions
µPD780812, µPD780814, µPD78F0818 1.7 Overview of Functions Part Number D780812 D780814 D78F0818 Item 16 K bytes 32 K bytes 60 K bytes Internal high-speed 512 Bytes 1024 Bytes 1024 Bytes Internal memory Internal expansion RAM 288 Bytes 288 Bytes 992 Bytes EEPROM 256 K bytes Memory space...
Page 32: Differences Between Flash And Mask Rom Version
µPD780812, µPD780814, µPD78F0818 1.8 Differences between Flash and Mask ROM version The differences between the two versions are shown in the table below. Differences of the electrical specification are given in the data sheet. Table 1-1: Differences between Flash and Mask ROM version Flash Version Mask ROM Version Flash EEPROM...
Page 33 µPD780812, µPD780814, µPD78F0818 [Memo]...
Page 34: Chapter 2 Pin Function (Μpd780814 Subseries)
µPD780812, µPD780814, µPD78F0818 Chapter 2 Pin Function (µPD780814 Subseries) 2.1 Pin Function List Normal Operating Mode Pins / Pin Input/Output Types Table 2-1: Pin Input/Output Types Input / After Pin Name Function Alternate Function Output Reset INTP0 Input Port 0 4 bit input / output port INTP1 Input...
Page 35: Non-Port Pins
µPD780812, µPD780814, µPD78F0818 2.2 Non-Port Pins Table 2-2: Non-Port Pins Alternate After Pin Name Function Function Reset INTP0 External interrupts with specifiable valid INTP1 Input edges (rising edge, falling edge, both rising Input INTP2 and falling edges) INTP3 Input Serial interface serial data input Input Output Serial interface serial data output...
Page 36: Description Of Pin Functions
µPD780812, µPD780814, µPD78F0818 2.3 Description of Pin Functions 2.3.1 P00 to P03 (Port 0) This is an 4-bit input/output port. Besides serving as input/output port the external interrupt input is implemented. (1) Port mode P00 to P03 function as input/output ports. P00 to P03 can be specified for input or output bitwise with a port mode register.
Page 37: P40 To P47 (Port 4)
µPD780812, µPD780814, µPD78F0818 (c) TI50 Pin for external count clock input to 8-bit timer/event counter 50. (d) TO50 Pin for output of the 8-bit timer/event counter 50. (e) TI51 Pin for external count clock input to 8-bit timer/event counter 51. (f) TO51 Pin for output of the 8-bit timer/event counter 51.
Page 38: P70, P71 (Port 7)
µPD780812, µPD780814, µPD78F0818 (2) Control mode These ports function as timer capture input. (a) TI20, TI21, TI22 Pins for external capture trigger input to the 16-bit timer capture registers of TM2. 2.3.7 P70, P71 (Port 7) These are 2-bit input/output ports. Besides serving as input/output ports, they function timer input/output. The following operating modes can be specified bit-wise or byte-wise.
Page 39: Reset
µPD780812, µPD780814, µPD78F0818 2.3.14 RESET This is a low-level active system reset input pin. 2.3.15 X1 and X2 Crystal resonator connect pins for main system clock oscillation. For external clock supply, input it to 2.3.16 CL1 and CL2 RC connect pins for sub system clock oscillation. 2.3.17 VDD0, VDD1 VDD0 is the positive power supply pin for ports.
Page 40: Pin I/O Circuits And Recommended Connection Of Unused Pins
µPD780812, µPD780814, µPD78F0818 2.4 Pin I/O Circuits and Recommended Connection of Unused Pins The input/output circuit type of each pin and recommended connection of unused pins are shown in the following table. For the input/output circuit configuration of each type, see table. Table 2-3: Types of Pin Input/Output Circuits (1/2) Input/Output Recommended Connection...
Page 41: Pin Input/Output Circuits (2/2)
µPD780812, µPD780814, µPD78F0818 Table 2-3: Types of Pin Input/Output Circuits (2/2) Input/Output Recommended Connection Pin Name Circuit Type for Unused Pins Connect to Vdd or Vss via CRxD a resistor individually CTxD CL1/CCLK or GND Leave open RESET Connect to V Connect to V Connect directly to V...
Page 42 µPD780812, µPD780814, µPD78F0818 Figure 2-2: Pin Input/Output Circuits Type 1 Type 2 P-ch Data N-ch Type 5-A Type 8-A Pullup Pullup P-ch P-ch enable enable Data Data P-ch P-ch IN/OUT IN/OUT Output Output N-ch N-ch disable disable Input enable Type 11-B Type 10-A Pullup P-ch...
