- Page 1 Maestro Plus Ice Machine with RIDE Technology ™ ™ Installation Instructions for Vision ™ D414AS, E414AS Order parts online www.follettice.com self-contained 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01571298R00 www.follettice.com...
- Page 2 § This appliance must not be cleaned by a water jet. § User maintence should not be done by children. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
-
Page 3: Table Of Contents
Contents Unpack .....................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements ............................5 Dispenser Preparation ..............................6 Install Vision dispenser ...............................6 Install bin signal ................................6 Install transport tube ..............................7 Mount Ice Machine ................................8 Ice machine in cabinet ..............................9 External Connections ..............................11 Air-cooled ice machines only ............................ -
Page 4: Unpack
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine Vision • RIDE Technology Maestro Plus... -
Page 5: Site Preparation
Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements 115 V NEMA 5-15 ➊... -
Page 6: Dispenser Preparation
Dispenser Preparation Install Vision dispenser Refer to Vision Installation, Operation and Service Manual packaged with dispenser for detailed instructions. Install bin signal ➋ Ground Relay in electrical box converts 24 V to contact closure ➊ ➊ 1. Mount the electrical box to the side of the Vision dispenser to establish a ground connection. -
Page 7: Install Transport Tube
Install transport tube Correct installation Incorrect installation § Length of run no more than 20 ft (6 m) § Dips in tube where water can collect § Tube run continuously from ice machine to § Splice or tight bend that restricts ice flow dispenser §... -
Page 8: Mount Ice Machine
Bin thermostat capillary tube mounting Bin thermostat capillary tube mounting Front View, VU155 Front View, VU300 ice tube retaining bracket thermostat thermostat ice tube retaining bracket tabs in ice tube retainer bracket ice tube ice tube engage holes in ice tube and hold tube in place thermostat... -
Page 9: Ice Machine In Cabinet
Ice machine in cabinet Maestro ice machines can be installed undercounter/in-cabinet to fill bins or dispensers using RIDE technology. Care must be taken to ensure proper cabinet venting to avoid recirculation of hot air. Improper venting can cause ice machine outages. Supplied grilles Maestro... - Page 10 Completed installation with air intake gasket gasket and door in place cabinet door Side View door & gasket must mate directly 22.75" (57.8 cm) 29" Front (74 cm) minimum cutout for supplied air intake grille 12"W x 12"H (30 cm x 30 cm) supplied air drain tube intake grille...
-
Page 11: External Connections
1/4" per foot (6,4 mm/0,3 m) pitch. ➋ § Install ice machine potable water supply (3/8" FPT) Note: Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity). -
Page 12: Transport Tube Installation
Transport tube installation Incorrect ice transport tube installation can result in wet ice and dispensing problems. Follow guidelines below to ensure correct installation. Call factory for assistance if you are unable to meet these requirements. General requirements § Maximum length of tube run – 20 ft (6 m). Factory approval required for longer runs. §... -
Page 13: Ride Model Ice Machine Start Up Procedure
RIDE model ice machine start up procedure The start-up procedure below is intended to ensure that ice machine is operating properly after installation has been made. Check each item listed and call factory immediately for assistance if you experience problems with unit. - Page 14 Vision • RIDE Technology Maestro Plus...
- Page 15 Vision • RIDE Technology Maestro Plus...
- Page 16 Maestro Plus is a trademark of Follett Products, LLC. Follett, Chewblet and RIDE are registered trademarks of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01571298R00 www.follettice.com...
