Summary of Contents for Follett Maestro Plus D414AT
- Page 1 Maestro Plus Ice Machine Installation Instructions ™ for Ice Storage Bin Top-mount Applications D414AT, D414ATF, E414AT, E414ATF Order parts online www.follettice.com self-contained 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01570068R00 www.follettice.com...
- Page 2 § This appliance must not be cleaned by a water jet. § User maintence should not be done by children. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
-
Page 3: Table Of Contents
Contents Unpack ....................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements .............................5 Louvered Docking Assembly Installation ........................6 External Connections ..............................7 Air-cooled ice machines only .............................7 Water-cooled ice machines only ..........................7 Icemaker Installation ..............................8 Slide in icemaker ...............................8 Route transport tube and thermostat ........................8 Internal Connections ..............................8 Front Cover ................................... -
Page 4: Unpack
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine ➊ ➋ ➌ ➍ 7/16" 7/16" ➎ ➏ BIN • TOP-MOUNT Maestro Plus... -
Page 5: Site Preparation
Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements 115 V NEMA 5-15 ➊... -
Page 6: Louvered Docking Assembly Installation
Louvered Docking Assembly Installation WARNING! § Docking station must be secured in accordance with these instructions to ensure ice machine stability. § Ventilation openings in the louvered docking station should be clear of obstruction. Failure to do so could result in damage to equipment. -
Page 7: External Connections
1/4" per foot (6,4 mm/0,3 m) pitch. ➋ § Install ice machine potable water supply (3/8" FPT) . Note: Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity). -
Page 8: Icemaker Installation
Icemaker Installation Slide in icemaker Route transport tube and thermostat ice transport tube 1/2" bin thermostat 2" § Slide ice machine into louvered docking assembly § Lubricate transport tube with water then route ➊ transport tube and thermostat through grommet Louvered docking assembly (4.1) MCD425AxT 01034560... - Page 9 5.3.2 Power Cable - 230 V, R290 BROWN BLUE § Make connections as shown. ➊ § Connect power cable to electrical box BIN • TOP-MOUNT Maestro Plus...
-
Page 10: Front Cover
Front Cover Install front cover to ice machine. Install cover Start Up Before turning on power 1. Turn on water to ice machine. 2. Check that hose clamp securely holds ice transport tube on nozzle. After turning on power 1. Turn on power to ice machine and confirm that gearmotor, fan motor and compressor start immediately. - Page 11 BIN • TOP-MOUNT Maestro Plus...
- Page 12 Maestro Plus is a trademark of Follett Products, LLC. Follett, Chewblet and RIDE are registered trademarks of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01570068R00 www.follettice.com...
