MCD425A/W HT, MCE425A HT, MCC425A HT
(See model number configurator on page 2 for details.)
Order parts online
www.follettice.com
fit most countertop dispensers manufactured by
Maestro Plus
™
for Harmony
Maestro Plus top-mount ice machines
Cornelius • Lancer • SerVend
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Ice Machine Installation Instructions
Top-mount Applications
™
self-contained
01033703R02
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Follett Maestro Plus MCD425A HT
Summary of Contents for Follett Maestro Plus MCD425A HT
- Page 1 Maestro Plus Ice Machine Installation Instructions ™ for Harmony Top-mount Applications ™ MCD425A/W HT, MCE425A HT, MCC425A HT (See model number configurator on page 2 for details.) Order parts online www.follettice.com self-contained Maestro Plus top-mount ice machines fit most countertop dispensers manufactured by Cornelius •...
- Page 2 Maestro Plus Chewblet Ice Machine Model Number Configurations Machine Voltage Series Condenser Application Configuration MC Chewblet (425 Series) C 220/60/1 425 up to Air-cooled, self-contained B Ice storage bin S RIDE ® 425 lbs W Water-cooled, H Harmony™ (remote ice delivery (193 kg) equipment) MF Maestro Flake...
- Page 3 Contents Unpack ..................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements ..........................5 Dispenser Top Preparation ............................6 Top Preparation - CORNELIUS ..........................6 Top Preparation - LANCER ...........................6 Install grommet ..............................6 Louvered Docking Assembly Installation ........................7 External Connections ..............................8 Air-cooled ice machines only ..........................8 Water-cooled ice machines only ..........................8 Icemaker Installation ..............................9 Slide in icemaker ..............................9 Route transport tube and thermostat ........................9 Internal Connections ..............................9 Dispenser Agitation Adjustment ..........................11 Agitation adjustments - CORNELIUS ......................
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine ➊ ➋ ➌ ➍ 7/16" 7/16" ➎ ➏ HARMONY • TOP-MOUNT Maestro Plus...
- Page 5 Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements 115 V NEMA 5-15 ➋...
- Page 6 Dispenser Top Preparation Prepare the dispenser. Note: The instructions below only apply to 22” & 30” wide dispensers. 44” wide dispenser instructions may be found with the top kit. Top Preparation - CORNELIUS Top Preparation - LANCER ➊ – — — ➋ All models Lancer models only ➊ ➊ § Remove protective tape from gaskets § Remove protective tape from gaskets ➋ ➋ § Apply gasket § Apply gasket Install grommet §...
- Page 7 Louvered Docking Assembly Installation WARNING! § Docking station must be secured in accordance with these instructions to ensure ice machine stability. § Ventilation openings in the louvered docking station should be clear of obstruction. Failure to do so could result in damage to equipment. § Plug must be accessible after final installation. sealant § Mount louvered docking assembly using four screws § Seal perimeter of docking station to mounting provided. surface. HARMONY • TOP-MOUNT Maestro Plus...
- Page 8 ➊. § Install drain line (3/4" MPT). § Install drain line The rigid drain line from the ice machine must have The rigid drain line from the ice machine must at least 1/4" per foot (6,4 mm/0,3 m) pitch. have at least 1/4" per foot (6,4 mm/0,3 m) pitch. ➋ ➋ § Install ice machine potable water supply § Install ice machine potable water supply ( 3/8" FPT) . ( 3/8" FPT) . Note: Follett recommends a Follett water filter Note: Follett recommends a Follett water filter system be installed in the ice machine inlet system be installed in the ice machine inlet water line (standard capacity #00130299, high water line (standard capacity #00130299, capacity #00978957, carbonless high capacity high capacity #00978957, carbonless high ➊ #01050442). capacity #01050442). ➌ ➍ § Connect cooling water supply and return...
- Page 9 Icemaker Installation Slide in icemaker Route transport tube and thermostat ice transport tube 1/2" bin thermostat 2" § Slide ice machine into louvered docking assembly § Lubricate transport tube with water then route ➊ transport tube and thermostat through grommet Louvered docking assembly (4.1) MCD425AxT 01034560 ➊ and into dispenser Note: Lubricating transport tube will allow entry into the grommet without the grommet being forced out of the hole/into dispenser. ➋ § Tighten clamp to secure transport tube ➌ § Route thermostat and secure in bracket Internal Connections Air-cooled ice machines –...
- Page 10 Water-cooled ice machines – follow steps 6.3.3 through 6.3.5. 6.3.3 6.3.4 Cooling Lines Potable Water and Drain Line ➊ ➋ ➊ § Connect cooling water supply and return § Insert potable water line into valve lines (supplied and connected to inside of docking § Connect drain line to barbed fitting on docking station) to ice machine. ➋ station 6.3.5 Power Cable Water Cooled Ice Tranport Tube (7.6) 01034560 MCD425AxT ➊...
- Page 11 Dispenser Agitation Adjustment - CORNELIUS Agitation adjustments Cornelius models ED, DB, DF, IDC and Flavor Fusion § Adjust the agitation tier located on the Cornelius PC board to 1 second on, 1 hour off. Note: see Cornelius manual for more information. Agitation adjustments – LANCER 4500 SERIES ROCKER SWITCHES AGITATION TIME PRESS IN ON (VIEW LOOKING PRESS IN ON THIS SIDE TO DOWN) SWITCH THIS SIDE TO...
- Page 12 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Enter Cancel Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Soda/Plain Water...
- Page 13 Dispenser diverter plate overview – CORNELIUS, ED, DF AND DB SERIES (installation on next page) Single Agitator 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) Dual Agitator 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers)
- Page 14 Dispenser diverter plate installation – CORNELIUS, ED, DF AND DB SERIES GATE MOUNTING PLATE STORAGE HOPPER FLANGE EXTENDS INTO STORAGE HOPPER THROUGH GATE OPENING ICE DIVERTER ICE CHUTE COVER APPLY RTV TO THIS SURFACE TO SEAL TO HOPPER GATE MOUNTING PLATE 10-32 WASHER GASKET ICE CHUTE...
- Page 15 Front Cover and Start Up Install front cover to ice machine. Install cover Start Up Before turning on power 1. Turn on water to ice machine. 2. Check that hose clamp securely holds ice transport tube on nozzle. After turning on power 1. Turn on power to ice machine and confirm that gearmotor, fan motor and compressor start immediately. 2. Check that ice begins to enter dispenser bin area within approximately 10 minutes. ➊ 3. Put ice against bin level thermostat in dispenser and check that compressor and gear motor shut down after thermostat opens. Fan motor should run for an additional 10 minutes.
- Page 16 Maestro Plus and Harmony are trademarks of Follett LLC. Follett, Chewblet and RIDE are registered trademarks of Follett LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01033703R02 www.follettice.com...
