- Page 1 Maestro Plus Ice Machine with RIDE Technology ™ ™ Installation Instructions for Ice Storage Bin D414AS, E414AS Order parts online www.follettice.com self-contained 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01571306R00 www.follettice.com...
- Page 2 § This appliance must not be cleaned by a water jet. § User maintence should not be done by children. § Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity).
-
Page 3: Table Of Contents
Contents Unpack ..................................4 Unpack Ice Machine ..............................4 Site Preparation ................................5 Installation site requirements ..........................5 Bin Top Preparation ..............................6 Mount thermostat box ............................6 Install shuttle actuator and bracket ........................6 Route thermostat ..............................6 Mount Ice Machine ..............................7 External Connections ..............................7 Air-cooled ice machines only ..........................7 Water-cooled ice machines only ..........................7 Bin thermostat cable ..............................8 Transport tube installation ............................9... -
Page 4: Unpack
Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack Ice Machine Bin • RIDE Technology Maestro Plus... -
Page 5: Site Preparation
Site Preparation Provide drainage, potable water supply and electrical power to within 6 feet (2m) of ice machine in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements ➊ ➋ ➌ 115 V ±5% 115 V 230 V ±10%... -
Page 6: Bin Top Preparation
Bin Top Preparation Top Preparation - Thermostat (if applicaable) 3.1.1 3.1.2 Mount thermostat box Install shuttle actuator and bracket SHUTTLE ➌ ACTUATOR ➋ ➊ THERMOSTAT GROMMET ➍ DOUBLE-SIDED TAPE THERMOSTAT BRACKET ➋ ➎ § Apply double-sided tape to bottom of thermostat box ➊... -
Page 7: Route Thermostat
3.1.3 Route thermostat SHUTTLE ACTUATOR 3/4" RADIUS (APPROX.) 2" 1" APPROX ➊ § Route thermostat through grommet and into bin ➋ § Secure thermostat in bracket Top Preparation - Shuttle Actuator (if applicaable) 3.2.1 Install shuttle actuator SHUTTLE ➋ ACTUATOR ➊... -
Page 8: Mount Ice Machine
1/4" per foot (6,4 mm/0,3 m) pitch. ➋ § Install ice machine potable water supply 3/8" FPT) Note: Follett recommends a Follett water filter system be installed in the ice machine inlet water line (standard capacity, high capacity, carbonless high capacity). -
Page 9: Bin Thermostat Cable
Bin thermostat cable (if applicable) ICE MACHINE ➋ ➊ Note: Do not apply power to ice machine bin signal connection! Ice THERMOSTAT BOX ON BIN machine can only see contact closure. § Connect 2-pin bin thermostat cable at thermostat box on bin and at front of ice machine. Bin •... -
Page 10: Transport Tube Installation
Transport tube installation Incorrect ice transport tube installation can result in wet ice and dispensing problems. Follow guidelines below to ensure correct installation. Call factory for assistance if you are unable to meet these requirements. General requirements § Maximum length of tube run – 20 ft (6 m). Factory approval required for longer runs. §... -
Page 11: Ride Model Ice Machine Start Up Procedure
RIDE model ice machine start up procedure The start-up procedure below is intended to ensure that ice machine is operating properly after installation has been made. Check each item listed and call factory immediately for assistance if you experience problems with unit. - Page 12 Maestro Plus is a trademark of Follett Products, LLC. Follett, Chewblet and RIDE are registered trademarks of Follett Products, LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01571306R00 www.follettice.com...
