SPECIFICATIONS
Ø56
78.4
184
262
MAINTENANCE
Always wipe plated area with dry soft cloth, and
sometimes wipe it with cloth soaked in mild soap.
ATTENTION
Don't use abrasive cleaning material such as;
1.
detergents containing hydrochloric acids, thinner,
polishing powder, and nylon brush.
2.
As the product model is constantly updated, the
actual product may not look the same as it
shown in the diagram, but the basic installation
principles are the same.
S06051-7N
1" WASTE W/ P – TRAP (L=262mm) TX709AV7
INSTALLATION
1.
Bolt
Cover
Packing
V - Packing
Body
2.
Plug
Nut
Packing
J - Bend
Pipe
TROUBLESHOOTING
Nut
Cover
Pipe
Seal or
solder
Packing
1. BOLT
2. NUT
3. NUT
R4
