WLS28 Pro LED Strip Light with IO-

Link Instruction Manual

Original Instructions

p/n: 220962 Rev. B

October 12, 2023

Table of Contents

Need help?

Do you have a question about the WLS28 Pro LED and is the answer not in the manual?

Questions and answers

Summary of Contents for Banner WLS28 Pro LED

Page 2: Table Of Contents
Chapter 3 Specifications FCC Part 15 Class B ....................................10 Industry Canada ICES-003(B)..................................11 Dimensions ........................................11 Photometric Data ......................................11 Chapter 4 Accessories Cordsets ........................................17 Brackets ........................................17 Chapter 5 Banner Engineering Corp Limited Warranty Mexican Importer......................................19 ...
Page 3: Chapter 1 Features
• Lensed models or choice of clear or diffuse window IMPORTANT: Read the following instructions before operating the light. Please download the complete WLS28 Pro LED Strip Light with IO-Link technical documentation, available in multiple languages, from www.bannerengineering.com for details on the proper use, applications, Warnings, and installation instructions of this device. IMPORTANT: Lea el siguiente instructivo antes de operar el luminario. Por favor descargue desde www.bannerengineering.com toda la documentación técnica de los WLS28 Pro LED Strip Light with IO-...
Page 4: Wiring Diagrams
WLS28 Pro LED Strip Light With IO-Link Instruction Manual Wiring Diagrams Male Pin Wire Color Description 1 Brown 18 V DC to 30 V DC 2 White Not used 3 Blue DC common 4 Black IO-Link Communication October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 5: Chapter 2 Io-Link Process Data Out (Master To Device)
Use process data to control entire light and select color, intensity, flash, direction, and animations. Use parameter data to create custom colors, intensity, and flash speeds. Animation Description Off Light is off Steady Color 1 is solid on at defined intensity Flash Color 1 flashes at defined speed, color intensity, and pattern (normal, strobe, three pulse, SOS, or random) Continued on page 6 October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 6 Dim and Blend Mode Dim and blend mode uses the light to finely adjust the intensity of one color, or blend between two or three colors. Use process data to set the dim and blend mode value. Use parameter data to set number of colors, range, colors, and intensities. October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 7 Percent are positioned on a band of LEDs as defined by the threshold color, intensity, flash speeds, backgrounds, band size percent width, and run mode animation types LED Mode Use process data to turn on and select a color for each individual LED. Use parameter to set global intensity. General Settings Description LED 1-64 Color Set chosen LED to off or to defined color LED Mode Intensity Defines intensity of all LEDs turned on Demo Mode Demo sequence cycles through 15 different configurations to highlight example applications. October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 8 Blank page ...
Page 9: Chapter 3 Specifications
Integral 4-pin M12 male quick-disconnect connector Environmental Rating Rated IP50 Vibration and Mechanical Shock Vibration: 10 Hz to 55 Hz, 1.0 mm peak-to-peak amplitude per IEC 60068-2-6 Shock: 15G 11 ms duration, half sine wave per IEC 60068-2-27 October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 10: Fcc Part 15 Class B
Refer to the CIE 1931 (x,y) Chromaticity Diagram to show equivalent color with indicated color coordinates. Actual coordinates may differ ± 5%. Lumen values shown apply to diffused models only. Heavy diffused models are 30% lower. October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 11: Industry Canada Ices-003(B)
Magenta: 0.204 Sky Blue: 0.367 Cool White: 1.082 Cyan: 0.449 Violet: 0.184 Green: 0.592 Amber: 0.327 Spring Green: 0.531 For models with a standard diffused window, multiply lux and candela values by an additional 0.750. Photometric data for 25° diffused lensed models is not shown. October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 16 Blank page ...
Page 17: Chapter 4 Accessories
1 = Brown 2 = White 3 = Blue 4 = Black Brackets SMBWLS28RA The bracket kit is available as a replacement for the one that comes with the light or switch. The kit contains two end brackets and four screws. Continued on page 18 October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 18 This kit allows the light or switch to be mounted to a 13/16-inch Unistrut channel. Light is shown. The kit includes: • #10-32 spring nuts (qty 2) • #10-32 socket head cap screws (qty 2) • #10 lock washers (qty 2) SMBWLSMAG Magnetic mounting bracket for easy attachment to steel surfaces SMBWLSMAGR Protective cover also available to prevent scratches to painted surfaces October 12, 2023 © Banner Engineering Corp. All rights reserved.
Page 19: Chapter 5 Banner Engineering Corp Limited Warranty
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period.
