Arborist 150 TMP CONTENTS SECTION: 1. Introduction and Purpose 2. Technical Specifications, Dimensions, Noise Level, and Lifting points 3. Safety and Symbols Ensure! Never! Always! Safety controls and switches Number not applicable 'No Stress' system Number not applicable Symbols 4. Machine Preparation Fitting TMP model to tractor Altering p.t.o. - Page 3 Arborist 150 TMP CONTENTS 6.11 Air cleaner 6.12 Electrics 6.13 Number not applicable 6.14 Number not applicable 6.15 Number not applicable 6.16 Bearings and pivots 6.17 Hydraulic connections 6.18 Mountings 6.19 Hydraulic return filter 6.20 Hydraulic Oil change 6.21 Fuses and No Stress system 6.22 Fault finding chart...
- Page 4 This manual explains the proper operation of your machine. Read these instructions thoroughly before operating and maintaining the machine. Failure to do so could result in personal injury or equipment damage. Consult your GreenMech supplier if you do not understand the instructions in this manual.
-
Page 5: Specifications
Arborist 150 TMP 2. SPECIFICATIONS Fig 2.1d Arborist 150TMP Tractor Mounted Main Features Discharge chute Reset button Control bar Chipper disc cover No-Stress display Power cable (not shown) Top Cover PTO connection Infeed chute Gearbox Hydraulic Tank 3 Point hitch... -
Page 6: Lifting Points
(Lwa) is displayed on the CE plate of each model as follows: Arborist 150 TMP - 118dB(A) – depending on tractor Minimise noise by switching to idle or stopping the tractor power take off whenever chipping is not in progress. -
Page 7: Ensure
Arborist 150 TMP 3. SAFETY 3.2.3 Operate with loose articles of clothing, including loose cuffs on gloves. 3.2.4 Work under a raised component without adequate safety support. 3.2.5 Operate the machine with untrained 3.1 ENSURE: personnel or with individuals present who 3.1.1 All Operators must be fully trained in... -
Page 8: Safety Controls And Switches
Arborist 150 TMP 3. SAFETY 3.4 Safety Controls and Switches 3.4.1 Emergency Stop/Control Bar (fig 3.4.1) Fig 3.4.1 Control Bar and Reset In the event of an emergency, push control Button bar right in to STOP feed rollers. Reset 3.4.1.1 Once the emergency has been... -
Page 9: Symbols On The Machine
Arborist 150 TMP 3. SAFETY 3.8 SYMBOLS on the MACHINE These relate to operator safety, correct use and maintenance of machine. Check that all personnel understand and are familiar with meanings before using machine. On TMP machines some symbols (e.g. engine, key, brakes) may refer to tractor controls. - Page 10 Arborist 150 TMP 3. SAFETY Important Safety Information Face shield must Caution! Beware of thrown Caution! Beware of be worn object hazard thrown object hazard Action: Stand to side of infeed chute, NOT in centre. Action: Keep away Ear defenders must...
-
Page 11: Important Safety Information
Arborist 150 TMP 3. SAFETY Important Safety Information Caution! Beware Caution! Crushing hazard! PTO Direction TMP Do NOT drive up or down slopes of more Do NOT work or than 20° park directly up or down slope. Maintenance Information Hydraulic Filler... -
Page 12: Operating Information
Arborist 150 TMP 3. SAFETY Operating Information Discharge chute control Control Bar. Left hand shown Push to stop: Centre-feed in: Pull–feed out Green is UP: Blue is DOWN ©GreenMech 04/15... -
Page 13: Machine Preparation
Arborist 150 TMP 4. MACHINE PREPARATION 4.1 Fitting TMP model to tractor 4.1.1 Check tractor p.t.o. operating speed. TMP Drive is set for 540rev/min. 4.1.2 Remove top and lower linkage pins on chipper (fig 4.1) Fig 4.1 3 Point links and PTO shaft 4.1.3 Lower three-point linkage on tractor... -
Page 14: Infeed Chute
Arborist 150 TMP 4. MACHINE PREPARATION 4.2 PTO shaft length PTO shaft must overlap by 150mm in longest situation and not bottom out in shortest situation. Always follow instructions supplied with shaft if available. Fig 4.3 Infeed chute height 4.2.1 To shorten PTO, separate each section and refit to machine. -
Page 15: Operation
Arborist 150 TMP 5. OPERATION 5.1 Pre-Work Checks: 5.1.1 Check machine is stationary, Tractor Key Fig 5.1.1 Chipper flywheel Cover in OFF position or removed, and hand brake applied. Access 5.1.2 Check that machine is level and infeed panel chute is not more than 600mm from ground (fig 3.4.3). -
Page 16: Starting Machine
Arborist 150 TMP 5. OPERATION 5.2 Starting Machine 5.2.1 Check all other personnel are clear of machine. Fig 5.2 No-Stress Control 5.2.2 Check that feed roller control bar is pushed to the FEED OUT or STOP position, to make the machine safe. -
Page 17: Blockages
Arborist 150 TMP 5. OPERATION Blockages. CAUTION! Beware sharp edges and dust. Wear protective gloves and eye shield! 5.4.1 Stop tractor engine and REMOVE key to secure place. 5.4.2 Open chipper chamber. See 5.1 Pre-work checks. Fig 5.4. Feed roller spring CAUTION! Chipped material is inflammable. -
Page 18: Preparing For Transport On Completion Of Work
Arborist 150 TMP 5. OPERATION 5.6 Preparing For Transport On Completion Of Work 5.6.1 Check chipper flywheel is stationary. 5.6.2 Remove surplus material from infeed chute and all machine surfaces. 5.6.3 Unlock, lift and secure covers to remove debris. 5.6.4 Swivel discharge chute into transport position, normally facing forward, and secure. -
Page 19: Routine Maintenance Schedule
Arborist 150 TMP 6. MAINTENANCE ROUTINE MAINTENANCE SCHEDULE CAUTION! Always remove tractor key and check for rotation before carrying out any maintenance. Note: Covers are secured closed with bolts requiring spanner. Hinge to open or remove. Replace when task is completed. - Page 20 Arborist 150 TMP 6. MAINTENANCE 6.1 Lubrication Points (see 6.14) Fig 6.1 Lubrication points Arborist 150 TMP Tractor mounted model 6.1.7 A Frame Top cover 6.1.5 6.1.4 6.1.3 6.1.6 6.1.2 6.1.1 (not shown) Grease except where stated 6.1.1 PTO shaft 2 nipples 6.1.2...
-
Page 21: Number Not Applicable
Arborist 150 TMP 6. MAINTENANCE Number not applicable. Number not applicable. Fig. 6.4 Hydraulic Oil Hydraulic Oil Dipstick/Filler/ Filter 6.4 Hydraulic Oil (if fitted) 6.4.1 Check daily (fig 6.4). If below mark check for leaks and refill to correct level. - Page 22 Arborist 150 TMP 6. MAINTENANCE 6.7 Disc Blade Cleaning - Replacement The design of blades permits relocation in at least Fig 6.7.1 Chipper flywheel Cover two rotated positions before regrinding or replacement is required. 6.7.1 Check tractor engine is switched off, and start Access key removed.
-
Page 23: Gearbox
Arborist 150 TMP 6. MAINTENANCE 6.8 Gearbox Fig 6.8 A Frame (Gearbox under) Weekly 6.8.1 Remove tractor if attached. 6.8.2 Remove A frame to reveal gearbox. Gearbox plugs under 6.8.3 Check oil level and refill as required. 1000 Hours 6.8.4 Drain and refill with clean oil. -
Page 24: Number Not Applicable
Arborist 150 TMP 6. MAINTENANCE 6.13 Number not applicable. 6.14 Number not applicable. 6.15 Number not applicable. 6.16 Bearings and Pivots weekly See paragraph 6.1 for routine lubrication. 250 hours 6.16.1 Check rotating components for excessive movement and noise in operation. -
Page 25: Hydraulic Oil Change
Arborist 150 TMP 6. MAINTENANCE 6.20 Hydraulic Oil change 1000 hours 6.21 Fuses and No Stress system 6.20.1 Remove hydraulic oil with suction A 20 amp fuse protects the No Stress pump at filter/filler and replace with new oil Power Protection System. - Page 26 (fig 4). Thread lubricant is recommended to ensure even torque. Do not use thread adhesive (e.g. Loctite). Reuse: Nord-Lock washers can normally be re-used when cleaned and re-lubricated. Nyloc nuts should always be inspected for damage before reuse. ©GreenMech 04/15...
-
Page 27: Storage
Arborist 150 TMP 7. STORAGE Storage 7.1.1 Thoroughly clean machine and note any replacement parts required. 7.1.2 Carry out 250 hour service if not already done. Refer to Section 6 7.1.3 Fit replacement parts when available. Removal from Storage 7.2.1 Carry out machine preparation as necessary Refer to Section 4 ©GreenMech... -
Page 28: Disposal
Arborist 150 TMP 8. DISPOSAL When machine is finally scrapped, the following items should be disposed of only at authorised waste disposal facilities. Gearbox oil, - Hydraulic oil. If in doubt, consult Local Authority environmental department. Major non-ferrous items such as covers and hydraulic hoses may also be disposed of separately. -
Page 29: Personal Protective Equipment (Ppe)
Safety Guides and Checklist as Safety Boots with good grip and ankle Transcribed from and Advised by support (complying with EN345-1) Arborculture & Forestry Advisory Group and Issued as Leaflet AFA604(rev1) by Non-Snag Outer Clothing appropriate to HSE, issued 04/14 prevailing weather conditions. -
Page 30: Emergency Procedures
17. Position the chipper so that operators do The PTO shaft is fitted with a suitable not have to stand on embankments/slopes guard complying with EN1152, that when feeding material into the machine encloses the shaft along its full length from tractor to machine. -
Page 31: Moving The Machine
26. Do not put any part of your body 37. Check chipping components and knives (including hands or feet), into the infeed each day for damage and wear. hopper while the machine is running. 38. Wear gloves when handling knives. 27. - Page 32 Further Reading Noise: Don’t lose your hearing! INDG363(rev2) HSE Books 2012 www.hse.gov.uk/pubns/indg363.htm First aid at work: Your questions answered Leaflet INDG2114(rev1) HSE books 2009 www.hse.gov.uk/pubns/indg214.htm Safety signs and signals. The Health and Safety (Safety Signs and Signals) Regulations 1996. Guidance on Regulations L64 (Second edition) HSE Books 2009 ISBN 978 0 7176 6359 0 www.hse.gov.uk/pubns/books/164.htm...
-
Page 33: Warranty Policy
MAINTENANCE Maintenance carried out during the warranty period should be carried out as per section 6 of the machine owner’s manual and by an authorised GreenMech dealer. ENGINES This is covered by the manufacturer of the engine. Please refer to the separate warranty conditions as supplied with the owner’s manual.
