Reolink Go Series G430+SR2
Reolink Go PT Plus is a 100% wire-free outdoor surveillance camera that runs on 4G
LTE and 3G networks. No WiFi needed. No wiring hassles. With an ultra-wide
viewing angle of 355° pan & 140° tilt, it can be a perfect security solution for large
areas warehouses, woods, etc. !
1. Specs
1
Speaker
2
6 IR LEDs
3
Status LED
4
Built-in PIR Sensor
5
Built-in Mic
6
Lens
7
Daylight Sensor
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Reolink Go G430+SR2
Summary of Contents for Reolink Go G430+SR2
- Page 1 Reolink Go Series G430+SR2 Reolink Go PT Plus is a 100% wire-free outdoor surveillance camera that runs on 4G LTE and 3G networks. No WiFi needed. No wiring hassles. With an ultra-wide viewing angle of 355° pan & 140° tilt, it can be a perfect security solution for large areas warehouses, woods, etc.
-
Page 2: Status Light
Antenna Battery Status LED Micro USB Port Power Switch Reset Hole Nano SIM Card Slot microSD Card Slot Status Light Note: If the camera connects the network successfully, there will be no status LED light up during idle mode. Status Light Camera Status Camera cannot recognize the SIM Red LED solid light up then starts to... -
Page 3: Setup And Install
Red LED solid light up then flash Data call failed or requires to input quickly about 3 times in 1s the APN. Red LED solid light up then blue LED Network connection failed. starts to flash and goes off completely Red LED solid light up then blue LED Network connection succeed. - Page 4 Notes: Some SIM cards have a PIN code, please use your smartphone to disable the PIN first. Do not insert the IoT or M2M SIM card into your smartphone. Install the SIM Card 1. Rotate the camera lens, and remove the rubber cover. 2.
- Page 5 3. With these done, press the rubber cover firmly for better waterproof performance. Notes: • The SIM card slot is above the SD card slot. When inserting the SIM card in, remember that the gold contacts shall face down and you need to push the trimmed corner inside the camera.
- Page 6 3. A blue LED will flash for a few seconds and then go solid before going out. You will hear a voice prompt "Network connection succeeded”, which means the camera has been successfully connected to the network. Note: You may also run into the following situations: Voice Prompts Camera Status Solutions...
- Page 7 APN 2. Import the correct APN correct. settings” settings to the camera. Set up the Camera on the App Please follow the steps below to do initial setup for the battery-powered cameras via Reolink App.
- Page 8 Step 1. Tap the icon in the top right corner to add the camera. Step 2. Scan the QR code on the back of the camera. If the phone doesn't respond, please tap Input UID/IP below the scan window, and then enter the 16-digit UID number under the QR code of the camera.
- Page 9 Step 4. Select a scene according to the place where your camera will be installed. Then tap Next. Step 5. Read the note and then tap Finish to complete the initialization of your camera.
- Page 10 Now the initialization is finished and you can move it to the position you want. Here is an article to choose a good position for the camera. Install the Camera We offer you guides on three different scenes in which the camera could be installed.
- Page 11 Note: In order to get a better network connection, it is recommended to install the antenna upward or horizontally. Step 3. Screw the camera to the security mount and adjust to the proper direction. Mount the Camera to the Ceiling Step 1.
- Page 12 Install the Camera with Loop Strap You are allowed to strap the camera to a tree with both the security mount and ceiling bracket. Thread the provided strap through the slots of the plate and fasten it to a tree. Next, attach the camera to the plate as you have done in the previous two methods.
-
Page 13: Physical Parameters
Step 1. Please choose a location for your solar panel that gets the most sunlight throughout the year. The Reolink solar panel needs only a few hours of direct sunlight to sufficiently power up your camera daily. The amount of energy that the solar panel can produce is affected by weather conditions, seasonal changes, geographic locations, etc. - Page 14 Step 2. Mount the bracket with the mounting template and the screws provided in the package. Step 3. Slot the solar panel into the bracket and make sure it's secure.
- Page 15 Step 4. Loosen the adjustment knob on the bracket, and adjust the angle of the solar panel to receive the most direct sunlight. Then re-tighten the adjustment knob to secure the panel. Step 5. Connect the solar panel to the camera with the micro USB cable Notes: Make sure the solar panel is not blocked.
- Page 16 solar panel might accumulate dust and other debris easily. It’s advised to install the solar panel angularly to receive the most direct sunlight. Wipe the solar panel regularly to remove dust or debris. Please charge the batteries in temperature between 0°C and 45°C (32-113°F). ...
