OneAccess 1424 Installation Manual page 29

1424 SHDSL Router
User manual
2.6.2 The different parts of the 1424 SHDSL Router
The following table gives an overview of the possible connectors located at the back of the 1424 SHDSL
Router and explains their function:
Interface identi- Interface function
fication
LINE This RJ45 connector is the SHDSL line connector.
Connect one side of an SHDSL line cable to the LINE connector of the 1424
SHDSL Router and the other side to an SHDSL outlet.
Refer to
nector.
CONSOLE This RJ45 connector is a V.24 DTE interface. This enables you to manage the
1424 SHDSL Router locally. For more information, refer to
ifications on page
USB This is a USB version 2.0 interface and can operate as a master. It can deliver up
to 500mA at 5V. It can be used to connect a mobile USB device for backup of the
DSL connection over the mobile 3G network.
LAN1 These RJ45 connectors are the Ethernet LAN connectors. There are 4+1 Ethernet
LAN connectors on the 1424 SHDSL Router.
LAN2
The separate Ethernet interface can be used as main WAN link or as a back-up
WAN link interface. The Ethernet switch is VLAN manageable.
Connect one side of an Ethernet LAN cable to the LAN connector of the 1424
SHDSL Router and the other side to an Ethernet network outlet. Each LAN inter-
face supports 10/100 Mbps auto-sense and auto cross-over.
Refer to
LAN2 interface specifications on page 38
12VDC-1A This is the power input. Insert the plug of the external power supply in this socket.
Secure the power supply connection by installing the DC power supply cord into
or
the holding clip provided on the back panel.
12V-1,5A
Refer to
1424 SHDSL Router.
This is the earth stud. Connect it to a reliable earth by means of a yellow-green
wire of at least 1,5mm².
Refer to
Contact the appropriate electrical inspection authority or an electrician if you are
uncertain that suitable earth is available.
• The back panel may be slightly different on specific versions of the 1424 SHDSL Router.
For optimum performance, the used line pairs have to be properly twisted.
5.1 - SHDSL line specifications on page 35
40.
5.2 - LAN1 4 port Ethernet switch specifications on page 37
5.7 - Power requirements on page 42
2.6.3 - Earth connection on page 22
Installing and connecting the 1424 SHDSL Router
for the pin lay-out of this con-
for the pin lay-out of this connector.
for the power specifications of the
for more information.
Chapter 2
5.5 - Console port spec-
and 5.3 -
21
