Operating Instructions & Parts Manual
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Fast Lift Service Jack,
Made by
SFA Companies, Kansas City, MO
U.S. Patent No's. 6,199,379 • 5,946,912
!
WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use an identical pair of
adequately rated jack stands.
Model
BH6023B
10939 N. Pomona Ave. Kansas City, MO 64153
sales@blackhawk-automotive.com
Low Profile
Capacity
SFA Companies
BH6023B-M0_082018
2 Ton
Advertisement
Table of Contents
Related Manuals for Blackhawk Automotive BH6023B
Summary of Contents for Blackhawk Automotive BH6023B
- Page 1 Fast Lift Service Jack, Low Profile Blackhawk Automotive is a Licensed Trade Mark Made by SFA Companies, Kansas City, MO Operating Instructions & Parts Manual Model Capacity BH6023B 2 Ton U.S. Patent No’s. 6,199,379 • 5,946,912 This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Safety And General Information
SAFETY AND GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this device before using. The owner and/or operator shall have an understanding of the device, its operating characteristics and safety operating instructions before operating the equipment. The owner and/or operator shall be aware that use and repair of this product may require special skills and knowledge. -
Page 3: Specifications
SPECIFICATIONS Model Capacity Jack Size (L x W x H) Min. Height Max. Height BH6023B 2 Ton 42-1/2" x 13-3/4" x 7" 2-1/2" 20" PREPARATION ssembly 1. Assemble the two-piece handle with provided bolt. -
Page 4: Operation
OPERATION Lifting 1. Follow the vehicle manufacturer’s recommended guidelines for lifting. Engage the emergency brake and chock each unlifted wheel in both directions to prevent inadvertent vehicle movement. 2. Close the release valve by turning the handle clockwise until firm resistance is felt. 3. -
Page 5: Troubleshooting
TROUBLESHOOTING Symptom Possible Causes Corrective Action Jack will not lift load • Release valve not tightly closed • Ensure release valve tightly closed • Load is too heavy • Consider higher capacity jack Jack will lift, but not maintain • Ensure release valve tightly closed •... -
Page 6: Replacement Parts
When ordering parts, please give the Model number, part number and parts description. Call or write for current pricing: SFA Companies, 10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A. Tel:(888)332-6419 Fax:(816)891-6599 E-Mail: sales@blackhawk-automotive.com Figure 2 - Replacement Parts Illustration for Model BH6023B... - Page 7 Lock Washer G880-20006-000 Bearing Bushing G489-40006-0000 Handle Bolt 1305-00016-031 G735-40003-0410 Handle Base Pin Seal Kit QG86308-K00 G735-40005-0410 Roller (includes a thru q) BH6023B-M0 Manual 1433-00012-204 Snap Ring BH6023B-L0 Label Hydraulic Unit G880-20010-0410 Attachment Screw **Repair Kit Contents: Item Description Item...
-
Page 8: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer’s exclusive remedy.
