EntryEase Reference
Cover _
Resend button: When ki III
pressed the door will stop if I !"," 'ii
moving up or reverse if \ I _ 'Till
rnovingdown•
X ....2//I
/
Send LED (yellow): Lit\ I *,' // I /
after a passed fingerprint \ I t , i i I/
sianaddil.td_Cnates_at ethe _L_ _ /
and can be used to stop _
I 1
/
or reverse door travel. --_ _l,,d
Pass LED (green): Lit when
_
I
a scanned fingerprint _'oy _1 i q *_'_
matches a stored print. __._
Ready LED (green): Lit
Sensor Strip
when unit is ready to scan
fingerprint.
Enroll button: When
pressed the unit will go
into Enroll mode.
Enroll LED (yellow):
Lit when the unit is in
Enroll mode•
Fail LED (red): Lit when
a scanned fingerprint
does not match a
stored print•
Retry LED (yellow): Lit
when another swipe is
required•
Step 3 Enroll Additional User(s)
NOTE: The device can store up to four fingerprints at a time.
An enrolled user must swipe finger first to enroll new user.
1. Open cover and wait until Ready LED
is lit.
2. Press and hold Enroll button until
Enroll LED starts to flash.
3. While the Enroll LED is flashing an
enrolled user must slowly and firmly
swipe finger.
Extra directions are located
on the inside of cover•
!:.@::_io£:i_}.iTo :-
_o_1.
i g_f_::4': ................
Step 2 Enroll Initial User
NOTE: The unit requires 3 passed swipes to enroll a user.
1. Open cover to turn unit on. Wait until
Enroll LED and Ready LED are lit (not
flashing).
4. The Enroll LED and Ready LED will
light when ready for new user to
swipe finger.
5. New user should swipe finger slowly
and firmly down the sensor strip until
three passed swipes are made.
6. The Enroll LED and Pass LED will
flash when new user is enrolled. Unit
will return to Ready mode.
2. Swipe finger slowly and firmly down
the sensor strip until three passed
swipes are made.
NOTE: The Pass LED will light for a
passed swipe. The Retry LED will light
if another swipe is needed. Swipe slowly
and with more pressure if this occurs.
NOTE: If cover is already open, press either the Resend or the
Enroll button to turn un# on. The Pass LED will light for a
passed swipe. The Retry LED will light if another swipe is
needed.
3. After the third passed swipe, the Enroll
and Pass LED will flash. Enrollment is
complete.
NOTE: If cover is already open, press either the Resend or the
Enroll button to turn unit on. If the Ready LED is lit refer to
Factory Reset in the Erase/Reset section.
