GUIDELINES
FOR UNIT
INSTALLATION
These guidelines are recommended by
MAAX Aker for the proper installation of
their product. A careful review of these
procedures (and any referenced
publications) before starting is impor-
tant in avoiding unnecessary problems
resulting in an improper assembly or
installation.
NOTE: All drawings in this publication
are typical, and may appear different
than the actual items being installed. In
addition, optional items may be shown
on the units which may not have been
ordered on the unit being installed.
ON WHIRLPOOL EQUIPPED MODELS,
A SEPARATE SET OF INSTRUCTIONS
IS PACKED WITH THE UNIT FOR THE
WHIRLPOOL SYSTEM. READ THEM
BEFORE INSTALLING UNIT!
WARNING!
NEVER LIFT OR HANDLE WHIRLPOOL
BY SYSTEM PIPING AT ANY TIME.
LIFTING THE UNIT BY THE PIPING CAN
CAUSE SYSTEM DAMAGE.
Bodyfit ACCT-6060
Bodyfit CT-6060
ACC2-6060
CT2-6060
Special Notes to Installer
It is the sole responsibility of the
installer to determine, prior to the
installation, the requirements necessary
for compliance with all codes involving
the unit or the installation!
All paperwork packaged with the unit
and any associated options or accesso-
ries should be saved and presented to
the homeowner upon completion of
the installation!
HANDLE THE UNIT BY THE SHELL ONLY!
Never lift any unit by attachments or
piping on the shell.
All published unit dimensions are for
reference only. Any critical dimensions
required for installation should be taken
directly from the unit being installed!
Any independent changes made to
the unit (or to any options and accesso-
ries supplied with the unit) beyond
those required for normal installation
can void all warranties! (Refer to
warranties for further information.)
Self-Rimming Bath Modules
Bodyfit ACCT-6060
Bodyfit CT-6060
Inspection Guidelines
A careful check of the unit should be
conducted upon receipt. Notify your
supplier immediately if any questions or
problems are encountered during this
process.
DO NOT INSTALL ANY UNIT
WITHOUT FIRST ADDRESSING
QUESTIONS WHICH ARISE DURING
THE INSPECTION!
Basic Module Check
Check for unit surface damage.
Check unit color for coordination to
other bathroom fixtures.
Check for proper options and acces-
sories.
Whirlpool and Accessories Check
An individual system check list is in-
cluded in the assembly and operational
guidelines packaged with whirlpool
equipped models and various accesso-
ries. Refer to the listed publications for
further information before continuing.
ACC2-6060
CT2-6060
