Freestanding Bathtub • Baignoire podium • Bañera en podió
Read all instructions carefully before proceeding.
Lire toutes les instructions attentivement avant de commencer
l'installation.
Leer detenidamente todas las instrucciones antes de comenzar
la instalación.
important
• Record the serial number
important
• Noter le numéro de série
importante
• Registre el número de serie
iNstaLLatioN iNstRuctioNs
Guide d'iNstaLLatioN
Guía paRa iNstaLacióN
®
origin
Save thiS guide for future reference.
conServer pour un uSage ultérieur.
conServe eSte manual como referencia.
Serial number • Numéro de série • Número de Serie

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Origin and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MAAX Origin

Summary of Contents for MAAX Origin

  • Page 1 Guide d’iNstaLLatioN Guía paRa iNstaLacióN Freestanding Bathtub • Baignoire podium • Bañera en podió ® origin Read all instructions carefully before proceeding. Save thiS guide for future reference. conServer pour un uSage ultérieur. Lire toutes les instructions attentivement avant de commencer l’installation.

  • Page 2: Table Of Contents

    être libremente sobre ellas; está diseñada sólo Origin support only. installées sur le support Origin seulement. para instalarla sobre el soporte Origin. atteNtioN atteNtioN adveRteNci...

  • Page 3: Identification Of Components

    Origin Série 25 premiers PART No / No DE Ó I PIÈCE / No DE QTÉ PARTE CANT f l e t e l t i o o l l...

  • Page 4: Preparation

    pRepaRatioN Determine the final position of the bathtub. Spread out on the floor the leg positioning template (make sure that the layout allows for the piping, valving and drain). Make sure to leave the necessary space at the back of the bathtub for the shelf and Fig.

  • Page 5: Ixing The Legs

    FixiNG tHe LeGs For a wooden floor: Using male leg (12) positioned on one of the circles in the corners, punch into the floor Template Fig. two opposing holes per circle for the 4 corners Gabarit Gálibo . If the floor is ceramic tile, drill the tile only (1/2" in depth maximum) through the male legholes using a 3/16"...

  • Page 6: Ssembly And Installation Of

    asseMBLy aNd iNstaLLatioN oF woodeN suppoRt From the main packaging, remove the rectangular box Fig. 5 containing the wood support. Lay the central support (4) on the left and right supports. Fig. 6 . Note: Check the assembly orientation of the central support (the central support is not symmetric);...

  • Page 7: Ssembly Of Bathtub

    asseMBLy oF BatHtuB Slip spacers (9) into the metal legs (14) under the bathtub. Screw nuts (6) on the metal legs (14) to keep spacers (9) adequately positioned. Note: Adjust nut (6) and spacers Fig. 8b (9) height according to the leg edge. Place the bathtub gently onto the base.

  • Page 8: Rain And Overflow Connections And Final Installation

    dRaiN aNd oveRFLow coNNectioNs aNd FiNaL iNstaLLatioN Slip the flange on the tail piece supported on the ground. Install the plumbing, the overflow and the bathtub drain according to assembly instructions. Take care to properly locate the accessories to obtain a 90­degree Fig.

  • Page 9: Maintenance

    MAAX, qui con un representante de MAAX, que le propondrá la questions and recommend the best solutions. proposera la meilleure solution selon la circonstance. mejor solución, según las circunstancias. GaRaNtie LiMitée GaRaNtía LiMitada...
  • Page 10 MAAX can execute the warranty produit tel que le décrit le guide d’installation afin el manual de instalación, con el fin de que MAAX specified herein. If such access is not available, que MAAX puisse exécuter la garantie spécifiée pueda cumplir con la garantía que se indica en...
  • Page 11 HERSEY, US TESTING, NAHB. HERSEY, US TESTING, NAHB. (ETL), WARNOCK HERSEY, US TESTING, NAHB. MAAX ORIGIN are registered trademarks of MAAX Bath Inc. / sont des marques de commerces déposées de MAAX Bath Inc. / son marcas registradas de MAAX Bath Inc.
  • Page 12 • service technique • servicio técnico canada united states T. 1 888 957­7816 T. 1 800 328­2531 F. 1 800 201­8308 F. 1 800 944­9808 10011414 © MAAX Bath Inc., 2008 Printed in Canada • Imprimé au Canada • Impreso en Canadá 2012­06­12...
