PEERLESS WSP 716-GS Assembly Instructions

External wall plate

Advertisement

Quick Links

Assembly Instructions - External Wall Plate
IMPORTANT!
Read entire instruction sheet
before you start installation and assembly.
WARNING
• Wall or mounting structure must be capable of sup-
porting a minimum static load of 600 lb (272 kg).
PARTS LIST
PART #
QTY.
A 024-P1043
1
024-P1042
B 510-9108
10
C 520-9521
12
D 560-9708
12
E 540-1063
22
THIS
END UP
WSP 724-GB,
WSP 724-GS
MAXIMUM LOAD CAPACITY:
200 lb (91 kg)
DESCRIPTION
wall plate 16" centers
wall plate 24" centers
1/4-20 x 1/2" phillips screw
1/4-20 x 2 1/2" phillips screw
toggler
washer
C
E
B
Cable Management Ports
A
Note: Wall plate may
appear slightly different
than illustrated.
Models:
WSP 724-GS, WSP 724-GB
WSP 716-GS, and WSP 716-GB for studs on 16" (406 mm)
centers, contains four cable management ports.
WSP 724-GS, and WSP 724-GB for studs on 16", 20" and 24"
(406 mm, 508 mm, 610 mm) centers, contains four cable
management ports.
PART #
A 024-C4043
024-C4042
B 520-9511
C 520-9522
D 560-9708
E 540-2056
WSP 716-GB,
WSP 716-GS
1 of 4
ISSUED: 01-23-07 SHEET #: 024-9011-1
WSP 716-GS, WSP 716-GB,
PARTS LIST
QTY.
DESCRIPTION
1
wall plate 16" centers
wall plate 24" centers
10
1/4-20 x 1/2" phillips screw
12
1/4-20 x 2 1/2" phillips screw
12
toggler
22
washer
D
*Note: The mounting hole which
is closest to the lip of the plate
indicates the up position.
*
THIS
END UP
