Jetinno JL500I Maintenance Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
JL500I
Maintenance Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the JL500I and is the answer not in the manual?

Questions and answers

Related Manuals for Jetinno JL500I

Summary of Contents for Jetinno JL500I

  • Page 1 JL500I Maintenance Manual...

  • Page 2: Warranty

    MATERIAL CODE NAME CHANGE GUIDE CHANGE FREQUENCY WARRANTY SPARE SUGGESTION/100PCS MACHINES 3111084000 20g Brewer Page 1 Failure 1 year 3111055300 Brewer drive Page 1 Failure 1 year 5111067000 Outlet pipe Page 1 Failure 1 year 5112051200 Brewer upper strainer Page 2-4 Failure 1 year 5112051300...
  • Page 3 MATERIAL CODE NAME CHANGE GUIDE CHANGE FREQUENCY WARRANTY SPARE SUGGESTION/100PCS MACHINES 3121050100C Mixer drive (single inlet) Page 11 Failure 1 year 5402090800B Mixer motor Page 11 Failure 1 year 5121053200A Piston_filter Page 11 Failure 1 year 5206051200A O sealing ring - INDIA6XWireDia1.5 Page 12 Failure 1 year...
  • Page 4 MATERIAL CODE NAME CHANGE GUIDE CHANGE FREQUENCY WARRANTY SPARE SUGGESTION/100PCS MACHINES 3405051000A Non-return valve Page 23 Failure 1 year 3405050600B Safety valve Page 24 Failure 1 year 3121050500C Water tank group Page 25 Failure 1 year 5121053400A Water tank Page 25 Failure 1 year 5121053500B...
  • Page 5 MATERIAL CODE NAME CHANGE GUIDE CHANGE FREQUENCY WARRANTY SPARE SUGGESTION/100PCS MACHINES 3201050700B Silicone tube connector Page 45 Failure 1 year 3201051600A 6mm L connector (white) Page 41-43 Failure 1 year 3201051400A 6mm T connector (white AVS) Page 40 Failure 1 year 3201051300A 6mm T connector (cold water) Page 40...
  • Page 6 MATERIAL CODE NAME CHANGE GUIDE CHANGE FREQUENCY WARRANTY SPARE SUGGESTION/100PCS MACHINES 5406051800A Leakage switch Page 60 Failure 1 year 3313063600A LED light Page 61 Failure 1 year 3401052400A Motor (BO26) Page 62 Failure 1 year 3401050400C 86132 Motor Page 63 Failure 1 year 3313052000A...
  • Page 7 20g brewer and brewer drive replacement manual 2. Pull the movable buckle outward and remove the brewer with downward pressure 1. Turn off the machine, unplug PTC connector, remove the brewer inlet and outlet pipes INLET: press the end face of the white quick joint by the 3.
  • Page 8 Outlet pipe, Brewer upper/lower strainers, O ring replacement manual - 1 1. Swipe the RFID card, or long click on the top left corner of the screen, enter the password when the dialog box appears: jn9527 2. Access to the machine management system, click on the bottom right corner of the screen [Settings]->[ES Brewer]->[ES Brewer 1]->[ES Action Control]- >[Dosage];...
  • Page 9 Outlet pipe, Brewer upper/lower strainers, O ring replacement manual - 2 3. Unplug the PTC connector; Rotate the coffee spout outward and pull down vertically to remove the spout 4. Press the end face of the white quick joint by the finger, and make sure the elastic space has been compressed, then unplug the pipe with force 5.
  • Page 10 Outlet pipe, Brewer upper/lower strainers, O ring replacement manual - 3 7. Remove the screws from the center part of the upper/lower strainers and take the strainers out. 8. Check whether the mesh is blocked, if it is, please take out a new one to replace it 9.
  • Page 11 Coffee grounds funnel replacement manual 1. Open the machine door and find the 2. Pull the movable buckle outward and 3. Remove the coffee grounds funnel, coffee grounds funnel tilt the brewer forward which can be replaced for cleaning Note: When putting the brewer back on, make sure it is pushed to the bottom and the buckle is snapped on. Can pull the brewer forward and it will not fall up to prove it is locked.
  • Page 12 ES_BREWER_PCBA V1.4 circuit board replacement manual - 1 2. Pull the movable buckle outward and remove the brewer with downward pressure 1. Turn off the machine, unplug PTC connector, remove the brewer inlet and outlet pipes INLET: press the end face of the white quick joint by the 3.
  • Page 13 ES_BREWER_PCBA V1.4 circuit board replacement manual - 2 5. Remove the sheet metal fixing screws on both 6. Unplug the two motor power connectors, sides of the drive module. Separate the remove the ES-Brewer board and replace it. top/bottom part of the drive.
  • Page 14 EK7 grinder, Bean detected sensors (send/receive) replacement manual Turn off the machine and unplug the power supply. Open machine door, push the plate under the bean hopper inward to the bottom. Lift the bean hopper upward and outward, then can remove it Long Phillips screwdriver to remove the left/right fixing screws of the grinder module;...
  • Page 15 Bean hopper, Instant canister, Powder nozzle, Insect-proof cover/base replacement manual 1. Access to machine Double- management system, click wheel Wheel- on [Open Machine Door] 2. Remove insect-proof Single- less and open it. push the plate cover wheel under the bean hopper Straight Right inward to the bottom.
  • Page 16 Canister motor shaft, Motor replacement manual 1. Access to machine management system, click 2. Wrap the canister motor shaft with a towel 3. Unplug the canister motor connector, use a on [Open Machine Door], open it and remove and pull it outward to remove. Remove the Phillips screwdriver to remove the motor to be replaced and replace it with a new one.
  • Page 17 Mixer drive group, Mixer motor disassembly manual Remove the screws, take off the cover plate and 3. Unplug the canister Access to machine motor connector the sheet metal parts. management system, click on [Open Machine Door], open it and remove six canisters.
  • Page 18 V/O sealing rings replacement manual 2. Check the O sealing ring, if damaged, find the corresponding new one to replace 1. Remove the canister and 4. Remove and check the V sealing silicone tube, pinch the handle ring, if damaged, find the of the fixing ring, rotate corresponding new one to 3.
  • Page 19 Mixer group, Mixer, Fixed ring, Cover, Inlet plug replacement manual 2. Mixer group contains the mixer body, the fixed ring, the cover and the inlet plug, can be removed and replaced 。 Mixer inlet MIXER COVER MIXER BODY plug 1. Remove the canister and silicone tube, INLET PLUG MIXER GROUP pinch the handle of the fixing ring,...
  • Page 20 Mixer insect-proof sponge replacement manual INSECT-PROOF SPONGE STEAM INLET TOP COVER STEAM OUTLET BOTTOM COVER 1. Remove the canister and silicone tube, 3. Separate the steam inlet top/bottom 2. Pull outward the steam inlet pinch the handle of the fixing ring, cover, take out the insect-proof sponge top/bottom cover rotate counterclockwise, pull outward...
  • Page 21 Channel bellows replacement manual 1. Access to machine management system, click on [Open Machine Door], open it and 2. Unplug the motor shaft of the corresponding remove six canisters. Turn off the leakage canister to be replaced. Remove the screws, take 3.
  • Page 22 Fan replacement manual - 1 2. Remove the screws, take off 1. Access to machine the cover plate and the management system, sheet metal parts. click on [Open Machine Door], open and remove six canisters. Turn off the leakage protection switch.
  • Page 23 Fan replacement manual - 2 7. Use an M7 wrench 8. Use an M7 wrench 6. Pull out the fixed sheet metal box of the to remove the to remove the lower bellows in the direction of the arrow. upper nut used to nut used to fix the fix the fan fan, then take out...
  • Page 24 Waste bin replacement manual Waste bin Waste bin 6L (deeper) Waste bin 18L 1. Access to machine management system, take out the waste bin(s), clean with a brush and rag or replace it.
  • Page 25 Gear pump replacement manual 1. Access to machine management system, 3. Unplug gear pump open machine door, turn off the power. power cable. Remove the four screws on the back and 2. Open machine door, remove Break the gear remove the cover plate the boiler group fixing screws pump sheet metal above the water cooler...
  • Page 26 2P/3W valve replacement manual CAUTION: PTC heater, high surface temperature, beware of burns. Access to machine management system, open machine door. Find the 2P/3W valve behind the brewer, cut the tie, unplug the silicone tube and the two white pipes, remove the screws, and unplug the valve power cable, then can replace the 2P/3W valve.
  • Page 27 4-way valve (24MA2V) replacement manual 2. Remove the screws, take off the cover plate and 1. Access to machine the sheet metal parts. management system, click on [Open Machine Door], open and remove six canisters. Turn off the leakage protection switch. 4.
  • Page 28 Flowmeter sensor replacement manual 1. Access to machine management 2. Open machine door, remove the boiler system, open machine door: Machine 5. Unplug the flow group fixing screws above the water meter connection Test – Operation - Empty Air Break. cooler 3.
  • Page 29 Non-return valve replacement manual 1. Access to machine management 2. Open machine door, remove the system, open machine door, boiler group fixing screws above turn off the power. Remove the the water cooler four screws on the back and remove the cover plate 3.
  • Page 30 Safety valve replacement manual 1. Access to machine management 2. Open machine door, remove the system, open machine door, turn boiler group fixing screws above off the power. Remove the four the water cooler screws on the back and remove the cover plate 4.
  • Page 31 Water tank group, Water tank, Cover, Float switch replacement manual 1. Access to machine management system and empty the air break: Machine Test – Operation - 3. Remove the screws and remove the cover plate Empty Air Break 2. Click on [Open Machine Door]，...
  • Page 32 Inlet solenoid valve replacement manual 2. Remove the screws, take off the cover plate and the sheet metal parts. 1. Access to machine management system, click on [Open Machine Door], open and remove six canisters. Turn off the leakage protection switch. 4.
  • Page 33 Boiler group replacement manual - 1 6. Unplug 3. Unplug 1. Access to machine management system, boiler flowmeter open machine door, turn off the power. outlet connection Remove the four screws on the back and pipe wire 2. Open machine door, remove the 7.
  • Page 34 Boiler group replacement manual - 2 11. Unplug the boiler wastewater pipe, then 10. Unplug water can remove the boiler cooler inlet pipe group and replace it...
  • Page 35 Boiler replacement manual - 1 6. Unplug 3. Unplug 1. Access to machine management system, boiler flowmeter open machine door, turn off the power. outlet connection Remove the four screws on the back and pipe wire 7. Unplug remove the cover plate 2.
  • Page 36 Boiler replacement manual - 2 11. Unplug the boiler wastewater pipe, then 10. Unplug water can remove the boiler cooler inlet pipe group and replace it...
  • Page 37 Boiler replacement manual - 3 12. Cut the tie, remove the DPS boiler insulation left cover, remove the quick joint and take out the boiler. Remove the STB connection cable, thermostat, pressure sensor, and temperature sensor, install them on the new boiler, and reset the parts...
  • Page 38 Thermostat (PBR380V-120) replacement manual 1. Access to machine management system, open machine door, turn off the power. 3. Unplug the Remove the four screws on the back and connector of remove the cover plate the thermostat 2. Open machine door, remove the boiler group fixing screws above the water cooler 4.
  • Page 39 Pressure sensor replacement manual 1. Access to machine management system, open machine door, turn off the power. Unplug the Remove the four screws on the back and pressure sensor 2. Open machine door, remove the remove the cover plate connection wire boiler group fixing screws above the water cooler Remove the pressure sensor...
  • Page 40 Temperature sensor replacement manual 1. Access to machine management system, CAUTION: Boiler high open machine door, turn off the power. surface temperature, Unplug beware of burns. Remove the four screws on the back temperature 2. Open machine door, remove the and remove the cover plate sensor boiler group fixing screws above...
  • Page 41 STB connector replacement manual 1. Access to machine management system, open machine door, turn off the power. Remove the four screws on the back and 2. Open machine door, remove the remove the cover plate boiler group fixing screws above the water cooler 3.
  • Page 42 Cam, Cup dispenser connecting rod, Turning gear, Drive pinion, Cup lid dispenser group replacement manual Access machine management Remove the screws system, click [Open Machine Door]. cup barrel and cup holder group turning gear Remove cup barrel; turn off the slotted (with automatic cup switch...
  • Page 43 Adjustable cup-holder group replacement manual 2. Change screw position to adjust height. 1. Access to machine management system, open cup door. Hold the bottom of cup-holder and pull it with force to the right, then can clean or replace it...
  • Page 44 6mm I D6 G1/8 connector & 4mm I D4 G1/8 connector replacement manual 6mm I D6 G1/8 connector 4mm I D4 G1/8 CAUTION: PTC heater, high surface temperature, connector beware of burns. 1. Access to machine management system, open machine door. Find 2P/3W valve behind the brewer, cut the tie, unplug the silicone tube and two white pipes, remove the nut.
  • Page 45 Internal thread D6 G1/8 connector replacement manual 1. Access to machine management system, open machine door, turn off the power. Remove the four screws on the back and 2. Open machine door, remove the remove the cover plate boiler group fixing screws above the water cooler 3.
  • Page 46 6mm T connector (cold water), 6mm T connector (white AVS) replacement manual Access to machine management 6mm L connector system, open machine door, turn (white) off the power. Remove the four Open machine door, remove the screws on the back and remove boiler group fixing screws above the cover plate 6mm T connector...
  • Page 47 6mm L connector (white) replacement manual - 1 3. Unplug 6. Unplug 1. Access to machine management system, flowmeter boiler open machine door, turn off the power. connection outlet Remove the four screws on the back and wire pipe 7. Unplug remove the cover plate 2.
  • Page 48 6mm L connector (white) replacement manual - 2 11. Unplug the boiler wastewater pipe, then 10. Unplug water can remove the boiler cooler inlet pipe group and replace it...
  • Page 49 6mm L connector (white) replacement manual - 3 6mm L connector (white) 12. Cut the tie, remove the DPS boiler insulation left cover, take out the blue snap and remove the connector, then can replace it...
  • Page 50 6mm L G1/8 connector (thread-white) replacement manual Access to machine management system, open machine door, turn off the power. Remove the four Open machine door, remove the screws on the back and remove boiler group fixing screws above the cover plate the water cooler 6mm L G1/8 connector...
  • Page 51 Silicone tube connector replacement manual 1. Access to machine management system, open machine door, turn off the power. silicone tube connector Remove the four screws on the back and 2. Open machine door, remove the remove the cover plate boiler group fixing screws above the water cooler 3.
  • Page 52 Inlet valve connector replacement manual 1. Inlet connector is connected to the inlet solenoid valve and connects to the water pump inlet interface 2. Inlet connector is connected to the inlet solenoid valve of the water cooler. Remove the blue snap, unplug the connector, then can replace it...
  • Page 53 27” Touch/Display screen replacement manual 1. Power off, remove the screws and the cover plate. Unplug the internal USB extension cable when take out the cover. 2. Unplug all connections on the board and at the POST light. Remove the screws and nuts.
  • Page 54 Water pump replacement manual Access to machine management system, click [Open Machine 3. Remove the four screws. Door]. Turn off the Remove the water pump and machine, Unplug the water pump power and replace it with a new one signal connection cable 2.
  • Page 55 Water cooler replacement manual Empty the air break, unplug the water cooler power cord and the cold water inlet valve connector. Rotate the connector counterclockwise until it is removed. Unplug the 2. Remove the 2 nuts and pull out the fixed 1.
  • Page 56 CUP BOARD_V1.3.3 (standard) replacement manual ATTENTION: Take pictures before unplugging to avoid insert the wrong place Remove 4 when resetting screws for board replacement 1. Turn off the machine, remove the screws and the cover plate. Unplug the internal USB extension cable when take out the cover.
  • Page 57 A83T_STUM_V3.4 (circuit board) replacement manual 3. Cannot be connected 1. Turn off the machine, backwards, otherwise the ATTENTION: remove the screws display will be short-circuited. Take pictures before and the cover plate. unplugging to avoid insert the wrong place when resetting 4.
  • Page 58 I/O CTRL BOARD V1.0.7 (circuit board) replacement manual 2. Take pictures before unplugging to avoid insert the wrong place when resetting. Unplug all connections on the I/O board 1. Access to machine management system, click on [Open Machine Door], open it and 3.
  • Page 59 RFID_BOARD_V1.3.1 (circuit board) replacement manual 1. Power off, remove the screws and the cover plate. Unplug the ATTENTION: internal USB extension cable Take pictures before when take out the cover. unplugging to avoid insert the wrong place 3. Remove 4 when resetting screws for board...
  • Page 60 Screen inverter replacement manual ATTENTION: Take pictures before unplugging to avoid 1. Power off, remove the screws insert the wrong place and the cover plate. Unplug the when resetting internal USB extension cable when take out the cover. 2. Unplug the connection cable on screen inverter.
  • Page 61 Touch_Key_V1.1 (circuit board) replacement manual ATTENTION: Take pictures before unplugging to avoid insert the wrong place 1. Power off, remove the screws when resetting and the cover plate. Unplug the internal USB extension cable when take out the cover. 2. Unplug the connection cable on the touch display board...
  • Page 62 RELAY_BOARD-V1.4.2 (circuit board) replacement manual 2. Take pictures before unplugging to avoid insert the wrong place when resetting. Unplug all connections on the relay board 1. Access to machine management system, click on [Open Machine Door], open it and 3. Remove 4 screws on the relay board for board remove six canisters.
  • Page 63 Door switch replacement manual 1. Power off, remove the screws and the cover plate. Unplug the internal USB extension cable when take out the cover. 2. Unplug door switch connector 3. Finger press the clasp to rotate outward to pull out the door switch and replace it with a new one.
  • Page 64 RSP-200-24 power replacement manual 2. Take pictures before unplugging to avoid insert the wrong place when resetting. Unplug all connections on the 24V power board. 3. Remove the 24V switching power supply 1. Access to machine management system, fixing nuts and replace them. click on [Open Machine Door], open it and ATTENTION: remove six canisters.
  • Page 65 LRS-150-12 power replacement manual 2. Take pictures before unplugging to avoid insert the wrong place when resetting. Unplug all connections on the 12V power board. 3. Remove the 12V switching power supply 1. Access to machine management system, fixing nuts and replace them. click on [Open Machine Door], open it and ATTENTION: remove six canisters.
  • Page 66 Leakage switch replacement manual 2. Take pictures before unplugging to avoid insert the wrong place when resetting. Unplug the connection cable on the leakage switch 3. Remove the leakage switch sheet metal 1. Access to machine management system, screws and remove the leakage switch for click on [Open Machine Door], open it and replacement.
  • Page 67 LED light replacement manual 1. Power off, remove the screws and the cover plate. Unplug the internal USB extension cable when take out the cover. 2. Unplug the connector of the LED light, remove it from the snap, then can replace it...
  • Page 68 Motor (BO26) replacement manual 1. Access to machine management system, click on [Open Machine Door], open it and remove 2. Unplug the motor shaft of the corresponding 3. Unplug the canister motor connector, use a six canisters. Turn off the leakage protection canister to be replaced.
  • Page 69 86132 Motor replacement manual Remove the motor fixing Remove the screws screws to remove the cup detection sensor sheet metal Remove the sheet metal Remove the motor for replacement...
  • Page 70 Cup detected sensor (send/receive) replacement manual Access to machine management Remove the screws system, click [Open Machine 3. Remove the 2 screws and cup holder group Door and take out the cup barrel. (with automatic cup Turn off the machine power. lid capping machine) Remove the screws according to the structure of the plate...
  • Page 71 Cup door detected sensor (send/receive), LED light replacement manual 1. Access to machine management system, click [Open machine door]. Remove the screws on both sides of the cup door, cut the tie, unplug the connector. Remove the sensors and LED light, then can replace them...
  • Page 72 Fuma wheel replacement manual 1. Check before installation b. Make sure ② ③ does not ① 10300709 protrude ③ by a. Check if the M12 hex socket rotating ① to set screws fuam wheel is ① adjust the fuma wheel height to ②...
  • Page 73 Built-in ice maker replacement manual Unplug the Remove the ice maker fixing screws 3. Unplug the connector; remove the machine power behind the machine; Pull out the ice blue snap, then unplug the Teflon cord; Remove maker module and lift it out of the tube and the silicone tube the connector on machine;...
  • Page 74 Ice Control Board V1.5 (circuit board) replacement manual Access to machine management system, open machine door; turn off the power switch on the ice maker control box. Use a screwdriver to remove the control box fixing screws, cover screws, pull out the cover plate. Unplug all connections on the ice control board and remove the screws for replacement...
  • Page 75 Weighing sensor control board replacement manual Access to machine management system, open machine door; turn off the power switch on the ice maker control box. Unscrew the screw manually and remove the sheet metal. Unplug all connections on the weighing sensor control board and remove the screws for replacement...
  • Page 76 Ice catcher replacement manual - 1 Access to machine management system, open machine door; turn off the power switch on the ice maker control box. Unscrew the screw manually and remove the sheet metal. Unplug the connector on the weighing sensor control board and the motor connector, remove the screws and the weighing module.
  • Page 77 Ice catcher replacement manual - 2 2. Remove screws and 4. Remove ice catcher for replacement 3. Remove screws and take out sheet metal. take out sheet metal CAUTION: Prevent loss of flange bearing.
  • Page 78 Weighing tray replacement manual Access to machine management system, open machine door; turn off the power switch on the ice maker control box. Unscrew the screw manually and remove the sheet metal. Unplug the connector on the weighing sensor control board, remove the screws and the weighing module, then can replace it.
  • Page 79 Electronic scale replacement manual - 1 1. Access to machine management system, open machine door; turn off the power switch on the ice maker control box. Unscrew the screw manually and remove the sheet metal. Unplug the connector on the weighing sensor control board, remove the screws and the weighing module...
  • Page 80 Electronic scale replacement manual - 1 4. Take out ice catcher and remove 5. Remove the screws for the electronic scale fixing screws. electronic scale replacement 2. Remove screws and Remove screws and take out sheet metal. take out sheet metal CAUTION: Prevent loss of flange bearing.
  • Page 81 Drain valve replacement manual Access to machine management system, open machine door; empty the ice maker and its water tank, cut the tie. Unplug the valve control power connector and the silicone tube, remove the fixing screws, take out the drain valve for replacement...
  • Page 82 Temperature detection sensor replacement manual - 1 Unplug the 4. Remove the ice maker fixing 3. Unplug the connector; remove the machine power screws behind the machine; Pull blue snap, then unplug the Teflon cord; Remove out the ice maker module and lift tube and the silicone tube the connector on it out of the machine...
  • Page 83 Temperature detection sensor replacement manual - 2 5. Remove the temperature insulation 6. Cut the tie, take out the temperature 7. Cut the tie, take out the temperature cover, cut the tie and unplug the for replacement for replacement connector...
  • Page 84 MILL RECTIFIER V1.0 replacement manual 1. Access to machine management system, open 2. Take a picture, remove the connection machine door and turn off the machine. Find the cable and the screws. Now can replace fairing conversion box behind the grinder and the rectifier board remove the screws.
  • Page 85 Ice storage bucket replacement manual Unplug the connector; 4. Remove the ice maker fixing Unplug the machine remove the blue snap, then screws behind the machine; power cord; Remove unplug the Teflon tube and Pull out the ice maker module the connector on the the silicone tube and lift it out of the machine...
