MS350 Series Installation Guide
About this Guide
This guide provides instruction on how to install and configure your MS350 series switch. This guide also provides
mounting instructions and limited troubleshooting procedures. For more switch installation guides, refer to the
switch installation guides section
Model number
MS350-24
MS350-24P
MS350-48
MS350-48LP
MS350-48FP
MS350-24X
Product Overview
on our documentation website.
Layer-3 24-port gigabit Ethernet switch with 4 SFP+ interfaces, hot-swappable power
supplies and hot-swappable fans
Layer-3 24-port gigabit Ethernet PoE switch with 4 SFP+ interfaces, hot-swappable power
supplies and hot-swappable fans
Layer-3 48-port Physically Stacking gigabit Ethernet switch with 4 SFP+ interfaces, hot-
swappable power supplies and hot-swappable fans
Layer-3 48-port gigabit Ethernet 370W PoE switch with 4 SFP+ interfaces, hot-swappable
power supplies and hot-swappable fans
Layer-3 48-port gigabit Ethernet 740W PoE switch with 4 SFP+ interfaces, hot-swappable
power supplies and hot-swappable fans
Layer-3 16-port gigabit Ethernet and 8-port multigigabit 740W UPoE switch with 4 SFP+
interfaces, hot-swappable power supplies and hot-swappable fans
Description
1
Advertisement
Table of Contents
Related Manuals for Cisco MERAKI MS350 Series
Summary of Contents for Cisco MERAKI MS350 Series
- Page 1 MS350 Series Installation Guide About this Guide This guide provides instruction on how to install and configure your MS350 series switch. This guide also provides mounting instructions and limited troubleshooting procedures. For more switch installation guides, refer to the switch installation guides section on our documentation website.
- Page 2 Physical Specifications MS350-24 MS350-24P MS350-24X MS350-48 1Gbe RJ45 mGbe RJ45 10Gbe SFP+ 40Gbe QSFP+ Hardware Stack Port Dedicated Mgmt Interface UPoE Capable Hot Swap Power Yes, Dual Yes, Dual Yes, Dual Yes, Dual Supply Hot Swap Fans 100 - 240 VAC, 47-63 100 - 240 VAC, 47-63 100 - 240 VAC, Power Input...
- Page 3 MS350-48 Series front panel MS350-24x Series front panel Back Panel MS350 Series back panel Factory Reset Button If the button is pressed and held for at least five seconds and then released, the switch will reboot and be restored to its original factory settings by deleting all configuration information stored on the unit.
-
Page 4: Package Contents
Solid white Switch is fully operational and connected to the Meraki cloud Switch does not have power Switch Ports No client connected Solid orange 10/100 Mbps (1 Gbps on SFP+) Solid green 1/2.5/5/10 Gbps (10 Gbps on SFP+) Back Panel Components Item Function LED Status... - Page 5 Rack Mount Kit includes: ▪ US 12-24 mounting screws and cage nuts, 5 of each ▪ INTL M5 mounting screws and cage nuts, 5 of each ▪ INTL M6 mounting screws and cage nuts, 5 of each ▪ Mounting washers Other items: •...
-
Page 6: Pre-Install Preparation
Pre-install Preparation You should complete the following steps before going on-site to perform an installation. Configure your Dashboard Network The following is a brief overview only of the steps required to add a switch to your network. For detailed instructions about creating, configuring and managing Meraki networks, refer to the online documentation (documentation.meraki.com). -
Page 7: Installation Instructions
Dynamic Assignment When using DHCP, the DHCP server should be configured to assign a static IP address for each MAC address belonging to a Meraki switch. Other features of the network, such as 802.1X authentication, may rely on the property that the switches have static IP addresses. - Page 8 2. Attach the switch face plate to the cage nuts on the rack.
-
Page 9: Basic Troubleshooting
If you are still experiencing hardware issues, please contact Cisco Meraki support by logging in to dashboard and using the Help option near the top of the page, then opening and email case or calling using the contact information on that... -
Page 10: Bringing Your Stack Online
Meraki data sheets. If your Cisco Meraki device fails and the problem cannot be resolved by troubleshooting, contact support to address the issue. Once support determines that the device is in a failed state, they can process an RMA and send out a replacement device free of charge. - Page 11 • The equipment is used in areas without exposure to harmful and dangerous production factors, unless otherwise specified in the operational documentation and/or on the equipment labeling. • The equipment is not for domestic use. The equipment is intended for operation without the constant presence of maintenance personnel.
