MS125 Series Installation Guide
Models
1Gbe RJ45
10Gbe SFP+
Dedicated Mgmt Interface
PoE Capable
Power Supply
Fans
MS125-24
MS125-24P
24
24
4
4
1
1
No
Yes, 370W
Built-in
Built-in
No
Built-in
MS125-48
MS125-48LP
48
48
4
4
1
1
No
Yes, 370W
Built-in
Built-in
No
Built-in
MS125-48FP
48
4
1
Yes, 740W
Built-in
Built-in
1
Advertisement
Table of Contents
Related Manuals for Cisco MERAKI MS125
Summary of Contents for Cisco MERAKI MS125
- Page 1 MS125 Series Installation Guide Models MS125-24 MS125-24P MS125-48 MS125-48LP MS125-48FP 1Gbe RJ45 10Gbe SFP+ Dedicated Mgmt Interface PoE Capable Yes, 370W Yes, 370W Yes, 740W Power Supply Built-in Built-in Built-in Built-in Built-in Fans Built-in Built-in Built-in...
-
Page 2: Package Contents
Package contents In addition to the MS switch, the following are provided: ▪ US 12-24 mounting screws and cage nuts, 5 of each ▪ INTL M5 mounting screws and cage nuts, 5 of each... -
Page 3: Installation Instructions
▪ Mounting washers Installation Instructions Note: Each MS125 comes with an instruction pamphlet within the box. This pamphlet contains detailed step by step guides and images to assist in the physical install of the switch. 1. Install the mounting cage nuts in the rack being used for the switch. - Page 4 3. Connect power to the power supply unit.
- Page 5 4. (Optional) Install additional SFP+ units as needed, depending on the compatibility of your model. MS125-24 Series front panel...
-
Page 6: Ports And Status Indicators
MS125-24P Series front panel MS125-48 Series front panel MS125-48LP/FP Series front panel Ports and Status Indicators The MS uses LEDs to inform the user of the device's status. When the device powers on, all the Internet LEDs flash twice. Additional functions are described below, from left to right. -
Page 7: Mounting Hardware
The mounting hardware includes a rack mount kit for standard 1U racks. When installing the device, make sure that there is sufficient space between the rear of the rack and other obstacles to ensure adequate airflow. Optional Mid-Mount bracket MS125 48 port models are designed for an optional MA-MNT-MID-1 mid-mount bracket when using 2-post racks.
