Linking parent unit and baby unit

Dry materials
Wood, plaster, cardboard, glass
(without metal, wires or lead)
Brick, plywood
Reinforced concrete
Metal grilles or bars
Metal or aluminium sheets
1 Press and hold the
power-on light goes on�
2 Press and hold the
display lights up. The 'link' light on the parent unit starts flashing red
and the message 'LINKING' appears on the display�
When the parent unit and baby unit are linked, the 'link' light turns
solid green� The signal strength indicator and the message 'LINKED'
appear on the display�
If no connection is established, the message 'NOT LINKED' is displayed
and the parent unit starts and the parent unit starts to beep�
What to do if no link is established
- If the parent unit is out of range, place it closer to the baby unit, but
not closer than 1 metre/3.5 feet.
- If the baby or parent unit is too close, <2 m/6.5 ft away from another
DECT appliance (e.g. a cordless phone), switch off this appliance or
move the unit away from this appliance�
- If the baby unit is switched off, switch it on.
Operating range
- The operating range is 330 metres/1000 feet outdoors and up to
50 metres/150 feet indoors.
- The operating range of the baby monitor varies depending on the
surroundings and factors that cause interference� Wet and moist
materials cause so much interference that the range loss is up to
100%. For interference from dry materials, see the table below.
Material thickness
< 30 cm (12 in)
< 30 cm (12 in)
< 30 cm (12 in)
< 1 cm (0.4 in)
< 1 cm (0.4 in)
button on the baby unit for 2 seconds until the
button on the parent unit for 2 seconds until the
- 8 -
Loss of range
0-10 %
5-35 %
30-100 %
90-100 %
100 %
