- Page 1 Installation Instruction for Free Vented Cover for VSI Models – Non-Ducted iVector S2 | 2022-04-01 US/CND...
-
Page 2: Installation
iVector S2 Installation Instruction for Free Vented Cover 1. Warnings US/CND installed either in a vertical position with non-ducted This instruction sheet must be read in conjunction horizontal outlet or in a horizontal position with with the main installation manual supplied with the non-ducted vertical outlet. - Page 3 iVector S2 Installation Instruction for Free Vented Cover • Make 4 holes Ø 8mm (nominal inch) in line with the For the horizontal ceiling version, secure the US/CND holes, B, and insert the toggle bolts (2 for each bracket) into appliance through the 2 holes, A, using the screws the wall.
- Page 4 iVector S2 Installation Instruction for Free Vented Cover 4. Installation of exterior frame US/CND • Position the exterior frame so that it is pushed against the wall. • Secure it to the sides of the built-in casing using the 4 screws supplied with the kit.
- Page 5 iVector S2 Installation Instruction for Free Vented Cover 5. Installation of exterior front panel and filter retaining crossbar US/CND • Hook the upper part of the front panel onto the tabs on the • Secure the front panel, re-screwing the 6 screws previous-ly frame.
- Page 6 iVector S2 Installation Instruction for Free Vented Cover 6. Installation of lower grille US/CND • Insert the two tabs on the grille into the designated slots on For horizontal ceiling installations, install the front the lower part of the frame. grille safety supports following the instructions in the •...
- Page 7 iVector S2 Installation Instruction for Free Vented Cover • Turn it until it completely lifts out of its housing. US/CND • Remove the filter retaining crossbar by unscrewing the 2 • Pull the filters out horizontally and carry out the cleaning screws.
- Page 8 Every care has been taken in the creation of this document. No part of this document may be reproduced without the express written consent of Purmo Group. Purmo Group accepts no responsibility for any inaccuracies or consequences arising from the use or misuse of the...
