- Page 1 Router Oberfräse Défonceuse Fresatrice Fresadora Tupia Bovenfrees Overfræser Yläjyrsin Overfræser Överfräs Yönlendirici P108 Ρούτερ P117 WX15RT WX15RT.1 WX15RT.2 WX16RT WX16RT.1...
- Page 2 Original instructions Übersetzung der Originalanleitung Traduction des instructions initiales Traduzione delle istruzioni originali Traducción de las instrucciones originales Tradução das instruções originais Vertaling van de oorspronkelijke instructies Oversættelse af de oprindelige instruktioner Alkuperäisten ohjeiden käännös Oversettelse av de opprinnelige instruksjonene Översättning av originalinstruktionerna Asıl talimatların çevirisi Μετάφραση...
- Page 6 1. FINE-ADJUSTMENT KNOB FOR DEPTH-OF-CUT 2. SCALE FOR FINE ADJUSTMENT OF DEPTH-OF-CUT 3. CLAMPING LEVER 4. LEFT HANDLE 5. SCALE FOR COARSE ADJUSTMENT OF DEPTH-OF-CUT 6. DEPTH STOP 7. WING SCREW FOR DEPTH STOP 8. DUST BOOTS 9. STEP BUFFER 10.
-
Page 7: Technical Data
TECHNICAL DATA WX15RT WX15RT.2 WX15RT.1 WX16RT WX16RT.1 Rated voltage 230V~50Hz Rated power 1500W 1800W Rated no load speed 11500~28000/min Collet size Ø8 &12mm Double insulation Machine weight 4.3kg NOISE AND VIBRATION DATA A weighted sound pressure 86dB(A) A weighted sound power 97dB(A) &K... - Page 8 If the tool is to be used regularly then invest in anti vibration accessories. Avoid using tools in temperatures of 10 C or less. Plan your work schedule to spread any high vibration tool use across a number of days. ACCESSORIES WX15RT WX15RT.1 WX16RT WX16RT.1 WX15RT.2...
- Page 9 ADDITIONAL SAFETY RULES 18. Never allow children to use the machine. 19. Do not use blunt or damaged router FOR YOUR ROUTER bits. Blunt or damaged router bits cause increased friction, can become jammed 1. Hold tool by insulated gripping and lead to imbalance.
- Page 10 SYMBOLS OPERATING INSTRUCTIONS NOTE: Before using the tool, read the instruction book carefully. To reduce the risk of injury, user must read instruction manual INTENDED USE The machine is intended for routing grooves, edges, profiles and elongated holes as well Warning as for copy routing in wood, plastic and light building materials, while resting firmly on the...
- Page 11 HOW TO FIT THE 6.35 mm /1/4” COLLET must remain pressed during the entire (See A) ( WX15RT, WX16RT) operation. This router is supplied with a 6.35mm(1/4”) Speed pre-selection collet as an accessory. To fit the 6.35 mm(1/4”) collet (b) simply slide The required speed can be pre-selected with it into the 12.7mm collet (a) fitted to the collet...
- Page 12 increase in motor speed to reduce the motor freely without the router bit touching the work- “kick” or torque effect to improve operator piece. Lower the router again until the depth comfort and safety. stop touches the step buffer (9). Afterwards set scale (2) to “0”...
-
Page 13: Maintenance
turning the clamping lever in anti-clockwise the required measure with the wing bolts (12). direction, then switch on. Carry out the cutting • Guide the machine with uniform feed and procedure with uniform feed. After finishing sideward pressure on the parallel guide (21) the cutting process, slide the router upwards along the edge of the workpiece. -
Page 14: Environmental Protection
Declare that the product, Description PLUG REPLACEMENT WORX Router (UK & IRELAND ONLY) Type WX15RT WX15RT.1 WX15RT.2 WX16RT WX16RT.1 If you need to replace the fitted plug then Function Cutting slots into or shaping the follow the instructions below. edge of various materials...
