Summary of Contents for CENTR INSPIRE T7
- Page 1 Model: T7B-110.1 T7B-220.1 USER MANUAL CENTR INSPIRE SERIES T7 & IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Record Serial Number Here MADE IN CHINA 80305-EN-V2024-12-12...
-
Page 3: Product Warranty
WELCOME Welcome to Centr and thanks for your purchase. We're happy to have you. Please inspect your product and contact us right away if anything is missing or damaged. Your equipment also comes with access to Centr's digital membership, unlocking tools that will fuel your active lifestyle and well-being. -
Page 5: Table Of Contents
TABLE OF CONTENTS PRODUCT WARRANTY..................3 IMPORTANT SAFETY INSTRUCTIONS............6 WARNING AND SERIAL NUMBER LABELS..........8 USE OF SAFETY KEY..................10 GROUNDING INSTRUCTIONS (FOR 110V MACHINES)......11 GROUNDING INSTRUCTIONS (FOR 220V MACHINES)......12 HARDWARE PACK.....................13 ASSEMBLY......................14 FEATURES OVERVIEW..................23 MOVING INSTRUCTIONS................27 MAINTENANCE AND CARE................28 ADJUSTING THE RUNNING BELT...............29 LUBRICATING THE RUNNING BELT ............30 TROUBLESHOOTING..................31 80305-EN-V2024-12-12... -
Page 6: Important Safety Instructions
Never operate the treadmill if it has a damaged power cord or electrical plug, if it is not working properly, if it has been dropped or damaged, or partially immersed in water. Contact Centr properly, if it has been dropped or damaged, or partially immersed in water. Contact Centr customer service. - Page 7 ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE- EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. Centr, LLC. DOES NOT ASSUME ANY RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
-
Page 8: Warning And Serial Number Labels
80427-V2024-12-03 Manufacture according to MFG-001 specification, WARNING AND SERIAL NUMBER LABELS supplied by CENTR Engineering. WARNING / AVERTISSEMENT / ADVERTENCIA / WARNUNG 80311-V2024-12-03 HEART RATE MONITOR MAY BE INACCURATE. STOP IMMEDIATELY IF YOU FEEL FAINT. Manufacture according to MFG-001 specification, LE MONITEUR DE FRÉQUENCE CARDIAQUE PEUT ÊTRE IMPRÉCIS. - Page 9 80390-V2024-12-09 Manufacture according to MFG-001 specification, supplied by CENTR Engineering. HOME USE TREADMILL. For Consumer Use Only. Manufacturer / Fabricant / HEALTH IN MOTION LLC Fabricante / Hersteller TAPIS ROULANT À USAGE DOMESTIQUE. Pour usage grand public uniquement. 3300 Horseless Carriage Drive, Norco, CA 92860 CINTA DE CORRER PARA USO DOMÉSTICO.
-
Page 10: Space Requirements
SPACE REQUIREMENTS This treadmill requires a minimum amount of floor space to safely operate. Keep a minimum open area of 2 m (78 in) behind the treadmill, and 0.6 m (24 in) on both sides. A space of 0.3 m (12 in) in the front is recommended for access to the power cord and switch. -
Page 11: Grounding Instructions (For 110V Machines)
GROUNDING INSTRUCTIONS (FOR 110V MACHINES) This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This treadmill is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 12: Grounding Instructions (For 220V Machines)
GROUNDING INSTRUCTIONS (FOR 220V MACHINES) This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This treadmill is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 13: Hardware Pack
HARDWARE PACK (NOT TO SCALE) HARDWARE STEP 3 STEP 2 2X Screw, 4.2X10 (20) 4X Bolt, M8X15 (17) 2X Bolt, M8X15 (18) 6X Bolt, M10X25 (14) 4X Washer, 8 (19) 2X Washer, 8 (19) 6X Lock Washer, 10 (15) 6X Washer, 10 (16) STEP 5 STEP 8 STEP A... -
Page 14: Assembly
ASSEMBLY NOTE: PLEASE REMOVE NUT AND WASHER FROM BOLT, PRIOR TO ASSEMBLING. WARNING It is recommended to have at least 2 people for unboxing and assembling the treadmill. Some parts of the treadmill may require two or more people to move depending on their physical abilities. Be sure that you and others are all physically fit and able to safely move the machine. - Page 15 STEP 2 - Attach the Upright Assembly to the Base Frame Assembly. Be sure not to crimp or cut the Cables. DO NOT FULLY TIGHTEN THE HARDWARE UNTIL INSTRUCTED. Once attached, connect the Cables from the Upright Assembly to the Base Frame Assembly. WARNING Be sure to keep fingers away when placing the Upright Assembly onto the Base Frame Assembly.
- Page 16 STEP 3 - Attach the Console Base Assembly to the Upright Assembly. Be sure not to crimp or cut any Cables. DO NOT FULLY TIGHTEN THE HARDWARE UNTIL INSTRUCTED. Once attached, connect the Cables from the right Upright to the Console Base Assembly. It is recommended to have at least 2 people for this step.
- Page 17 STEP 4 - Align the edges of the Upright Assembly with the Base Frame Assembly and fully tighten the front bolts (*) that attach the Upright Assembly. THEN TIGHTEN ALL HARDWARE FROM PREVIOUS STEPS being sure that the Upright Assembly and Base Frame Assembly are still aligned. Upright Assembly ( * ) Base Frame Assembly...
- Page 18 STEP 5 - The Left and Right Inner Upright Covers have a tab on the front with a metal clip. Be sure that the metal clip on the tab is centered on the tab, and not past the edge of the Inner Upright Cover before installing.
- Page 19 STEP 6 - Re-attach the Power Input Cover to the Base Frame Assembly with the round head screws removed from the earlier step. DO NOT FULLY TIGHTEN THE HARDWARE UNTIL INSTRUCTED. Be sure not to crimp or cut any Cables. Base Frame Assembly Upright Assembly Power Input Cover...
- Page 20 STEP 7 - Re-attach the Motor Cover to the Base Frame Assembly with the flat head screws removed from the earlier step. The Power Input Cover may need to be slightly flexed to properly set the Motor Cover. TIGHTEN ALL HARDWARE FROM PREVIOUS STEPS. Motor Cover Base Frame Assembly Power Input Cover...
- Page 21 STEP 8 - Route the Cables up into the Console Mast while sliding it down onto the Console Base Assembly. Only pull the Cables out enough to route them into the Console Mast. Be sure not to crimp or cut any Cables. Attach the Console Mast to the Console Base Assembly. Then tighten the pre-installed hardware inside of the Console Mast to fully secure it to the Console Base Assembly.
- Page 22 Console Assembly. If needed, the Console User Manual can be found by scanning the appropriate QR Code. 80322-EN 80323-EN FOR T7S FOR T7 CENTR INSPIRE SERIES CENTR INSPIRE SERIES 15.6” TOUCHSCREEN 15” TOUCH KEY LED DISPLAY Pg. 22 80305-EN-V2024-12-12...
-
Page 23: Features Overview
FEATURE OVERVIEW CONSOLE MAST CONSOLE KEYPAD WATER BOTTLE HOLDER CHARGING TRAY CONTACT HEART RATE SENSORS INCLINE CONTROLS PHONE HOLDER SIDE HANDRAILS SPEED CONTROLS UPPER HANDRAILS SAFETY KEY RUNNING BELT RUNNING DECK TRANSPORT WHEEL DECK SIDE PLATFORM LIFTING HANDLE LEVELER BELT ADJUSTMENT BOLTS 80305-EN-V2024-12-12 Pg. -
Page 24: Before You Begin
Console. If the Console User Manual needs to be found electronically, scan the appropriate QR Code to access the Console User Manual. 80322-EN 80323-EN FOR T7S FOR T7 CENTR INSPIRE SERIES CENTR INSPIRE SERIES 15.6” TOUCHSCREEN 15” TOUCH KEY LED DISPLAY Pg. 24... - Page 25 6. The app will show that it is connected to the treadmill. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Centr, ® LLC, is under license. Other trademarks and trade names are those of their respective owners.
- Page 26 7. Tap OK. 8. Then select a workout and tap Start when ready to workout. 9. Once the workout on the app begins, push Start on the treadmill to begin a Quick Start workout. The app will capture your workout from the treadmill. Note: If the app does not follow along with the workout, the connection to the treadmill may need to be reconnected.
-
Page 27: Moving Instructions
MOVING INSTRUCTIONS Before moving the treadmill, be sure that the Incline is set to 0, the Power switch is in Off position, and the power cord is removed from the outlet and machine. WARNING The treadmill may be moved by one or more people depending on their physical abilities. Be sure that you and others are all physically fit and able to safely move the machine. -
Page 28: Maintenance And Care
MAINTENANCE AND CARE WARNING The safe operation of the machine can only be maintained when the equipment is regularly examined for damage and wear. It is the sole responsibility of the user/owner to ensure that regular maintenance and inspections for damage and wear are performed. Special attention should be given to components which are most susceptible to wear. -
Page 29: Adjusting The Running Belt
ADJUSTING THE RUNNING BELT The running belt is properly adjusted at the factory but may loosen or change over time. It is important to properly adjust the running belt so it has the right tension and is centered on the deck, without drifting to one side. -
Page 30: Lubricating The Running Belt
LUBRICATING THE RUNNING BELT The pre-lubricated running belt on this treadmill should run approximately 5592 miles IMPORTANT NOTE: (9000 km) before the belt and deck need to be inspected for lubrication. After the initial break in period, lubricating the running deck and belt is essential as the friction between the two affects the life span and function of the treadmill. -
Page 31: Troubleshooting
TROUBLESHOOTING When the treadmill electronics detect a problem or a potential problem, the HR window in the center of the console keypad will display one of the Error Codes in the following table. WARNING Always unplug the treadmill from the electrical outlet before cleaning, lubricating or repairing the unit. ERROR CODE POSSIBLE SOLUTION(S) E01H - Low Voltage Disconnect... -
Page 32: Calibration Failure
WARNING Always unplug the treadmill from the electrical outlet before cleaning, lubricating or repairing the unit. ERROR CODE POSSIBLE SOLUTION(S) E0AH - Motor Overload Confirm if the load is too heavy. 2. Check if the running belt needs lubrication, if the running belt is severely worn and needs replacement, or if there are any abnormalities in the transmission mechanism (such as the rollers). -
Page 33: Connection Error
WARNING Always unplug the treadmill from the electrical outlet before cleaning, lubricating or repairing the unit. ERROR CODE POSSIBLE SOLUTION(S) EMERGENCY STOP - Safety Check if the safety switch button operates smoothly and freely. Switch Error 2. Check if the connection wires and plugs for the safety switch are loose or disconnected. - Page 34 Pg. 34 80305-EN-V2024-12-12...
- Page 35 80305-EN-V2024-12-12 Pg. 35...
- Page 36 centr.com...
