Model # CSM.2
USER MANUAL
START HERE
SMITH
QUICKSELECT
COMMERCIAL SMITH MACHINE
Record Serial Number Here
Centr LLC
80009-V2024-04-17
PATENT PENDING
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSPIRE SMITH QUICKSELECT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CENTR INSPIRE SMITH QUICKSELECT

Summary of Contents for CENTR INSPIRE SMITH QUICKSELECT

  • Page 1 Model # CSM.2 USER MANUAL START HERE SMITH QUICKSELECT COMMERCIAL SMITH MACHINE Record Serial Number Here Centr LLC 80009-V2024-04-17 PATENT PENDING MADE IN CHINA...
  • Page 2 Pg. 2 80009-V2024-04-17...
  • Page 3 If you need help finding an Inspire Fitness Authorized Servicer, please contact us directly: Email Phone Hello@centr.com +1 877-738-1729 (US Only) +1 714-738-1729 (Global) Mon-Fri 8am-5pm PT - UTC-7h/8h *Support is provided in English and Spanish* 80009-V2024-04-17 Pg.
  • Page 4 Pg. 4 80009-V2024-04-17...

  • Page 5: Table Of Contents

    csm.2 TABLE OF CONTENTS IMPORTANT SAFETY NOTICE..............6 IMPORTANT SAFETY INSTRUCTIONS............7 GROUND ANCHORING................7 WARNING AND SERIAL NUMBER LABELS..........8 ASSEMBLY HARDWARE KIT..............9 ASSEMBLY INSTRUCTIONS..............12 EXPLODED VIEW..................23 PARTS LIST....................24 PRODUCT WARRANTY................25 80009-V2024-04-17 Pg. 5...

  • Page 6: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. Please note the following safety precautions: Consult your physician before beginning any exercise program Always keep children and pets away from the machine.

  • Page 7: Important Safety Instructions

    INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. Centr LLC. DOES NOT ASSUME ANY RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. THIS MACHINE REQUIRES 2 PEOPLE FOR ASSEMBLY.

  • Page 8: Warning And Serial Number Labels

    WHEN THIS EQUIPMENT IS IN USE. TEENAGERS SHOULD NOT USE THIS EQUIPMENT WITHOUT ADULT SUPERVISION. 8. CALL YOUR AUTHORIZED CENTR DISTRIBUTOR IF YOU HAVE ANY QUESTIONS ON THE PROPER USE OR MAINTENANCE OF THIS EQUIPMENT. 9. MAKE SURE ALL PULL PINS, LOCKS, AND SAFETY LATCHES ARE IN PLACE AND FULLY ENGAGED BEFORE EACH USE.

  • Page 9: Assembly Hardware Kit

    csm.2 ASSEMBLY HARDWARE KIT CSM-2 103444 STEP1 6-M10x125 Hex Bolts - (15) 8-M10x25 Hex Bolts - (14) 20-M10 Flat Washers -(12) 6-M10 Locknuts -(13) STEP2 4- Countersunk Flat Cushion -(16) 4-M8x20 Flat Head Screws -(17) 4 - M8 x 20 Button Head Bolts -(52) 4 - M8 Flat Washers -(31) HARDWARE PACK (NOT TO SCALE) 80009-V2024-04-17...
  • Page 10 ASSEMBLY HARDWARE KIT CSM-2 103445 STEP3 4-M10x90 Hex Bolts -(21) 4-M10 Locknuts -(13) 8-M10 Flat Washers-(12) 8 - M6*5 Set Screws-(18) STEP4 4 - M10 x40 Hex Bolts-(25) 8- M10 Flat Washers-(12) 4 - M10 Locknuts -(13) 4 - M6*5 Set Screws -(18) STEP5 8 - Limit buckle-(29) STEP6...
  • Page 11 csm.2 ASSEMBLY HARDWARE KIT CSM-2 103446 STEP7 8 - M10 x 20 Hex Bolts-(35) 1 - M10 x 80 Hex Bolts-(38) 2 - M10 x 95 Hex Bolts-(39) 1 - M10 x 125 Hex Bolts -(15) 10 - M10 Flat Washers-(12) 8 - M8 x 16 Button Head Bolts-(30) 8 - M8 Flat Washers-(31) 2 - Hat Washers-(36)

  • Page 12: Assembly Instructions

    FRAME ASSEMBLY STEP 1-A STEP 1-B Assemble Lower Cross Brace (1) to Main Assemble Lower Cross Brace (1) to Main Frame Left (7), secure with Bolt (15), Washer (12) and Frame Right (6), secure with Bolt (15), Washer (12) and Nut Nut (13).DO NOT FULLY TIGHTEN YET.
  • Page 13 csm.2 TRACK BAR INSTALLATION STEP 2-A STEP 2-B Install TUBULAR Rack (3) to Sliders Left Install Bolt (52) , Washer (31) and right side, secure with Bolt (17), Washer (16). Secure To Secure in place. in place. If needed. The trackbar can be adjusted in and out by turning the threaded spacer.
  • Page 14 GUIDE ROD AND SMITH BAR INSTALLATION INSTALL SET SCREWS TOP STEP 3 A. Slide a Rod Slider (20) thru the upper holes of the frame. STEP 3 B. Slide Rod Mount (8) On each guide bar, then Fasten Brackets (8) with Bolt (21), Washers (12), LockNuts (13).
  • Page 15 csm.2 INSTALL WEIGHT PLATES STEP 4 A. Insert the Guide Rods (24) through the holes in the bottom of the frame. Be sure the ends of the rods with the holes are facing Up. STEP 4 B. Slide a Rubber Bumper (23) on each of the Guide Rods (24).
  • Page 16 COUNTER WEIGHTS INSTALLATION STEP 5 A. Install Counterweight cable (58) to Weight bar (11) with U Braclet(55), Bolt (56) and Bolt (57). Then move Weight Bar (11) to its highest position. STEP 5 B. Set Counter Balance Weight (9) At bottom of the frame, next to the weightstack.
  • Page 17 csm.2 GUIDE CABLES TOP STEP 5 D. Install Counter Weight Guide Cable (28) 2 per side. Install at top first, then tension at bottom. STEP 5 E. Install Grommets (29) on cable guides, then push into counter weights. INSTALL GROMMETS GUIDE CABLES BOTTOM 80009-V2024-04-17 Pg.
  • Page 18 STEP 6-A Install 3 Upper Leveling Brackets (5) Bolts (35) Washer (12) to build Shroud Mount Loop (2) for top. 1 for left side, 1 for right side. Hand tighten bolts. STEP 6-B Install Rear Upper Shroud Mount brakets (4) (LEFT AND RIGHT SIDE) to the Upright Frames with Bolt (15), Screw the Upper Leveling Brackets with the Bolts (30) and the Washers (31).
  • Page 19 csm.2 STEP 6-C Install 2 Bolts (35) with Spacers (36) to build Shroud Loop (2) for Lower frame. 1 for left side, 1 for right side. Hand tighten bolts. STEP 6-D Install Lower Shroud Mount brakets (37) to the Upright Frames with Bolts (35) and Washers (12) on two sides.
  • Page 20 STEP 7 A Install Main Shroud(32) Wraps on the OUTSIDE of the frame. Open the velcro and wrap around upper, and VELCRO then Lower Bracket. STEP 7 B Install Rear Shroud(33) Wraps on the INSIDE of the frame. From the Right of the weightstack to the back STEP 7 C Install Middle Shroud(34) This is the shortest piece.
  • Page 21 csm.2 TOP COVER INSTALLATION STEP 8 A Install Inner Right Top Cover (46) and Outer RightTop Cover(47). Locate where the 2 pieces will go, secure using Bolts (41)(43)(44)(47)(23), and Threaded Cylinders (40) on opposite side. as illustrated below. STEP 8 B Repeat installation process for opposite side for Inner Left Top Covers (45) and Outer Left Top Cover (48).
  • Page 22 PLACARDS INSTALLATION STEP 9 Install Placards (50) and (51) to right and left inner part of shroud. Use Bolt LockNut (49) to secure in place. There are 2 different placards, one for Left side, one for Right side. SQUAT CHEST PRES S SCAN FOR SCAN FOR EXERCISE DEMO...

  • Page 23: Exploded View

    csm.2 80009-V2024-04-17 Pg. 23...

  • Page 24: Parts List

    Description Part Number WLDMT, LOWER CROSS BRACE 102451 WLDMT, SHROUD LOOP, CSM2 102593 TUBE, TUBULAR RACK 102550 WLDMT, REAR UPPER SHROUD BRACKET, CSM2 102598 UPPER LEVELING BRACKET, CSM2 102601 ASSY, MAIN FRAME, RH 102455 ASSY, MAIN FRAME, LH 102538 ASSY, SLIDE ROD MOUNT, CSM2 102576 WLDMT, COUNTER BALANCE WEIGHT, CSM2 102584...

  • Page 25: Product Warranty

    csm.2 PRODUCT WARRANTY To view full warranty details, or to register your product for warranty, visit inspirefitness.com/support AUSTRALIA Our goods come with guarantees that cannot be excluded under the Australian Consumer. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
