DaVinci GreenSmart GSE39 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND OPERATION.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Travis Industries, Inc.
 Copyright 2024, T.I.
DaVinci GreenSmart
Electric Fireplaces
KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE.
12521 Harbour Reach Dr., Mukilteo, WA 98275
Manual
French language manuals at davincifireplace.com.
Manuels de langue Française à davincifireplace.com
$10.00
3/12/25
www.travisproducts.com
100-01597

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GreenSmart GSE39 and is the answer not in the manual?

Questions and answers

Related Manuals for DaVinci GreenSmart GSE39

Summary of Contents for DaVinci GreenSmart GSE39

  • Page 1 DaVinci GreenSmart Electric Fireplaces Manual PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND OPERATION. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. INSTALLER: Leave this manual with the appliance. French language manuals at davincifireplace.com. Manuels de langue Française à davincifireplace.com CONSUMER: Retain this manual for future reference.

  • Page 2: Overview

    Introduction Overview This manual details the installation and operation of the DaVinci GreenSmart Electric fireplaces. Listing Details This appliance was listed to UL 2021 4 Edition Dedicated Electric Room Heaters / CSA C22.2 No.46- 13(R2018) – Electric Air-Heaters. The listing label adhered to the back of the appliance. A copy is shown to the right.

  • Page 3: Table Of Contents

      Replacement Parts List ........... 66   Electrical Connection ..........22     DaVinci 39 GSE .............. 66   Hardwire Installations 120v or 240v ........ 22 Wiring Diagram (39 GSE) ......... 77     Power Cord Installations (120v Only) ......23 Wiring Diagram (51 &...

  • Page 4: Safety Precautions

    WARNING: To reduce the risk of fire, electric shock, or injury to persons, always use a licensed electrician. WARNING: In order to avoid overheating, do not cover the heater or air vents located on the appliance or obstruct the air circulation around the appliance. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 5 The adapter should not be used if a three-slot grounded receptacle is available. NOTE: Adaptors are NOT for use in Canada. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 6 State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov WARNING Read this entire manual before proceeding with the installation. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 7: Installation Options

    120V AC 60Hz Supply Voltage 240V AC 60Hz If wired to 120v AC - 1400 Max. Power Consumption (watts) If wired to 240v AC - 2800 Power for Flame Effect (watts) © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 8: Packing List (39 Gse)

    Side Tile Stop (top/bottom) (x4) Glass Suction Cup Tools (x2) Side Tile Stop (side)( x2) 120v Power cord Side panel (x2) Back panel uplight (x1) DaVinci GreenSmart Electric Fireplace Remote handset Magnetic tool © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 9: Packing List (51 Gse)

    Side Tile Stop (top/bottom) (x4) Glass Suction Cup Tools (x2) Side Tile Stop (side)( x2) 120v Power cord Side panel (x2) Back panel uplight (x2) DaVinci GreenSmart Electric Fireplace Remote handset Magnetic tool © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 10: Packing List (59 Gse)

    Side Tile Stop (top/bottom) (x4) Glass Suction Cup Tools (x2) Side Tile Stop (side)( x2) 120v Power cord Side panel (x2) Back panel uplight (x2) DaVinci GreenSmart Electric Fireplace Remote handset Magnetic tool © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 11: Packing List (71 Gse)

    Side Tile Stop (top/bottom) (x4) 120v Power cord Side Tile Stop (side)( x2) Back panel uplight A Side panel (x2) Back panel uplight B DaVinci GreenSmart Electric Fireplace Back panel uplight C Magnetic tool Remote handset Glass Suction Cup Tools (x2) © Travis Industries...

  • Page 12: Recommended Installation Procedure

    7. Install the hearth (if applicable). Install the mantel (if applicable). 8. Finalize the installation (see page 31). Recommended Specialty Tools  Large Level (or Laser Level)  Outlet tester and/or multi-meter © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 13: Dimensions - Single Sided Configurations

    Installation (for qualified installers only) Dimensions - Single Sided Configurations Appliance Width Dimension (a) DaVinci 39 GSE 39-3/4” (1010mm) DaVinci 51 GSE 51-1/2” (1308mm) DaVinci 59 GSE 59-3/8” (1508mm) DaVinci 71 GSE 71-1/8” (1807mm) © Travis Industries 3/12/2025 - 1597...
  • Page 14 Installation (for qualified installers only) Dimensions – Bay Configuration Appliance Width Dimension (a) Width Dimension (b) DaVinci 39 GSE 39-3/4” (1010mm) 41” (1041mm) 52-3/4” (1340mm) DaVinci 51 GSE 51-1/2” (1308mm) DaVinci 59 GSE 59-3/8” (1508mm) 60-5/8” (1540mm) DaVinci 71 GSE 71-1/8”...
  • Page 15 Installation (for qualified installers only) Dimensions – Left Corner Configuration Appliance Width Dimension (a) Width Dimension (b) DaVinci 39 GSE 39-3/4” (1010mm) 40-3/8” (1026mm) DaVinci 51 GSE 51-1/2” (1308mm) 52-1/8” (1324mm) DaVinci 59 GSE 59-3/8” (1508mm) 60” (1524mm) DaVinci 71 GSE 71-1/8”...
  • Page 16 Installation (for qualified installers only) Dimensions – Right Corner Configuration Appliance Width Dimension (a) Width Dimension (b) DaVinci 39 GSE 39-3/4” (1010mm) 40-3/8” (1026mm) DaVinci 51 GSE 51-1/2” (1308mm) 52-1/8” (1324mm) DaVinci 59 GSE 59-3/8” (1508mm) 60” (1524mm) DaVinci 71 GSE 71-1/8”...

  • Page 17: Installation

    Installation (for qualified installers only) Minimum Framing Dimensions – Single Sided configuration Appliance Width Dimension (W) Height Dimension (H) DaVinci 39 GSE 40-1/4” (1022mm) 25-1/8” (638mm) DaVinci 51 GSE 52” (1321mm) 23-5/8” (600mm) DaVinci 59 GSE 59-7/8” (1521mm) 23-5/8” (600mm) DaVinci 71 GSE 71-5/8”...

  • Page 18: Minimum Framing Dimensions - Bay Configuration

    Installation (for qualified installers only) Minimum Framing Dimensions – Bay configuration Appliance Width Dimension (W) Height Dimension (H) DaVinci 39 GSE 39-3/4” (1010mm) 25-1/8” (638mm) DaVinci 51 GSE 51-1/2” (1308mm) 23-5/8” (600mm) DaVinci 59 GSE 59-3/8” (1508mm) 23-5/8” (600mm) DaVinci 71 GSE 71-1/8”...

  • Page 19: Minimum Framing Dimensions - Left Corner Configurations

    Installation (for qualified installers only) Minimum Framing Dimensions – Left Corner configurations Appliance Width Dimension (W) Height Dimension (H) DaVinci 39 GSE 40” (1016mm) 25-1/8” (638mm) DaVinci 51 GSE 51-3/4” (1314mm) 23-5/8” (600mm) DaVinci 59 GSE 59-5/8” (1514mm) 23-5/8” (600mm) DaVinci 71 GSE 71-3/8”...

  • Page 20: Minimum Framing Dimensions - Right Corner Configuration

    Installation (for qualified installers only) Minimum Framing Dimensions – Right Corner configuration Appliance Width Dimension (W) Height Dimension (H) DaVinci 39 GSE 40” (1016mm) 25-1/8” (638mm) DaVinci 51 GSE 51-3/4” (1314mm) 23-5/8” (600mm) DaVinci 59 GSE 59-5/8” (1514mm) 23-5/8” (600mm) DaVinci 71 GSE 71-3/8”...

  • Page 21: Hearth Requirements

    A combustible or noncombustible hearth may be installed in front of the fireplace anywhere up to the edge of the fireplace opening. The hearth finish material must not extend beyond the fireplace opening or it will interfere with the installation and removal of the glass. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 22: Electrical Connection

    NOTE: If using the included power cord make sure that the outlet is “readily accessible”, grounded, and meets all other code requirements. We recommend checking with the local authority having jurisdiction while planning the installation. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 23: Power Cord Installations (120V Only)

    Connect the power cord assembly with the replacement cover plate to the fireplace wire harness.  Reinstall the screws removed in the first step, to secure the cover plate and cord to the fireplace. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 24: Installation

    Insert the fireplace into the framing. Slide the fireplace back until the nailing flanges are pressed up against the front of the framing. c) Screw the flanges to the framing as shown below. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 25 Reinstall the shipping bracket screws to the appliance and discard the shipping bracket.  Using the magnetic tool, lift and remove the glass retaining bar located in front of the glass panel. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 26 See the stickers on the glass panel for guidance. Replace the glass in the reverse order to initial removal, ensuring that both steel plate brackets are fitted and secured using the thumbscrews. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 27: Fireplace Configurations

    Using the removed screws, install (2) of the top/bottom tile stops and (1) side tile stop and screw them to the appliance (see “Bay Configuration” illustration on the following page). © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 28: Bay Configuration

    NOTE: The clip on the electrical connector should be oriented toward the front of the fireplace when oriented properly. NOTE: The GSE 39 has (1) uplight The GSE 51 and GSE 59 have (2) uplights The GSE 71 has (3) uplights © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 29: Facing & Mantel Requirements

    Mantel Requirements  A mantel (combustible or non-combustible) may be installed above the fireplace. Make sure it does not overlap the glass opening.  The maximum mantel depth is 12” (305mm). © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 30: Tv Installations Above The Fireplace

    There is no maximum depth for a recessed TV installation.  Check with the manufacturer of the Television for any additional installation requirements when their product is installed in proximity to a heat source. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 31: Finalizing The Installation

    Step 3: Position log AI-30 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 32 Step 7: Position log P-10 onto the corresponding outline on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 33 Ensure good coverage, including areas underneath the raised logs. Step 11: Distribute the black resin embers around the base of the logs, placing them inside the black area of the fuel bed. Ensure good coverage. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 34 Complete the setup by carefully re-fitting the front glass using the suction cup tools provided, then re-fit the glass retaining bar following the steps detailed in the section “Glass Removal” in reverse. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 35: Log And Media Installation (51& 59 Gse)

    Step 3: Position log AI-7 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 36 Position log AI-9 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed, and plug the cable into the port on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 37 Step 11: Position log AA-16 onto the corresponding outline on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 38 Position log AI-5 onto the corresponding outline on the fuel bed and plug the cable into the connector on the fuel bed. Step 15: Position log AD-8 onto the corresponding outline on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 39 Distribute the black glass embers around the entire fuel bed, placing them over both clear and black resin embers. Do not feel that you need to use all of the black glass embers provided. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 40 Complete the setup by carefully re-fitting the front glass using the suction cup tools provided, then re-fit the glass retaining bar following the steps detailed in the section “Glass Removal” in reverse. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 41: Log And Media Installation (71 Gse)

    Step 3: Position log AI-22 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 42 Position log AI-21 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed, and plug the cable into the connector on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 43 Step 11: Position log AI-10 onto the corresponding outline on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 44 Position log AI-24 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed, and plug the cable into the connector on the fuel bed. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 45 Step 19: Distribute the black resin embers around the base of the logs, placing them inside the black area of the fuel bed. Ensure good coverage, including areas underneath the raised logs. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 46 Complete the setup by carefully re-fitting the front glass using the suction cup tools provided, then re-fit the glass retaining bar following the steps detailed in the section “Glass Removal” in reverse. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 47: Operation

    Light Kit is working correctly before the final sheeting and finish has been installed over the framing. Once you are satisfied that the lighting is working correctly with the remote control, the sheeting can be installed, and the finish material applied. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 48: Before You Begin

    Operation Before You Begin  Read this entire manual before you use your new heater (especially the section "Safety Precautions" on pages 4 & 5). Normal Operating Sounds © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 49: Location Of Controls

    Located in the upper right corner of the fireplace, above the glass. Remote Control The remote is included with the appliance. Digital Assistants Works with Alexa™ and Google Home™ (Not included) Smart Home App Works with Apple™ and Android™ © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 50: Manual Control Operation

    Press 4 times = no heat/no fan Press 2 times = low heat setting Preset Mode Press repeatedly to cycle through the 6 fire preset modes (+3 user-defined presets if programmed). © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 51: Remote Control Operation

    Flame type A (gas style flame), White Flame type B (wood burning style FL.1 FL.4 Flame type A (gas style flame), Orange flame), Orange FL.2 Flame type A (gas style flame), Yellow © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 52 While in the sound effect menu, press the plus and minus buttons to increase and decrease the volume - 1 bar is the quietest setting, and 5 bars is the loudest setting. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 53: App Control

    App Control There are (2) methods for connecting the fireplace to the DaVinci app. The automatic method allows the app to identify and connect to the fireplace on its own. If for some reason this method does not work, proceed to the next section titled “Manual app installation and setup”...
  • Page 54 Once this is complete the app will begin to connect to the appliance. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 55 Sharing access section. If the automatic method was not successful in connecting the fireplace with the app, follow the steps in the next section “Manual App Installation and Setup”. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 56: Manual App Installation And Setup

    Operation MANUAL APP INSTALLATION AND SETUP To connect your Fireplace to the DaVinci app you will need the following.  A device running the Android or iOS operating system such as a tablet or smartphone.  A network within range of the fireplace.
  • Page 57 Once the password has been entered, you will be presented with a checklist to ensure trouble-free connection of your appliance to the network. You may also be asked to allow location permissions, please read, and follow the on-screen prompts. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 58 Heater (Wi-Fi). The app will then prompt you to enter your Wi-Fi password, ensure the correct network is selected, enter your Wi-Fi password, and then press the next button. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 59 When first initiating the pairing, the fuel bed will flash red. Once successfully paired the fuel bed will display green. If a flashing blue fuel bed appears repeat the pairing procedure. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 60 Once paired with the fireplace, the app can be used to control the fireplace. The fireplace will now be shown on the Tuya home screen. Select the appliance to begin using the DaVinci/Fireplace Xtrordinair app. To turn the fireplace on, use the power button as highlighted in the illustration below.

  • Page 61: Advanced Wi-Fi Router Guidance

    If the signal strength is not full, it may indicate a connectivity issue. If they are greyed out or only 1 or 2 bars are showing, then the signal strength of your home network may need boosting in order for your Tuya app to control the appliance. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 62: Voice Control

    Finally, click either “Link to Amazon Alexa” or “Link to Google Assistant” and follow the on-screen instructions to complete the pairing setup. Once paired, the following voice commands can be used: NOTE: <my fireplace> refers to the name set for the DaVinci appliance within the smart device settings. This can be changed to suit your preference.
  • Page 63 Alexa, turn up volume on <my fireplace> Volume Alexa, turn down volume on <my fireplace> Alexa, set <my fireplace> to 5-104 Set Room Alexa, make it warmer in here Temperature Alexa, make it cooler in here © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 64: Danger High Voltage

    Glass Cleaning The glass may be cleaned with a non-abrasive cleaner. To clean the inside of the glass, remove the glass, place it on a non-scratching surface, and clean the inside surface. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 65: Troubleshooting

    See above for the reset procedure. engaged the E.S.C. feature. Heat turns off   before desired Open window detection Check that any windows in the room are closed. temperature is has been activated. reached. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 66: Replacement Parts List

    Maintenance (for qualified technicians only) Replacement Parts List CAUTION: Use only Travis Industries replacement parts. Do not use substitute materials. DaVinci 39 GSE © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 67 DAVINCI ALL GSE - ROCKER SWITCH# 250-06693 DAVINCI ALL GSE - WIRING INLET BOARD# 250-06694 DAVINCI ALL GSE - POWER CORD# 250-06960 DAVINCI ALL GSE - FUEL BED LED BOARD B# 250-06937 DAVINCI ALL GSE - LCD SCREEN# 250-06692 © Travis Industries 3/12/2025 - 1597...
  • Page 68 Maintenance (for qualified technicians only) DaVinci 51 GSE © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 69 DAVINCI 51 GSE - DOWN LIGHT LED# 250-06784 DAVINCI 51 GSE - FLAME SCREEN# 250-06785 DAVINCI 51 GSE - FUEL BED LED BOARD A# 250-06662 DAVINCI 51 GSE - FUEL BED LED BOARD B# 250-06663 DAVINCI 51 GSE - FUEL BED SPINDLE#...
  • Page 70 Maintenance (for qualified technicians only) DaVinci 59 GSE © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 71 DAVINCI 59 GSE - FRONT GLASS# 250-06658 DAVINCI 59 GSE - FLAME SCREEN# 250-06660 DAVINCI 59 GSE - FUEL BED LED BOARD A# 250-06662 DAVINCI 59 GSE - FUEL BED LED BOARD B# 250-06663 DAVINCI 59 GSE - FUEL BED SPINDLE#...
  • Page 72 Maintenance (for qualified technicians only) DaVinci 71 GSE © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 73 DAVINCI 71 GSE - LOG LIGHT PCB# 250-06936 DAVINCI 71 GSE - LED BOARD, FUEL BED 250-06937 DAVINCI 71 GSE - BACK PANEL, [RT] UP LIGHT LED 250-06941 DAVINCI 71 GSE - BACK PANEL, [MID] UP LIGHT LED 250-06942 DAVINCI 71 GSE - BACK PANEL, [LF] UP LIGHT LED...
  • Page 74 (250-06906) AI-21 AI-23 (250-06907) (250-06908) AI-27 AI-28 (250-06909) (250-06910) AI-29 AI-30 (250-06911) (250-06912) Twig P-10 P-15 (250-06858) (250-06893) Medium Char (250-06890) Contact your local DaVinci™ fireplace dealer to purchase replacement parts. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 75: Maintenance

    (250-06862) (250-06889) AD-8 X-14 (250-06859) (250-06867) Small Bark P-10 P-13 (250-06858) (250-06892) Twig Medium Char P-15 (250-06893) (250-06890) Large Char (250-06891) Contact your local DaVinci™ fireplace dealer to purchase replacement parts. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 76 AI-25 (250-02617) (250-06914) Chunk AI-26 AI-31 (250-06918) (250-06905) Chunk Medium Char AA-16 (250-06862) (250-06890) Small Bark Twig P-13 P-15 (250-06892) (250-06893) Contact your local DaVinci™ fireplace dealer to purchase replacement parts. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 77: Wiring Diagram (39 Gse)

    Wiring Diagram Wiring Diagram (39 GSE) Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 78: Wiring Diagram (51 & 59 Gse)

    Wiring Diagram Wiring Diagram (51 & 59 GSE) Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 79: Wiring Diagram (71 Gse)

    Wiring Diagram Wiring Diagram (71 GSE) Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...

  • Page 80: Limited Warranty

    WITHIN 30 DAYS, giving them proof of purchase, the purchase date, and the model name and serial number. 2. Travis Industries, Inc. has the option of either repairing or replacing the defective component. © Travis Industries 10/10/2023 - 1592 DaVinci GreenSmart Electric...
  • Page 81 Notes © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 82 Notes © Travis Industries 10/10/2023 - 1592 DaVinci GreenSmart Electric...
  • Page 83 Notes © Travis Industries 3/12/2025 - 1597 DaVinci GreenSmart Electric...
  • Page 84 Voice Control Operation ........62 Installation ............24 Wiring Diagrams ..........77 Installation Options ..........7 Yearly Service Procedure ........ 64 Location of Controls ......... 49 Log and Media Installation ....... 31 © Travis Industries 10/10/2023 - 1592 DaVinci GreenSmart Electric...
