PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND OPERATION.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Travis Industries, Inc.
 Copyright 2024, T.I.
DaVinci 59 GreenSmart
Electric Fireplace
KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE.
12521 Harbour Reach Dr., Mukilteo, WA 98275
Manual
French language manuals at davincifireplace.com.
Manuels de langue Française à davincifireplace.com
$10.00
9/9/24
www.travisproducts.com
100-01597

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 59 GreenSmart and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DaVinci 59 GreenSmart

  • Page 1 DaVinci 59 GreenSmart Electric Fireplace Manual PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND OPERATION. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. INSTALLER: Leave this manual with the appliance. French language manuals at davincifireplace.com. Manuels de langue Française à davincifireplace.com CONSUMER: Retain this manual for future reference.
  • Page 2: Overview

    Introduction Overview This manual details the installation and operation of the DaVinci 59 GreenSmart Electric fireplace. Listing Details This appliance was listed to UL 2021 4 Edition Dedicated Electric Room Heaters / CSA C22.2 No.46-13(R2018) – Electric Air-Heaters. The listing label adhered to the back of the appliance.
  • Page 3: Table Of Contents

    Fireplace Configurations .......... 24   Wiring Diagram ............54     Fuel Bed Uplights ............25 Facing & Mantel Requirements ....... 26     Facing Requirements ............26   Mantel Requirements ............26 © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 4: Safety Precautions

    WARNING: To reduce the risk of fire, electric shock, or injury to persons, always use a licensed electrician. WARNING: In order to avoid overheating, do not cover the heater or air vents located on the appliance or obstruct the air circulation around the appliance. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 5 The adapter should not be used if a three-slot grounded receptacle is available. NOTE: Adaptors are NOT for use in Canada. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 6 State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov WARNING Read this entire manual before proceeding with the installation. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 7: Installation Options

    Optional LED ambient lighting kit (sku#  94400151) Can be installed as a Single Sided, Bay, Left Corner or Right Corner Fireplace Specifications 59 GREENSMART ELECTRIC FIREPLACE Weight (lbs.) Dimensions (inches) H23-1/8” x W59-3/8” x D19-3/8” 120V AC 60Hz Supply Voltage...
  • Page 8: Packing List

    Side Tile Stop (top/bottom) (x4) Remote handset Side Tile Stop (side)( x2) Box 1 Side panel (x2) Box 2 DaVinci 59 GreenSmart Electric Fireplace Log set A Magnetic tool Log Set B Glass Suction Cup Tools (x2) Log Set C...
  • Page 9: Recommended Installation Procedure

    7. Install the hearth (if applicable). Install the mantel (if applicable). 8. Finalize the installation (see page 28). Recommended Specialty Tools  Large Level (or Laser Level)  Outlet tester and/or multi-meter © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 10: Dimensions - Single Sided Configurations

    Installation (for qualified installers only) Dimensions - Single Sided Configurations © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 11 Installation (for qualified installers only) Dimensions – Bay Configuration © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 12 Installation (for qualified installers only) Dimensions – Left Corner Configuration © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 13 Installation (for qualified installers only) Dimensions – Right Corner Configuration © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 14: Minimum Framing Dimensions - Single Sided Configuration

    (for qualified installers only) Minimum Framing Dimensions – Single Sided configuration IMPORTANT If using the optional Ambient Light Kit it must be connected to the fireplace before covering the chase (see pg 34 for details). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 15: Minimum Framing Dimensions - Bay Configuration

    (for qualified installers only) Minimum Framing Dimensions – Bay configuration IMPORTANT If using the optional Ambient Light Kit it must be connected to the fireplace before covering the chase (see pg 34 for details). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 16: Minimum Framing Dimensions - Left Corner Configurations

    (for qualified installers only) Minimum Framing Dimensions – Left Corner configurations IMPORTANT If using the optional Ambient Light Kit it must be connected to the fireplace before covering the chase (see pg 34 for details). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 17: Minimum Framing Dimensions - Right Corner Configuration

    (for qualified installers only) Minimum Framing Dimensions – Right Corner configuration IMPORTANT If using the optional Ambient Light Kit it must be connected to the fireplace before covering the chase (see pg 34 for details). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 18: Hearth Requirements

    A combustible or noncombustible hearth may be installed in front of the fireplace anywhere up to the edge of the fireplace opening. The hearth finish material must not extend above the fireplace opening or it will interfere with the installation and removal of the glass. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 19: Electrical Connection

    NOTE: If using the included power cord make sure that the outlet is “readily accessible”, grounded, and meets all other code requirements. We recommend checking with the local authority having jurisdiction while planning the installation. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 20: Power Cord Installations (120V Only)

    Connect the power cord assembly with the replacement cover plate to the fireplace wire harness.  Reinstall the screws removed in the first step, to secure the cover plate and cord to the fireplace. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 21: Installation

    Insert the fireplace into the framing. Slide the fireplace back until the nailing flanges are pressed up against the front of the framing. c) Screw the flanges to the framing as shown below. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 22 Reinstall the shipping bracket screws to the appliance and discard the shipping bracket.  Using the magnetic tool, lift and remove the glass retaining bar located in front of the glass panel. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 23 See the stickers on the glass panel for guidance. Replace the glass in the reverse order to initial removal, ensuring that both steel plate brackets are fitted and secured using the thumbscrews. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 24: Fireplace Configurations

    Using the removed screws, install (2) of the top/bottom tile stops and (1) side tile stop and screw them to the appliance (see “Bay Configuration” illustration on the following page). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 25: Bay Configuration

    Near the middle of each uplight assembly, there are (2) electrical ports in the fuel bed. Connect the electrical leads from the assemblies to their respective ports as shown below. NOTE: The clip on the electrical connector should be oriented toward the front of the fireplace when oriented properly. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 26: Facing & Mantel Requirements

    Mantel Requirements  A mantel (combustible or non-combustible) may be installed above the fireplace. Make sure it does not overlap the glass opening.  The maximum mantel depth is 12” (305mm). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 27: Tv Installations Above The Fireplace

    There is no maximum depth for a recessed TV installation.  Check with the manufacturer of the Television for any additional installation requirements when their product is installed in proximity to a heat source. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 28: Finalizing The Installation

    Step 3: Position log AI-7 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 29 Position log AI-9 onto the corresponding outline on the fuel bed, locating the peg on the underside of the log into the hole in the fuel bed, and plug the cable into the port on the fuel bed. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 30 Step 11: Position log AA-16 onto the corresponding outline on the fuel bed. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 31 Position log AI-5 onto the corresponding outline on the fuel bed and plug the cable into the port on the fuel bed. Step 15: Position log AD-8 onto the corresponding outline on the fuel bed. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 32 Distribute the black glass embers around the entire fuel bed, placing them over both clear and black resin embers. Do not feel that you need to use all of the black glass embers provided. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 33 Complete the setup by carefully re-fitting the front glass using the suction cup tools provided, then re-fit the glass retaining bar following the steps detailed in the section “Glass Removal” in reverse. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 34: Optional Equipment

    Light Kit is working correctly before the final sheeting and finish has been installed over the framing. Once you are satisfied that the lighting is working correctly with the remote control, the sheeting can be installed, and the finish material applied. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 35: Operation

    Operation Before You Begin  Read this entire manual before you use your new heater (especially the section "Safety Precautions" on pages 4 & 5). Normal Operating Sounds © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 36: Location Of Controls

    Located in the upper right corner of the fireplace, above the glass. Remote Control The remote is included with the appliance Digital Assistants Works with Alexa™ and Google Home™ (Not included) Smart Home App Works with Apple™ and Android™ © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 37: Manual Control Operation

    Press 1 time = fan without heat Press 4 times = no heat/no fan Press 2 times = low heat setting Preset Mode Press repeatedly to cycle through the 6 fire preset modes (+3 user-defined presets if programmed). © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 38: Remote Control Operation

    Flame type A (gas style flame), White FL.1 FL.4 Flame type A (gas style flame), Orange Flame type B (wood burning style flame), Orange FL.2 Flame type A (gas style flame), Yellow © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 39 While in the sound effect menu, press the plus and minus buttons to increase and decrease the volume - 1 bar is the quietest setting, and 5 bars is the loudest setting. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 40: App Control

    App Control There are (2) methods for connecting the fireplace to the DaVinci app. The automatic method allows the app to identify and connect to the fireplace on its own. If for some reason this method does not work, proceed to the next section titled “Manual app installation and setup”...
  • Page 41 , you will also need to ensure your device is connected to the wifi network in your phone settings. Once this is complete the app will begin to connect to the appliance © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 42 Sharing access section. If automatic method was not successful in connecting the fireplace with the app, follow the steps in the next section “Manual App Installation and Setup”. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 43: Manual App Installation And Setup

    Operation MANUAL APP INSTALLATION AND SETUP To connect your Fireplace to the DaVinci app you will need the following.  A device running the Android or iOS operating system such as a tablet or smartphone.  A network within range of the fireplace.
  • Page 44 Once the password has been entered, you will be presented with a checklist to ensure trouble-free connection of your appliance to the network. You may also be asked to allow location permissions, please read, and follow the on-screen prompts. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 45 Now from the list of small home appliances select Heater (Wi-Fi). The app will then prompt you to enter your Wi-Fi password, ensure the correct network is selected, enter your Wi-Fi password, and then press the next button. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 46 When first initiating the pairing, the fuel bed will flash red. Once successfully paired the fuel bed will display green. If a flashing blue fuel bed appears repeat the pairing procedure. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 47 Once paired with the fireplace, the app can be used to control the fireplace. The fireplace will now be shown on the Tuya home screen. Select the appliance to begin using the DaVinci/Fireplace Xtrordinair app. To turn the fireplace on, use the power button as highlighted in the illustration below.
  • Page 48: Advanced Wi-Fi Router Guidance

    If the signal strength is not full, it may indicate a connectivity issue. If they are greyed out or only 1 or 2 bars are showing, then the signal strength of your home network may need boosting in order for your Tuya app to control the appliance. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 49: Voice Control

    Once paired, the following voice commands can be used: NOTE: <my fireplace> refers to the name set for the DaVinci appliance within the smart device settings. This can be changed to suit your preference. Google Device...
  • Page 50 Alexa, turn up volume on <my fireplace> Volume Alexa, turn down volume on <my fireplace> Alexa, set <my fireplace> to 5-104 Set Room Alexa, make it warmer in here Temperature Alexa, make it cooler in here © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 51: Danger High Voltage

    Glass Cleaning The glass may be cleaned with a non-abrasive cleaner. To clean the inside of the glass, remove the glass, place it on a non-scratching surface, and clean the inside surface. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 52: Troubleshooting

    Overheating may have engaged the E.S.C. feature. Heat turns off   Open window detection Check that any windows in the room are closed. before desired temperature is has been activated. reached. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 53: Replacement Parts List

    DAVINCI 59 GSE - WIRING INLET BOARD# 250-06694 DAVINCI 59 GSE - POWER CORD# 250-06695 DAVINCI 59 GSE - RETAINING BRKT# 250-06696 Contact your local DaVinci™ fireplace dealer to purchase replacement parts. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 54: Wiring Diagram

    Maintenance (for qualified technicians only) Wiring Diagram Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 55: Limited Warranty

    WITHIN 30 DAYS, giving them proof of purchase, the purchase date, and the model name and serial number. 2. Travis Industries, Inc. has the option of either repairing or replacing the defective component. © Travis Industries 9/9/2024 - 1597 59 GreenSmart...
  • Page 56 Voice Control Operation ........49 Installation ............21 Wiring Diagram ..........54 Installation Options ..........7 Yearly Service Procedure ........ 51 Location of Controls ......... 36 Log and Media Installation ....... 28 © Travis Industries 10/10/2023 - 1592 59 GreenSmart...
