SELF-CONTAINED CUBER
INSTRUCTION MANUAL
(original instructions)
FOR END USER
No. 15 Qingqiu Street, Suzhou Industrial Park, Suzhou 215126 China
IM-45CNS
IM-65NS
IM-65NS-Q
IM-65NS-LM
IM-100CNS
L1M141101 (011025)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM-45CNS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hoshizaki IM-45CNS

  • Page 1 IM-45CNS SELF-CONTAINED CUBER IM-65NS IM-65NS-Q IM-65NS-LM IM-100CNS INSTRUCTION MANUAL (original instructions) FOR END USER No. 15 Qingqiu Street, Suzhou Industrial Park, Suzhou 215126 China L1M141101 (011025)
  • Page 2: Table Of Contents

    ENGLISH IMPORTANT SAFETY INFORMATION ....................1 I. INSTALLATION INSTRUCTIONS ......................3 1. CONSTRUCTION .........................3 2. ACCESSORIES ..........................3 3. UNPACKING ..........................4 4. LOCATION ...........................5 5. INSTALLATION ..........................5 6. ELECTRICAL CONNECTIONS ....................6 7. WATER SUPPLY AND DRAIN CONNECTIONS .................6 II. OPERATING INSTRUCTIONS ......................8 1. START UP ............................8 2.
  • Page 3: Important Safety Information

    ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury.
  • Page 4 * If the supply cord is damaged, it must be replaced by a replacement cord available from Hoshizaki Parts/Service Centres. * Do not touch the electrical parts or operate the switches with damp hands. * This appliance is not intended for use by persons (including children) with reduced physical,...
  • Page 5: Installation Instructions

    Air Filter Bin Door Handle Storage Bin Front Panel Bin Door (Lower) Front Panel Air Filter Louver (Lower) Power Cord Louver [IM-45CNS] [IM-100CNS] 2. ACCESSORIES IM-45CNS IM-100CNS IM-65NS-Q IM-65NS-LM Scoop Inlet Hose Outlet Hose 1/2-3/4 Nipple Connector Cover 3/4-3/4 Nipple...
  • Page 6: Unpacking

    4) Remove the package of accessories. Check the contents according to “2. ACCESSORIES”. 5) Remove the shipping tape holding the bin control switch by opening the bin door and reaching in. Bin Control Switch Bin Door [IM-65NS,-65NS-Q,IM-65-LM] Bin Control Switch Bin Control Switch Bin Door Bin Door [IM-100CNS] [IM-45CNS]...
  • Page 7: Location

    ENGLISH 4. LOCATION WARNING This icemaker is not intended for outdoor use. The icemaker should not be located next to ovens, grills or other high heat producing equipment. This appliance is not suitable for installation in an area where a water jet could be used. CAUTION The location should provide a firm and level foundation for the icemaker.
  • Page 8: Electrical Connections

    Supply or Water Fittings Regulations. * Icemaking water must be potable water. Where scaling can be caused by water quality: - Installation of an external filter or softener is recommended. Contact your local water treatment professional or Hoshizaki service agent.
  • Page 9 ENGLISH * Water supply pressure should be minimum 0.07 MPa (0.7 bar) and maximum 0.78 MPa (8 bar). If the pressure exceeds 0.78 MPa (8 bar), use a proper pressure reducing valve. Do NOT throttle back the supply tap. * A plumbing permit and services of a licensed plumber may be required in some areas. * The icemaker drain is gravity flow, so ensure drain hose has an adequate pitch or fall.
  • Page 10: Operating Instructions

    ENGLISH II. OPERATING INSTRUCTIONS CAUTION Do not put your hands into the back of the storage bin or the ice chute on top of the storage bin. Ice may drop off the icemaker, Ice Chute a hard block of ice may suddenly break down, or the icemaking mechanism may suddenly move, resulting in injury. Storage Bin NOTICE All parts are factory-adjusted.
  • Page 11: Maintenance

    1) Either mix 1 litre of water with 4 ml of 5.25% sodium hypochlorite solution in a suitable container, or the recommended Hoshizaki sanitiser as directed. 2) Soak the scoop in the solution for more than 3 minutes. Rinse thoroughly, and shake to remove surplus liquid.
  • Page 12: Before Calling For Service

    1) Slide the air filter off the the louver . 2) Clean the air filter by using a vacuum cleaner. When severely clogged, use warm water and a neutral cleaner to wash the air filter. 3) Rinse and dry the air filter thoroughly. NOTICE After cleaning, be sure to place the air filter back in position. Air Filter Louver Air Filter [IM-45CNS] [IM-65NS-Q] [IM-65NS-LM] Louver [IM-100CNS] 2. BEFORE CALLING FOR SERVICE WARNING Do not damage the refrigerant circuit. [a] Error Code Indication If the error code “E” is indicated on the display, before calling for service, check the following.
  • Page 13: Disposal

    4. WARRANTY Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or workmanship for the duration of the “warranty period”. The warranty shall be effective for two years from the date of installation. Hoshizaki’s liability under the terms of the warranty are limited and shall exclude routine servicing, cleaning, essential maintenance and/or repairs occasioned by misuse and installations not in accordance with Hoshizaki guidelines.
  • Page 14: Specifications

    ENGLISH SPECIFICATIONS Model IM-45CNS IM-65NS-Q Type Air-cooled, cube ice Air-cooled, cube ice Power Supply 1 phase 220 - 240V 50Hz 1 phase 220 - 240V 50Hz Electric Consumption 360W 370W Ice Production per 24h 41kg (5mm) / 46kg (15mm) 26kg (6mm) (ambient 10°C, water 10°C)
  • Page 15 ENGLISH Model IM-65NS IM-65NS-Q Type Air-cooled, cube ice Air-cooled, cube ice Power Supply 1 phase 220V 60Hz 1 phase 220V 60Hz Electric Consumption 370W 370W Ice Production per 24h 55kg (5mm) / 62kg (15mm) 28kg (6mm) (ambient 10°C, water 10°C) (ambient 10°C, water 10°C) Dimensions 633mm(W) x 506mm(D) x 840mm(H)
