Service Manual
Modular Flaker
Models
F-450 to 1002M_J(Z)(-C)(-SC)
FD-650 to FD-1002M_J(Z)(-C)(-CB)
N-2, N-3 and Later Auxiliary Codes
hoshizakiamerica.com
Number: 73253
Issued: 5-22-2024
Revised: 9-23-2024
