- Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLFZ224-SS01A...
-
Page 2: Warranty Registration
Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed prod- uct at marketing@marvelrefrigeration.com, and we might... -
Page 3: Table Of Contents
TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety Compressor Specifications Important Safety Instructions Troubleshooting Extended Control Operation - Service Installation Service Mode Unpacking Your Appliance Thermistor Electrical Defrost Cutout & Product Dimensions Remove Fan and Cover Installing Your Appliance Warranty Side-by-Side &... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize Safety Symbols, Words and Labels WARNING... -
Page 5: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the Use two or more people to move product. appliance to sit upright for a period of at least 24 hours Failure to do so can result in personal injury. -
Page 6: Electrical Shock Hazard
ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be Do not remove plugged into a mating grounding type receptacle in ground prong accordance with the National Electrical Code and applicable local codes and ordinances. -
Page 7: Cutout & Product Dimensions
CUTOUT & PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 24” 34” to 35” 24” 23 7/8” 33 3/4” to 34 3/4” 23 5/8” 25 1/2” 46 3/8” 25 3/4” (61 cm) (86.4 cm to 88.9 cm) (61 cm) (60.7 cm) - Page 8 CUTOUT & PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 140 lbs 115V/60Hz/15A (63.6 kg) “H” “D” “F” “E” Solid Door 21 1/2” 3 1/2” (8.9 cm) (54.6 cm) Shown Minimum Minimum rough-in opening is required to be larger than the adjusted height of the cabinet.
-
Page 9: Installing Your Appliance
The could result in personal injury. Contact your dealer or overall height of your Marvel appliance may be adjusted Marvel customer service at 616-754-5601 to order. higher (by turning the leveling leg out, CCW) and lower (by For safety concerns 15"... -
Page 10: Side-By-Side & Stacking Installations
SIDE-BY-SIDE & STACKING INSTALLATION Side-by-Side Installation Stainless steel models which include the standard stainless handle will require 4 9/16” (116 mm) to allow both doors to Other Site Requirements open to 90° at the same time. Units must operate from separate, properly grounded elec- trical receptacles places according to each unit’s electrical 4 9/16”... -
Page 11: Installing The Anti-Tip Device
INSTALLING THE ANTI-TIP DEVICE Anti-Tip WARNING Bracket Leveling Leg • ALL APPLIANCES CAN TIP RESULTING IN INJURY. • INSTALL THE ANTI-TIP Bottom View of " BRACKET PACKED WITH Appliance (54.6 cm) THE APPLIANCE. • FOLLOW THE INSTRUCTIONS BELOW Front of cabinet Anti-Tip Device Step by step instructions for locating the po- WARNING... - Page 12 INSTALLING THE ANTI-TIP DEVICE NOTE When the floor mounted anti-tip bracket is used the minimum adjusted height of the cabinet is increased by " (9 mm). "V" notches Rear Leveling leg in bracket Screw " (54.6 cm) "V" notches in bracket...
-
Page 13: Door Reversing Instructions
DOOR REVERSAL Door Reversing Instructions Tools Needed: • 1/8” Hex Key • 5/32” Hex Key • Phillips Screwdriver 1. Open door and remove hinge pin from the upper hinge using a 1/8” hex key tool, making sure to steady the door. Slowly remove the door from the upper hinge and lift to remove off the base lower hinge. - Page 14 DOOR REVERSAL 6. Remove the toe kick from the door and attach it to the opposite side. Toe Kick Reversal 7. Reattach the upper and lower hinges, and hinge brackets to opposite sides. Then install the door.
-
Page 15: Using Your Electronic Control
• Close door to silence alert and reset etc. Marvel recommends allowing the unit to reach set points before loading. High/Low Temp. Notifications When the compartment temperature exceeds the control setting for an extended amount of time: •... -
Page 16: Loading Tips And Suggestions
INTERIOR ADJUSTMENTS Loading Tips and Suggestions Your appliance is equipped with a cantilever shelf and basket system which provides maximum adjustability and customizing of the storage arrangements listed below. To remove the basket: Press this tab on each side of the basket slide and pull the basket out of the slides. -
Page 17: Care And Cleaning
CARE & CLEANING Front Grille Be sure that nothing obstructs the required air flow openings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille are. CAUTION SHOCK HAZARD: Disconnect electrical power from the appliance before cleaning with soap and water. -
Page 18: Stainless Steel Maintenance
STAINLESS STEEL MAINTENANCE Background NOTE Stainless steel does not stain, corrode, or rust as easily as ordinary steel, but it is not stain or corrosion proof. Stainless steels can discolor or corrode if not maintained Stainless steel products should never be installed, or stored properly. -
Page 19: Energy Savng Tips
ENERGY SAVING TIPS The following suggestions will minimize the cost of operating your refrigeration appliance. 1. Do not install your appliance next to a hot appliance (cooker, dishwasher, etc.), heating air duct, or other heat sources. 2. Install product out of direct sunlight. 3. -
Page 20: Service
Winterization If the unit will be exposed to temperatures of 40° F (5° C) or less, the steps above must be followed. For questions regarding winterization, please call Marvel at (616) 754-5601. CAUTION Damage caused by freezing temperatures is not covered... -
Page 21: If Service Is Required
OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •... -
Page 22: Before Calling For Service
• Compressor: The compressor makes a hum or pulsing- sound that may be heard when it operates. If you think your Marvel product is malfunctioning, read the • Evaporator: Refrigerant flowing through an evaporator- Control Operation section to clearly understand the may sound like boiling liquid. -
Page 23: Checking Product Temperature
TROUBLESHOOTING Checking Product Temperature Causes which affect the internal temperatures of the cabinet include: • Temperature setting. • Ambient temperature where installed. • Installation in direct sunlight or near a heat source. • The number of door openings and the time the door is open. -
Page 24: Wire Diagram
WIRE DIAGRAM Freezer Thermistor Evap Fan Freezer Evap Thermistor Evap Heater Door Switch Interior LED RD/BK Compressor Programming Port DIAGNOSTICSS VCC CONTROL User Interface USER INTERFACE N L 1 2 3 4 5 6 Condenser Fan... -
Page 25: Product Liability
The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part. -
Page 26: Warranty Claims
Final billing - Remodel • 60 day submittal deadline from date of completed service Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial • Only one repair or unit per warranty claim number, part number and part description. -
Page 27: Ordering Replacement Parts
Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information. -
Page 28: R600A Specifications
R-600a is heavier than air, do not allow any leakage/migra- tion to low areas such as basements and stairs. Never use a torch on a fully charged refrigeration system. Never substitute Marvel OEM replacement parts or methods of construction. R-600a must be stored and transported in approved... - Page 29 R600A SPECIFICATIONS R-600A Specifications/Labeling WARNING R-600a equipped products are labeled (both the unit and the compressor). Only skilled and well trained service technicians R-600a is colorless and odorless. permitted to service R-600a equipped products. R-600a is considered non-toxic, but is flammable when All tools and equipment must be approved for use with mixed with air.
-
Page 30: Leak Detection
R600A SPECIFICATIONS Evacuate/reclaim via the piecing pliers to ensure the When re-brazing, the system must be purged with system is empty of R-600a before any system work is nitrogen and at least one access point open to the performed. atmosphere. When re-brazing, proper ventilation is required along with constant monitoring for the presence of R600a refrigerant. - Page 31 R600A SPECIFICATIONS The low side of the refrigeration system (evaporator, compressor and suction line) must be leak tested with the compressor off (equalized pressure). Recharging No air is ever to be allowed inside the refrigeration system (R-600a refrigerant or dry nitrogen only). Never use a torch on a fully charged refrigeration system.
-
Page 32: System Diagnosis Guide
SYSTEM DIAGNOSIS GUIDE Refrigeration System Diagnosis Guide System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold... -
Page 33: Compressor Specifications
COMPRESSOR SPECIFICATIONS EMC46CLC WARNING Refrigerant R600A Electrocution can cause death or serious injury. Burns Voltage 115 VAC from hot or cold surfaces can cause serious injury. Frequency 60 Hz Take precautions when servicing this unit. Start Winding 5 Ohm at 77°F Disconnect the power source. -
Page 34: Troubleshooting Extended
Evaporator: Refrigerant flowing through an evaporator Included in this section are some diagnostic tips; if may sound like boiling liquid. additional help is required, please contact Marvel at • Condenser Fan: Air moving through a condenser may 616.754.5601 for assistance. - Page 35 TROUBLESHOOTING EXTENDED...
-
Page 36: Main Control
TROUBLESHOOTING EXTENDED Main Control CAUTION The main control board is very robust and is rarely the cause of system issues. It is important to fully diagnose the board for any suspected failures before attempting Precautions must be taken while working with live to remove the board for replacement or service. -
Page 37: Control Operation-Service
CONTROL OPERATION-SERVICE UI Button Layout Control Function Guide Function Command Display/Options ON/OFF Press Unit will immediately release turn ON or OFF 1. Hidden Button Sabbath Mode See "Sabbath -Access Service Menu Mode" section -No LED directly above. All LEDs turn on with button 2. -
Page 38: Service Mode
SERVICE MODE Service Mode Guide 1. THERMISTOR 1 — ZONE This shows the pure thermistor reading with no offsets 0. Exit taken into account. 1. Thermistor 1 temperature not including offsets. 2. THERMISTOR 2 — EVAPORATOR 2. Thermistor 2 temperature not including offsets. This shows the pure thermistor reading with no offsets 3. - Page 39 SERVICE MODE 15: CLEAR ERROR LOG To clear errors, press and hold (5 seconds) when CLR is flashing. 16: THERMISTOR - 1 DIFFERENTIAL This number should not be adjusted. 17. Does not apply to this model. 18. THIS NUMBER SHOULD NOT BE ADJUSTED 19.
-
Page 40: Thermistor Failure
THERMISTOR Thermistors Evaporator Thermistor Thermistors are used for various temperature readings. If the evaporator thermistor fails, the unit will rely on a Thermistors provide reliable temperature readings using a preset defrost timer during defrost cycles. The unit will resistance which varies based on surrounding otherwise operate normally. -
Page 41: Defrost
DEFROST Defrost This unit defrosts every 8 hours of compressor runtime for 60 minutes. If you have verified that the unit does not have an ambient air leak, utilize the Control Operation - Service section and adjust unit to defrost every 6 hours for 60 minutes. -
Page 42: Convection Cooling
REMOVE FAN & COVER Convection Cooling This unit is equipped with an advanced convection cooling system. Convection cooling stabilizes cabinet temperature, cools product faster and increases energy efficiency. Evaporator Fan The evaporator fan is responsible for circulating warm air from the refrigeration zone, past the evaporator and back into the refrigerated zone. - Page 43 REMOVE FAN & COVER NOTE Fan must be oriented to pull air in through lower evaporator cover vents and push air out at fan mounting location. 10. Installation is the reverse of removal. 11. Care must be taken to assure the bottom of the evaporator cover is reinstalled behind the front edge of the train trough.
-
Page 44: Warranty
For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase. - Page 45 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
