O W N E R ' S G U I D E
O W N E R S G U I D E
M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N
M A R V E L U N D E R C O U N T E R R E F R I G E R A T I O N
F O R M O D E L # M L R F 2 2 4
F O R M O D E L # M L R E 2 2 4
T H E O R I G I N A L R E F R I G E R A T I O N E X P E R T S S I N C E 1 8 9 2
T H E O R I G I N A L R E F R I G E R A T I O N E X P E R T S S I N C E 1 8 9 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Marvel MLRF224-SS01A
Summary of Contents for Marvel MLRF224-SS01A
- Page 1 O W N E R ' S G U I D E O W N E R S G U I D E M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N M A R V E L U N D E R C O U N T E R R E F R I G E R A T I O N F O R M O D E L # M L R F 2 2 4 F O R M O D E L # M L R E 2 2 4...
- Page 2 Got a Marvelous Design? The service number and serial number can be found on the We would love to see how your Marvel product looks in its serial plate which is located inside the cabinet on the left new home. Send us photos at marketing@marvelrefrigera- side near the top.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety Important Safety Instructions Installation Unpacking Your Appliance Electrical Installing The Water Supply Maintenance Care and Cleaning Stainless Steel Maintenance Extended Non-Use Operating Instructions Ice Maker Operation Interior Adjustments Energy Savng Tips Service... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situa- tions that may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operat- ing this appliance. -
Page 5: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE CAUTION WARNING If the appliance was shipped, handled, or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the ap- Use two or more people to move product. pliance to sit upright for a period of at least 24 hours before Failure to do so can result in personal injury. -
Page 6: Electrical
ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in accor- dance with the National Electrical Code and applicable lo- Do not remove cal codes and ordinances (see Figure 4). -
Page 7: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Supply CAUTION Observe and follow all local building codes when installing this appliance. " outside diameter copper tubing for your Water line from water water supply which is available at any local hard- valve to ice-maker ware or plumbing supply store. -
Page 8: Ice Maker Operation
ICE-MAKER OPERATION CAUTION The water supply to the ice-maker must be turned on prior to turning the ice-maker on. Failure to do so will cause rapid dry cycling of the ice-maker mold heater resulting in temperature control issues in the freezer compartment. Ice-maker operation •... -
Page 9: Interior Adjustments
INTERIOR ADJUSTMENTS CAUTION Make sure your cantilever shelf is secure on the shelf supports by pressing down on the shelf before loading. Freezer: CAUTION Figure 27. Never try to move a loaded shelf, remove every- thing from the shelf before moving. Use both hands when moving the shelf. - Page 10 CARE AND CLEANING Front Grille The following suggestions will minimize the Be sure that nothing obstructs the required air flow open- cost of operating your refrigeration appliance. ings in front of the cabinet. At least once or twice a year, 1.
- Page 11 STAINLESS STEEL MAINTENANCE Background NOTE Stainless steel does not stain, corrode, or rust as easily as ordinary steel, but it is not stain or corrosion proof. Stain- less steels can discolor or corrode if not maintained prop- Stainless steel products should never be installed, or stored erly.
-
Page 12: Energy Savng Tips
ENERGY SAVING TIPS The following suggestions will minimize the cost of operating your refrigeration appliance. 1. Do not install your appliance next to a hot appliance (cooker, dishwasher, etc.), heating air duct, or other heat sources. 2. Install product out of direct sunlight. 3. - Page 13 Winterization If the unit will be exposed to temperatures of 40° F (5° C) or less, the steps above must be followed. For questions regarding winterization, please call Marvel at (616) 754-5601. CAUTION Damage caused by freezing temperatures is not covered...
-
Page 14: Obtaining Service
OBTAINING SERVICE If Service is Required: • If the product is within the first year warranty period please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. •... - Page 15 White light (upper & lower) Blue light (upper & lower) Evap fan Evap fan Condenser fan Zone temp Evap temp Zone temp Evap temp Door switch 1 Defrost Heater Door switch 2 Compressor / Condenser Power In N.C. Neutral FUSE...
-
Page 16: Product Liability
The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part. -
Page 17: Warranty Claims
Claims must be submitted online at • Final billing - Remodel www. marvelservice . co m Warranty parts will be shipped at no charge after Marvel • 60 day submittal d eadline from date of completed confirms warranty status. Please provide the model, serial service number, part number and part d escription. -
Page 18: Ordering Replacement Parts
Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information. -
Page 19: R600A Specifications
PERSONNEL DO HOT PUNCTURE REFRIGERANT TUBING refrigeration system. RISK Of FIRE OR EXPLOSION. FIAMHA_ B LE REFRIGERANT USED. CONSULT Never substitute Marvel OEM replacement parts REPAIR IIANUAVOWHER'S GUIDE BEFORE ATTEMPTING TO SERVICE THIS PRODUCT. ALL SAFETY PRECAUTIONS HUST BE FOUOWEO. - Page 20 R-600A SPECIFICATIONS/LABELING WARNING R-600a equipped products are labeled (both the unit and the compressor). Only skilled and well trained service technicians permitted to service R-600a equipped products. R-600a is colorless and odorless. All tools and equipment must be approved for use with R-600a refrigerant.
- Page 21 Evacuate/reclaim via the piecing pliers to ensure the When re-brazing, the system must be purged with dry system is empty of R-600a before any system work is nitrogen and at least one access point open to the performed. atmosphere. When re-brazing, proper ventilation is required along with constant monitoring for the presence of R600a refrigerant.
- Page 22 The low side of the refrigeration system (evaporator, Proper ventilation during service is required. compressor and suction line) must be leak tested with the compressor off (equalized pressure). Never apply a torch to a charged R-600a refrigeration system. RECHARGING No air is ever to be allowed inside the refrigeration system Use OEM replacement service parts and do not alter the (R-600a refrigerant or dry nitrogen only).
-
Page 23: System Diagnosis Guide
System Diagnosis Guide REGRIGERATION SYSTEM DIAGNOSIS GUIDE System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold... -
Page 24: Compressor Specifications
Compressor Specifications EMC46CLC REFRIGERANT R600A DANGER VOLTAGE 115 VAC FREQUENCY 60 Hz START WINDING 5 Ohm at 77 ° Electrocution can cause death or serious injury. RUN WINDING 7 Ohm at 77 ° Burns from hot or cold surfaces can cause serious 12 Ohm at 77 °... -
Page 25: Control Operation-Service
Control Operation-Service CONTROL FUNCTION GUIDE FUNCTION COMMAND DISPLAY/ OPTIONS UI BUTTON LAYOUT Unit will immediately Press � and release ON/OFF turn ON or OFF Sabbath Mode See "Sabbath Mode" section Hidden Button SHOWROOM MODE -Access Service Menu This mode is designed to show units in a display -No LED directly above. - Page 26 For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
- Page 27 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 41015887 Rev A All specifications and product designs subject to change without notice. Such revisions do not entitle 12/14/20 the buyer to corresponding changes, improvements, additions, replacements or compensation for...
