Description
The AKG Model C 417 is an extremely smooth
omnidirectional microphone intended to be worn by speakers
who demand highest audio quality and complete freedom of
movement. It is one of the smallest lavalier microphones
available today and is available in both black and beige
versions for ultimate concealing. Frequency response
extends from 20 Hz to 20 kHz, with a 4 dB rise at 8 kHz for
enhanced intelligibility.
The C 417 can handle sound pressure levels of 126 dB
with only 3% THD and operates with phantom powering over
a range from 9 to 52 Vdc. The C417 has a 10 ft. (3-meter)
cable that is terminated in an XLR-M connector for phantom
powering. The C 417/L has a 5 ft. (1.5-meter) cable
terminated in a mini-XLR-F connector for use with the B 29 L
battery power supply/mixer, MPAIII phantom power adapter,
or with PT 40, -61, -80, -81 wireless transmitters.
Specifications
Transducer Principle:
Pre-polarized condenser
Frequency Range:
20–20,000 Hz
Polar Pattern:
Omnidirectional
Sensitivity at 1,000 Hz: 10 mV/Pa = ^ -40 dB
Equivalent Noise Level: 32.4 dB (DIN 45 412)
Sound Pressure Level for 1% THD:
118 dB (for 3 % THD: 126 dB)
S/N Ratio (A-weighted): 60 dB
Electr. Impedance:
200 ohms
Load Impedance:
≥ 1,000 ohms
Power Requirement:
9–52 V phantom power (DIN 45596) or
battery powering from B 29 L, or AKG
bodypack transmitters
Connectors:
C417/B: 1/8" mono jack
C417: 3-pin XLR type
C417/L: 3-pin miniature XLR
Finish:
Matte black or beige
Size:
Dia 0.3 in. (7.5 mm)
Length 0.5 in. (15 mm)
Net Weight:
C 417/L: 0.3 oz. (8 g)
C 417: 0.3 oz. (8 g)
Shipping Weight:
C 417/L: 5.9 oz. (160 g)
C 417: 8 oz. (220 g)
Included Accessories : W 407 Windscreen
H 40/1 Tie clip
H 41 Tie pin
Optional Accessories: B 29 L Battery power supply
(for C 417 L)
MPAIII Phantom adapter
(for C 417 L)
MicroMic II Condenser Lavalier Microphones
C 417
Features
• Ultra-slim profile and matte black
or beige finish for unobtrusive
wearing
• Extended low and high frequency
response
• Omnidirectional pattern for natural
speech quality
• High sensitivity (10 mV/Pa)
• High acoustic level capability
(126 dB-SPL for 3% THD)
