44 - 50 - 60 - 72 - 82
OWNERS MANUAL
Read and understand this entire owner's manual, including all safety
WARNING
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
SPECTRUM SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EF-36WM and is the answer not in the manual?

Questions and answers

Related Manuals for evolution fires EF-36WM

Summary of Contents for evolution fires EF-36WM

  • Page 1 SPECTRUM SERIES 44 - 50 - 60 - 72 - 82 OWNERS MANUAL Read and understand this entire owner’s manual, including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury. Keep this owner’s manual for future reference.

  • Page 2: Table Of Contents

    IMPORTANT SAFETY INFORMATION! TABLE OF CONTENT Important safety information! WARNING Parts and hardware When using electrical appliances basic precautions should always be followed to reduce the risk of fire, Specification and dimension electric shock and injury to persons, including thefollowing: READ ALL THE INSTRUCTIONS BEFORE USING THIS APPLIANCE Fire installation This heater is hot when in use.

  • Page 3: Parts And Hardware

    Do not cut the plug off the power cable, this also applies to fuse spares. If the plug is removed 43.3" 19.1" 7.9" 42.2" 18.3" 10.1" 43.1" EF-42WM 110.2cm 48.4cm 20cm 107.22cm 46.56cm 25.61cm 109.6cm Evolution Fires will no longer honor the warranty. 50" 19.1" 7.9" 48.9" 18.3" 10.1" 49.8" EF-50WM 127cm 48.4cm 20cm 124.2cm 46.56cm 25.61cm 126.57cm The frame of the media wall must be hollow allowing air flow to reach the fire.

  • Page 4: Media Wall Airflow & Ventallation

    MEDIA WALL AIRFLOW & VENTALLATION INSTALLATION OVERVIEW Your appliance allows for three installation configurations. IMPORTANT! MORE AIR FLOW MORE HEAT If your are hiring a company to build your media wall or building your own follow the steps below to ensure the electric fire works efficiently without overheating.

  • Page 5: Installation - Minimum Clearances

    INSTALLATION - MINIMUM CLEARANCES OPERATION Your appliance is a recessed and/or mantel installed appliance. Select a suitable location that is not Please read the entire owner’s manual, including all safety information, before plugging in susceptible to moisture build-up. It must be located with enough distance away from flammable or using this product.

  • Page 6: Installation Rough Framing

    INSTALLATION ROUGH FRAMING INSTALLATION PLASTERBOARD FRAMING DIMENSIONS (MM) MODEL NAME EF-36WM EF-42WM 1107 EF-50WM 1275 EF-60WM 1529 PLASTERBOARD RECESS DIMENSIONS (MM) EF-72WM 1833 MODEL NAME 2087 EF-82WM EF-36WM Note EF-42WM 1132 The appliance is not load bearing. Carefully consider weight of finishing materials when constructing...

  • Page 7: Installation Preparation

    INSTALLATION PREPARATION INSTALLATION CHOOSE YOUR VIEWING STYLE EF- 36”, 42”, 50” models have 4 brackets and 8 screws. EF-60”, 72”, 82” models have 6 brackets and 12 Attach the relevant side panels or side trims to achieve your look. screws. Follow instructions below for your relevant model: One sided 1.

  • Page 8: Side Lights Installation

    INSTALLATION OF THE FRONT GLASS PANEL SIDE LIGHTS INSTALLATION Firstly remove the 4 screws which are fitted into the fireplace as shown Install the side lights as shown below. Side Light Colour Options Please Note: Unpack the glass screen, place it into the bottom tray and push backwards until the 4 tabs on the glass The side lights can only be used on media wall designs when the media wall build is wider than the fire, screen line up with screw holes.

  • Page 9: Log-Set / Crystal Ember Media Bed Installation

    LOG-SET / CRYSTAL EMBER MEDIA BED INSTALLATION OPERATION NOTE: It is strongly recommended that the mounting bracket be screwed into at least 2 wall studs. Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, The glass front must be removed and the appliance must be mounted in its final location before the fire,serious injury, or death.

  • Page 10: Touch Panel Operation

    REMOTE CONTROL FUNCTIONS TOUCH PANEL OPERATION BUTTON FUNCTION ACTION&INDICATION ON: Enables control panel functions and remote 1. Press once. Indicator light turns on. Power turns on. control. Turns on flame effect. All functions enabled. OFF: Disables control panel functions and remote 2.

  • Page 11: Operation

    OPERATION REMOTE CONTROL OPERATION Read and understand this entire owner’s manual, including all safety information, before BUTTON FUNCTION ACTION & INDICATION plugging in or using this product. Failure to do so could result in electric shock, fire, serious COLOR button: Makes the color flame effect 1.Press once.

  • Page 12: Set Current Day And Time

    TIMER SETTINGS ON REMOTE CONTROL 2 Set ON/OFF time and temperature on a weekly cycle Timer: Displays current day, time, and week. Press to enter or confirm Press . When “MON” begins flashing, press 3 times. When “ON” begins flashing, use timer settings.

  • Page 13: Cleaning And Maintenance

    Open window warning CLEANING AND MAINTENANCE If the room temperature decreases by 10 degrees within 3 minutes, the appliance will assume there is Cleaning an open window nearby. In order to conserve energy, the heater will automatically switch from High Heat to Low Heat, or if the heater is already at Low Heat, it will turn off completely.

  • Page 14: Troubleshooting/ Faq

    TROUBLESHOOTING/ FAQ Electrical and Moving Parts: The fan motors are lubricated at the factory and will not require lubrication. Electrical components are integrated in the fireplace and are not serviceable by the consumer. Problem Note Possible Cause Solution Storage: Store fireplace in a clean dry place when not in use. Fire not turning on Fire not plugged in or Check plug is correctly fitted...

  • Page 15: Product Warranty

    Heater cutting out If problem persists, the Build-up of hot air Ensure inlets and outlet are free installation will need from obstruction and there are assessed to ensure it sufficient clearances surrounding adheres to all required the unit. minimumclearances as stated in this manual.

This manual is also suitable for:

Ef-42wmEf-50wmEf-60wmEf-72wmEf-82wm
