Evervue 60 - 72
OWNERS MANUAL
WARNING
CAUTION
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
Advertisement
Table of Contents
Related Manuals for evolution fires Evervue 60
Summary of Contents for evolution fires Evervue 60
- Page 1 Evervue 60 - 72 OWNERS MANUAL Read and understand this entire owner’s manual, including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury. Keep this owner’s manual for future reference. If you sell or give this CAUTION product away, make sure this manual accompanies this product.
-
Page 2: Table Of Contents
TABLE OF CONTENT Important safety information! Parts and hardware Specification and dimension Fire installation Media wall airflow & ventallation Installation rough framing Installation - minimum clearances Operation Installation rough framing Installation plasterboard Installation preparation Installation choose your viewing style Side lights installation Installation of the front glass panel Log-set / crystal ember media bed installation Operation... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION! WARNING When using electrical appliances basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including thefollowing: READ ALL THE INSTRUCTIONS BEFORE USING THIS APPLIANCE This heater is hot when in use. To avoid burning, do not touch hot surface. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 1 m from the front of the heater and keep them away from the sides and rear. -
Page 4: Parts And Hardware
PARTS AND HARDWARE A – Fireplace Bracket 2 D-Remote Control Bracket 1 Log Set Small Crystals Coal Virmiculite SPECIFICATION AND DIMENSION PRODUCT DIMENSIONS Model Number 59" 20" 59" 9 1/2" 20" 15" 59" EFEV60 EFEV72 9 1/2" 72" 20" 72" 20"... -
Page 5: Fire Installation
Do not cut the plug off the power cable, this also applies to fuse spares. If the plug is removed Evolution Fires will no longer honor the warranty. The frame of the media wall must be hollow allowing air flow to reach the fire. If there is not enough airflow getting to the fire you will find your fire switches off when the heater is used. -
Page 6: Media Wall Airflow & Ventallation
MEDIA WALL AIRFLOW & VENTALLATION IMPORTANT! MORE AIR FLOW MORE HEAT If your are hiring a company to build your media wall or building your own follow the steps below to ensure the electric fire works efficiently without overheating. Leaving a letterbox cutout above the fire will ensure maximum airflow to the fire increasing its efficiency and will also prevent overheating. -
Page 7: Installation Overview
INSTALLATION OVERVIEW Your appliance allows for three installation configurations. One Sided One Sided Glass exposed on the front only. Glass exposed on the front only. Three Sided Glass exposed on the front, left and right sides. -
Page 8: Operation
OPERATION Please read the entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury. Power Plug the power cord into a 220-240V 50Hz outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). -
Page 9: Installation - Minimum Clearances
INSTALLATION - MINIMUM CLEARANCES Your appliance is a recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture build-up. It must be located with enough distance away from flammable materials such as curtains, furniture and high traffic areas. Note Follow all local and national electrical regulations/codes. -
Page 10: Installation Preparation
INSTALLATION PREPARATION EF- 36”, 42”, 50” models have 4 brackets and 8 screws. EF-60”, 72”, 82” models have 6 brackets and 12 screws. Follow instructions below for your relevant model: 1. Remove the 8 (or 12) silver screws on 2. Install the 4 (or 6) ‘L shape’ metal the top and bottom of the appliance, brackets using the 8 (or 12) screws see figure 3-1. - Page 11 INSTALLATION OF THE FRONT GLASS PANEL Firstly remove the 4 screws which are fitted into the fireplace as shown Unpack the glass screen, place it into the bottom tray and push backwards until the 4 tabs on the glass screen line up with screw holes. Screw in the 4 screws which were removed in the first step.
- Page 12 Flame colors and patterns switching.
-
Page 14: Installation Of The Front Glass Panel
Installation of the front glass panel Firstly remove the 4 screws which are fitted into the fireplace as shown Unpack the glass screen, place it into the bottom tray and push backwards until the 4 tabs on the glass screen line up with screw holes. Screw in the 4 screws which were removed in the first step. -
Page 15: Log-Set / Crystal Ember Media Bed Installation
Log-set / Crystal Ember Media Bed Installation NOTE: Please use the information below to set out your media set based on the model you purchased. The glass front must be removed and the appliance must be mounted in its final location before the log-set / crystals are installed. -
Page 16: Two Sided
INSTALLATION CHOOSE YOUR VIEWING STYLE Attach the relevant side panels or side trims to achieve your look. One sided One sided Side Panel Side Panel two sided DESIRED CLOSED Two sided SLDE DESIRED CLOSED SLDE Side Panel Side Trim Three sided Three sided Side Trim Side Trim... - Page 17 User Guide (v3.34.5) Version: 20210809 Online Version...
- Page 28 Log in...
- Page 43 Find EFEV smart fireplace...
- Page 44 Add EFEV smart fireplace...
- Page 45 Added EFEV smart fireplace...
- Page 46 Add EFEV smart fireplace...
-
Page 48: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning ALWAYS turn the fireplace OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.ming maintenance, or moving this fireplace. -
Page 49: Troubleshooting/ Faq
TROUBLESHOOTING/ FAQ Problem Note Possible Cause Solution Fire not turning on Fire not plugged in or Check plug is correctly fitted If all solutions have switched on at socket into socket and the socket is been tested and turned on. problem persists, a new control panel is Disconnect plug and inspect the... -
Page 50: Product Warranty
Heater cutting out If problem persists, the Build-up of hot air Ensure inlets and outlet are free installation will need from obstruction and there are assessed to ensure it sufficient clearances surrounding adheres to all required the unit. minimumclearances as stated in this manual. - Page 51 If your fire is to be buit on to an existing chimney breast, the chimney must be blocked off as the drafts can affect the appliance causing it to over heat. If the problem continues, keep the product unplugged from the power socket and contact your supplier.
- Page 52 Removal of the plug will invalidate your warranty. Product warranty only applies if purchased through an Evolution Fires authorized seller only. The warranty is only valid while the product remains with the original purchaser. If the Item is installed in another home and has a new ownership the warranty does not apply.
- Page 53 GET IN TOUCH www.evolutionfires.co.uk sales@evolutionfires.com Unit 2 Firefly Square, Plantation Road, Burscough, Lancashire, L40 8JT United Kingdom...
