- Page 2 How to Replace the Touch Panel Step 1 - Remove the glass screen IMPORTANT: UNPLUG THE FIRE FROM THE POWER SOURCE BEFORE STARTING THESE STEPS Remove glass - Remove the screws circled in red so the glass can be removed. The screws will be needed to reinstall the glass.
- Page 3 How to Remove the Plastic Tray Step 2 - Remove the plastic tray Remove the two screws circled in red to release the plastic tray. Photo after removing the plastic try.
- Page 4 How to Remove the Air Outlet Panel Step 3 1. Remove the screws circled in red so the air outlet panel can be loosened. The air outlet panel.
- Page 5 How to Remove the Touch Panel Step 4 The touch panel is located on the air outlet panel component Touch Panel Location Use a Phillips screwdriver to press down the red circle buckle (the button board buckle is axisymmetric, and all four buckles need to be pressed down) to remove the touch panel.
