- Page 1 ADVANCE SERIES ADVANCE SERIES 1300 ADVANCE SERIES 1500 ADVANCE SERIES 1800 ADVANCE SERIES 2000 HOW TO BUILD A MEDIA WALL FEATURING THE ADVANCE SERIES SCAN THE QR CODE...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION! TABLE OF CONTENT WARNING Important safety information! Parts and hardware When using electrical appliances basic precautions should always be followed to reduce the risk of fire, Specification and dimension electric shock and injury to persons, including thefollowing: Preparation READ ALL THE INSTRUCTIONS BEFORE USING THIS APPLIANCE Installation - minimum clearances... -
Page 3: Parts And Hardware
Do not cut the plug off the power cable, this also applies to fuse spares. If the plug is removed Evolution Fires will no longer honor the warranty. Dimensions The frame of the media wall must be hollow allowing air flow to reach the fire. If there is not enough airflow getting to the fire you will find your fire switches off when the heater is used. -
Page 4: Installation - Minimum Clearances
INSTALLATION - MINIMUM CLEARANCES INSTALLATION OVERVIEW Your appliance is a recessed and/or mantel installed appliance. Select a suitable location that is not Your appliance allows for three installation configurations. susceptible to moisture build-up. It must be located with enough distance away from flammable materials such as curtains, furniture and high traffic areas. -
Page 5: Operation
OPERATION UNPACKING Congratulations on your new electric fire. In order to unpack your product without Please read the entire owner’s manual, including all safety information, before plugging in causing any damage to yourself of the product, please take care and follow the or using this product. -
Page 6: Installation Choose Your Viewing Style
INSTALLATION CHOOSE YOUR VIEWING STYLE OPTIONAL SIDE PANELS Attach the relevant side panels or side trims to achieve your look. When unpacked the fire has only one pane of glass visible at the front. The two side sections are covered by blanking plates. If the fire is to be installed as a two or three sided appliance these plates need to be removed. -
Page 7: Product Information
Please read the instructions carefully BEFORE installation. The installation MUST be carried out by a qualified person. Supplier name Evolution Fires Connect the appliance to a single-phase AC supply of the voltage specified on the ratings plate. Model number EAS1300... -
Page 8: Operating The Fire
OPERATING THE FIRE Manual control: This appliance can be operated manually using the controls situated on the top right hand side of the fire screen. ON/OFF POWER SWITCH- This switch is used to turn the mains supply to the appliance on or off. When the switch is in the ON position an orange indicator light will show in the middle of the screen. - Page 9 Adjusting the desired temperatur : Standby button: Use this button to switch the fire on / off, and unlock the remote if remote is locked. While the fire is heating on, use rotate button to set the desired temperature. A confirmation beep will be heard from the fire. If the room is already warmer than the temperature set Heat button: then the heater will switch off until the thermostatic sensor detects a fall in temperature.
-
Page 10: Wi-Fi / Smart Control
WI-FI / SMART CONTROL Preparation In order to prepare please check that your mobile phone is connected to your Wi-Fi router. Plug your fire in to the wall. Switch the fire on at the wall socket. DO NOT use the STANDBY button to turn on, use the power switch. - Page 11 7. Adding your device 5. Connecting to your Wi-Fi Wait whilst the app adds the device. Please keep the phone close to the device whilst the device is syncing. Select your Wi-Fi network and input the password of your Wi-Fi network. If it fails to sync Repeat steps 4,5 and 6 6.
- Page 12 Maintenance: 1. To turn the fire on press the You MUST remove the plug from the socket outlet and allow the heater to cool completely before Switch button at the bottom of the screen cleaning or maintenance. 2. To set timers press the clock button at the bottom Cleaning: right of the screen.
-
Page 13: Cleaning And Maintenance
CLEANING AND MAINTENANCE Safety Features As this appliance contains a heating component there is an automatic thermal cut out safety Cleaning feature. This feature stops the product from overheating and from potentially causing a fire. If the appliance reaches a temperature above the guideline parameters the automatic thermal cut ALWAYS turn the fireplace OFF and unplug the power cord from the outlet before cleaning, out safety feature will activate and the heater will cut out. -
Page 14: Troubleshooting/ Faq
TROUBLESHOOTING/ FAQ Electrical and Moving Parts: The fan motors are lubricated at the factory and will not require lubrication. Electrical components are integrated in the fireplace and are not serviceable by the consumer. Storage: Problem Note Possible Cause Solution Store fireplace in a clean dry place when not in use. Fire not turning on Fire not plugged in or Check plug is correctly fitted... -
Page 15: Product Warranty
If your fire is to be buit on to an existing chimney breast, the chimney must be blocked off as the Heater cutting out Build-up of hot air Ensure inlets and outlet are free If problem persists, the drafts can affect the appliance causing it to over heat. from obstruction and there are installation will need assessed to ensure it... -
Page 16: Year Limited Warranty
Removal of the plug will invalidate your warranty. Product warranty only applies if purchased through an Evolution Fires authorized seller only. The warranty is only valid while the product remains with the original purchaser. If the Item is installed in another home and has a new ownership the warranty does not apply.
