- Page 1 DYU SMART ELECTRIC BIKE L1 INSTRUCTION Do not use this product without carefully reading this instruction manual and understanding the performance of electric bicycles Please keep the instruction manual properly...
- Page 2 INSTRUCTION 21 22 23 25 26 1.Throttle Handlebar 19.Wheel hub 2.Brake lever 20.Disc brake 3.Power button 21.Frame 4.Handle bar 22.Pedal 5.Sunvisor 23.Crank 6.Light Switch 24.Chain wheel 7.Dash board 25.Chain 8.Front light 26.Back fork 9.Hook 27.Kickstand 10.Front shell 28.Absorber 11.Rear shell 29.Decorative cover 12.Head tube(#Frame number) 30.Rear Reflector...
-
Page 3: List Of Accessories
list of accessories Wireless key*2 10mm Single open wrench*1 Pedal*2 Charger*1 Instruction Inner hexagon spanner*1 15mm Single open wrench*1 Manual*1 Battery assemble instruction 1. Use the key to open the seat 2. Connect the battery wires and close compartment. Put the battery inside the seat compartment the compartment, as shown in the diagram above... - Page 4 FUNCTIONS 1.After removing the package, install the front wheel and hold the brake handle several times. After the brake line is restored, check if there is any abnormality in the disc brake. Any abnormality, please adjust the gap of the disc brake. Install the pedals, open the seat and connect the power cord, then enjoy the riding.
- Page 5 Front light switch DC2.1 charging Power port Horn Button DASHBOARD FUNCTION DIAGRAM Battery status Headlamp Under-voltage reminder Speed display Trip Distance Speed, power reuse area Power mileage multiplexing area prompt Throttle handlebar Failure Cruise Controller Failure Brake reminder Motor Failure...
- Page 6 PRODUCT SPECIFICATION Model L1 (TDT008Z) Material Metal Folding Released size 1420*627*1004mm Package size 1380*260*1030mm SIZE INFO Center distance between 985mm front and rear wheels Pedal height off the ground 120mm Hub size 14 inches Colour White/Black Weight 36.4kg Max load...
- Page 7 PRODUCT SPECIFICATION Model L1 (TDT008Z) Battery Type Lithium-ion batteries Battery 12.5AH Chinese battery Rated voltage DC54.6V Charging input voltage AC 100~240V Charging time Motor type PARAMETERS Motor rated power Brushless DC motor Maximum output power 400W Motor rated speed 700W Motor Rated voltage...
-
Page 8: Battery And Charging
ATTENTION Battery and Charging Limits 0°-45° conditions for charging and -10°~ 45° discharge. Keep the battery dry, do not put the battery in acid, alkaline liquid, avoid rain, keep away from fires, keep away from heat sources and high temperature environments. It is prohibited connect the positive and negative poles of the battery;... -
Page 9: Maintenance
charging should be away from combustible, charging time should exceed 6 hours. Drive on the lawful side of the non-motorized lane, downhill and paved road surface no more than 15km/h. Drive on the lawful side when there is no non-motorized lane. When adjusting handlebars or saddle, pay attention not to breach the safety line mark of the riser pipe and saddle pipe. - Page 10 The functions of a specific model mentioned in this manual are only applicable to that model. The L1 is a road-going e-bike. It can be used on even and well-surfaced tracks or dedicated cycle paths that are designed for everyday cycle transport. It is not intended for off-road or ‘cyclocross’...
-
Page 11: Warranty
Warranty Your purchase of this e-bike includes a statutory warranty against non-conformity defects in material and in workmanship which begins from the date you physically receive the e-bike. Additionally, your purchase also includes a seller’s warranty starting on the same date as detailed below: •... - Page 12 DYU E-bike Owners Group Manufacturer: Shenzhen DYU Intelligent Mobility Technology Co., Ltd website：www.dyucycle.com...
