- Page 1 DYU SMART ELECTRIC BIKE Z1 INSTRUCTION Do not use this product without carefully reading this instruction manual and understanding the performance of electric bicycles Please keep the instruction manual properly...
-
Page 2: Parts And Components
Parts & Components Parts & Components Disc Brake Caliper Display Front Mudguard Brake Lever Frame Battery Case Handlebar (where seat tube battery is installed, Power Switch removable) Pedal Steering Stem Crank Stem Latch Chain Wheel Headlight Chain Head Tube Kickstand (where frame code is engraved) Front Fork Rear Mudguard... -
Page 3: Getting Started
10. Cruise control: When riding in the throttle mode, twist and hold the throttle for 5 to 8 seconds, and release, for cruise control. To disable, twist the throttle again, or brake. 11. Theft tracker: Please refer to DYU’s WeChat official account. (Optional, and only applicable to some products) 12. Removing/Installing the battery: A built-in battery cannot be removed. For replacement, please contact our official customer service. -
Page 4: Product Parameters
Product Parameters Model TDT013Z Frame Material Aluminum alloy 720*460*700 mm Foldable Size (or 28.35*18.11*27.56 inches) 1246*525*1055 mm Expanded size (or 49.06*20.67*41.54 inches) 760*370*750 mm Package Size Appearance Size (or 29.92*14.57*29.53 inches) 862 mm (or 33.94 inches) Wheelbase 100 mm (or 3.94 inches) Pedals’... -
Page 5: Product Features
Product Parameters Model TDT013Z Battery Type Lithium-ion Battery Capacity 7.5Ah / 10Ah Battery Rated Voltage DC36V Charging Voltage DC42V Charger Input Voltage AC220V Accessories Charging Time 4H / 5H Parameters Motor Type Brushless D.C.Motor Motor Rated Power 250W Motor Rated Speed 410r/min Motor Rated Voltage Controller Under-Voltage Value... -
Page 6: Circuit Diagram
Circuit Diagram DC2. 1 Charging Port Electrolock_36V Electrolock_36V Electrolock_36V Electrolock_36V Throttle 36V Battery Pack Phase Wire A Left Power Cut-off Brake Lever Motor Right Power Cut-off Brake Lever Phase Wire B Controller Phase Wire C Light Switch Electrolock_36V Electrolock_36V Booster Horn Switch Phase Wire Anti-theft... -
Page 7: Battery And Charging
ATTENTION Battery & Charging: Do not connect the positive to negative, or vice versa. Do not damage, disassemble, or short-circuit the ● battery. Avoid water, other liquid, or other foreign matter inside the battery to prevent short circuit. Instructions in this manual must be followed when charging the battery, otherwise the owner shall ●... -
Page 8: Maintenance
Maintenance 1. The front and rear wheels should be aligned to the center of the front fork and frame. 2. Park away from direct sunlight and rain. 3. Do not rinse the eBike. Wipe with a damp cloth to clean. 4. - Page 9 DYU E-bike Owners Group Manufacturer: Shenzhen DYU Intelligent Mobility Technology Co., Ltd website：www.dyucycle.com...
