OWNER'S MANUAL
Heat Pump Air-To-Air
Split Air Conditioner
INVERTER CONSOLE NG Series
For proper operation, please read and keep this manual carefully.
Designed by Cooper&Hunter International Corporation, FL Miami, USA
www.cooperandhunter.com
CH S09FVX2 NG
CH S12FVX2 NG
CH S18FVX2 NG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH-S09FVX2-NG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cooper & Hunter CH-S09FVX2-NG

  • Page 1 OWNER’S MANUAL Heat Pump Air-To-Air Split Air Conditioner INVERTER CONSOLE NG Series CH S09FVX2 NG CH S12FVX2 NG CH S18FVX2 NG For proper operation, please read and keep this manual carefully. Designed by Cooper&Hunter International Corporation, FL Miami, USA www.cooperandhunter.com...
  • Page 3: Explanation Of Symbols

    OWNER’S MANUAL EXPLANATION OF SYMBOLS This symbol indicates the possibility of death or WARNING serious injury. This symbol indicates the possibility of injury or CAUTION damage to property. Indicates important hazard-related information, used to indicate risk of property NOTICE damage. EXCEPTION CLAUSES Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons:...
  • Page 4 REFRIGERANT Before install Appliance the appliance, filled with read the flammable installation gas R32. manual first. This appliance is not intended for use by Before use the Before repair persons (including children) with reduced appliance, the appliance, read the physical, sensory or mental capabilities, or lack read the service owner’s of experience an d knowledge, unless they have...
  • Page 5: Installation Notes

    OWNER’S MANUAL SAFETY OPERATION OF FLAMMABLE REFRIGERANT Qualification requirement for Maintenance notes installation and maintenance man Check whether the maintenance area or the room area meet the requirement of the All the work men who are engaging in the nameplate. refrigeration system should bear the valid - It’s only allowed to be operated in the certification awarded by the authoritative...
  • Page 6: Safety Instructions For Transportation And Storage

    Filling the refrigerant Conditioner should properly Use the refrigerant filling appliances specia- grounded. Incorrect grounding may cause lized for R32. Make sure that different kinds electric shock. of refrigerant won’t contaminate with each Do not put through the power before other.
  • Page 7: Operation And Maintenance

    OWNER’S MANUAL SAFETY PRECAUTIONS Do not step on top panel of outdoor unit, or WARNING put heavy objects. It may cause damage or personal injury. When below phenomenon Operation occurs, please turn off air conditioner and and Maintenance disconnect power immediately, and then contact the dealer or qualified professionals This appliance can be used by children for service:...
  • Page 8: Installation Notice

    INSTALLATION NOTICE Tools for installation 1. Level meter 2. Screw driver 3. Impact drill 4. Drill head 5. Open-end wrench 6. Pipe cutter 7. Leakage detector 8. Universal meter 9. Inner hexagon spanner 10. Measuring tape 11. Pipe expander 12. Torque wrench 13.
  • Page 9: Installation Of Indoor Unit

    OWNER’S MANUAL INSTALLATION OF INDOOR UNIT Selection of installation location. 8. The unit is at least 1 metre away from any television or radio 9. Set (unit may cause interference with the Such a place where cool air can be picture or sound).
  • Page 10: Refrigerant Piping

    INSTALLATION OF INDOOR UNIT Refrigerant piping CAUTION 1. Drill a hole ( 55mm in diameter ) in the spot Min.allowable length indicated by the symbol in the illustration as below . The suggested shortest pipe length is 2.5m, 2. The location of the hole is different in order to avoid noise from the outdoor depending on which side of the pipe is taken unit and vibration.
  • Page 11: Drain Piping

    OWNER’S MANUAL INSTALLATION OF INDOOR UNIT Boring a wall hole and installing 5. Insulate the indoor drain pipe with 10mm or more of insulation material to prevent wall embedded pipe condensation. 6. Remove the air filters and pour some water For walls containing metal frame or metal board, into the drain pan to check the water flows be sure to use a wall embedded pipe and wall...
  • Page 12 INSTALLATION OF INDOOR UNIT Preparation 2)Upper casing Open the front panel, remove the 4 screws and dismount the front grille while pulling it forward. Follow the arrows to disengage the clasps on the front case to remove it. Follow the procedure below when removing 3)Side casings the slit portions.
  • Page 13 OWNER’S MANUAL INSTALLATION OF INDOOR UNIT The mounting plate should be installed on a 3. Once refrigerant piping and drain piping wall which can support the weight of the indoor connections are complete, fill in the gap of unit. the through hole with putty. A gap can lead 1.
  • Page 14 INSTALLATION OF INDOOR UNIT Connect the pipe of indoor unit Selection of copper and heat insulation materials 1. Aim the pipe joint at the corresponding bellmouth. When using commercial copper pipes and 2. Pretighten the union nut with hand. fittings, observe the following: 1.
  • Page 15 OWNER’S MANUAL INSTALLATION OF INDOOR UNIT Checking for gas leakage CAUTION 1. Check for leakage of gas after air purging 1. Insulate the joint of the pipes securely. 2. See the sections on air purges and gas leak Incomplete insulation may lead to water checks in the installation manual for the leakage.
  • Page 16 INSTALLATION OF INDOOR UNIT 4. Pull wires to make sure that they are securely CAUTION latches up, then retain wires with wire retainer. 1. Do not use tapped wires, stranded wires, extensioncords, or starburst connections, Sensor securing plate as they may cause overheating, electrical shock, or fire.
  • Page 17: Routine Check After Installation

    OWNER’S MANUAL ROUTINE CHECK AFTER INSTALLATION Check after installation Items to be checked Possible malfunction Situation Has it been fixed firmly? The unit may drop,shake or emit noise. Have you done the refrigerant It may cause insufficient refrigerating leakage test? capacity.
  • Page 18: Maintenance

    MAINTENANCE 4. Attach the front panel. NOTICE Insert the front panel into the grooves of the unit (3 places). Before inspection and maintenance of the Attach the string to the right, inner-side of unit. PLEASE set power switch to “OFF” to the front grille.
  • Page 19 OWNER’S MANUAL MAINTENANCE 2 Filters: 6. Wash the air filters with water or clean them with vacuum cleaner. If the dust does not come off easily, wash 1. Wipe them with dry soft cloth them with neutral detergent thinned with 2.
  • Page 20: Part Names And Their Functions

    PART NAMES AND THEIR FUNCTIONS WARNING Before opening the front panel, be sure to stop the operation and turn the breaker OFF. Do not touch the metal parts on the inside of the indoor unit, as it may result in injury. 1.
  • Page 21: Introduction For Icons On Display Screen

    OWNER’S MANUAL OPERATION AND INTRODUCTION OF REMOTE CONTROLLER BUTTONS ON REMOTE INTRODUCTION FOR CONTROLLER ICONS ON DISPLAY SCREEN Set fan speed Send signal X-FAN button Set temp. Temp. Indoor ambient temp. display type Outdoor ambient temp. Auto mode Cool mode Dry mode Fan mode Heat mode...
  • Page 22: Introduction For Buttons On Remote Controller

    INTRODUCTION FOR BUTTONS ON REMOTE CONTROLLER Button NOTICE This button is used for setting Fan Speed in This is a general use remote controller, the sequence that goes from AUTO, it could be used for the air conditioners , then back to Auto. with multifunction;...
  • Page 23 OWNER’S MANUAL This remote controller is universal . If any Sleep 3 – the sleep curve setting under Sleep command , ais sent out, the unit will mode by DIY; carry out the command as 1. Under Sleep 3 mode, press “Turbo” button indicates the guide louver swings as: for a long time, remote controller enters into user individuation sleep setting status, at...
  • Page 24 Button After press of this button, disappears and «ON «blinks. 00:00 is displayed for ON time Press this button, could select displaying the setting. Within 5 seconds, press « +» or «-» indoor setting temperature or indoor ambient button on to adjust the time value.Every press temperature.When the indoor unit firstly power of either button changes the time setting by on it will display the setting temperature, if the...
  • Page 25: Function Introduction For Combination Buttons

    OWNER’S MANUAL FUNCTION INTRODUCTION FOR COMBINATION BUTTONS Child lock function Press «-» and «+» buttons simultaneously to turn on or turn off child lock function. When child lock function is on, « » icon is displayed on remote controller.If you operate the remote controller, the «...
  • Page 26: Replacement Of Batteries In Remote Controller

    Replacement of batteries in remote controller 1. Press the back side of remote controller marked with « », as shown in the fig, and then push out the cover of battery box along the arrow direction. 2. Replace two 7# (AAA 1.5V) dry batteries, and make sure the position of «+»...
  • Page 27 OWNER’S MANUAL CONSTRUCTION OF THE OUTDOOR UNIT air inlet air outlet NOTICE Actual product may be different from above graphics, please refer to actual product.
  • Page 28: Installation Notice

    INSTALLATION NOTICE CAUTION mode. Then, fully close the valve at high pressure side (liquid valve). About 30–40 seconds later, fully close the valve at low pressure side (gas valve), immediately Space to the obstruction stop the unit and disconnect power. At least 50cm Please note that the time for refrigerant recovery should not exceed 1 minute.
  • Page 29: Selection Of Installation Location

    OWNER’S MANUAL INSTALLATION NOTICE SELECTION OF Tools for installation INSTALLATION LOCATION 1. Level meter 2. Screw driver Basic requirement 3. Impact drill Installing the unit in the following places 4. Drill head may cause malfunction. If it is unavoidable, 5. Open-end wrench please consuit the local dealer: 6.
  • Page 30: Safety Precaution

    INSTALLATION NOTICE Safety precaution Grounding requirement Must follow the electric safety regulations The air conditioner is the first class when installing the unit. electric appliance.It must be properly According to the local safety regulations, grounding with specialized grounding use qualified power supply circuit and air device by a professional.
  • Page 31: Installation Of Outdoor Unit

    OWNER’S MANUAL INSTALLATION OF OUTDOOR UNIT Step 1: Step 2: Fix the support of outdoor unit Install drain joint (select it according to the actual installation (only for some models) situation) 1. Connect the outdoor drain joint into the hole on the chassis, as shown in the picture 1.
  • Page 32 INSTALLATION OF OUTDOOR UNIT Step 4: Step 5: Connect indoor and outdoor pipes Connect outdoor electric wire 1. Remove the screw on the right handle of 1. Remove the wire clip; connect the power outdoor unit and then remove the handle. connection wire and signal control wire (only for cooling and heating unit) to the wiring terminal according to the color;...
  • Page 33 OWNER’S MANUAL INSTALLATION OF OUTDOOR UNIT Step 6: Neaten the pipes 1. The pipes should be placed along the wall, bent reasonably and hidden possibly. Min. semidiameter of bending the pipe is 10cm. 2. If the outdoor unit is higher than the wall hole, you must set a U-shaped curve in the pipe before pipe goes into the room, in order to prevent rain from getting into the room.
  • Page 34: Test And Operation

    TEST AND OPERATION Use vacuum pump Check after installation Check according to the following requirement after finishing installation. 1. Remove the valve caps on the liquid valve and gas valve and the nut of refrigerant Items to be checked Possible malfunction charging vent.
  • Page 35: Configuration Of Connection Pipe

    OWNER’S MANUAL CONFIGURATION OF CONNECTION PIPE 1. Standard length of connection pipe: 5 m, Additional refrigerant 7.5 m, 8 m. charging amount for R32 2. Min. length of connection pipe. For the unit with standard connection pipe of 5 m, there is no limitation for the min length of connection pipe.
  • Page 36: Pipe Expanding Method

    PIPE EXPANDING METHOD E: Expand the port NOTICE Expand the port with expander. Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: A: Cut the pipe Confirm the pipe length according to the distance of indoor unit and outdoor unit.
  • Page 37 OWNER’S MANUAL SPECIALIST’S MANUAL The following checks shall be applied to i.e. non-sparking, adequately sealed installations using flammable refrigerants: intrinsically safe. the charge size is in accordance with the Presence of fire extinguisher room size within which the refrigerant If any hot work is to be conducted on the containing parts are installed;...
  • Page 38 affected. This shall include damage to cables, containing chlorine shall be avoided as the excessive number of connections, terminals chlorine may react with the refrigerant and not made to original specification, damage to corrode the copper pipe-work. seals, incorrect fitting of glands, etc. Decommissioning Ensure that the apparatus is mounted Before carrying out this procedure, it is...
  • Page 39 OWNER’S MANUAL Labelling flammable refrigerant does not remain within Equipment shall be labelled stating that the lubricant. The evacuation process shall be it has been de-commissioned and emptied carried out prior to returning the compressor of refrigerant. The label shall be dated and to the suppliers.
  • Page 40: Operating Systems

    EWPE SMART WI-FI CONTROL APPLICATION Wi-Fi app and set up Operating systems Requirement for user’s smart phone: iOS system Support iOS7.0 and above version Android system Support Android 4.4 and above version Download and installation Scan the QR code or search Ewpe Smart in the application reset tools according to actual situation.
  • Page 41: Swing Settings

    OWNER’S MANUAL Swing Settings Click Up down swing or Left right swing to turn on or turn off swing function. Click the arrow at the right lower corner of icon to enter the set swing range. Preset Setting Select Timer to set preset times of your choice Other function settings Homepage menu...
  • Page 42: Specification

    SPECIFICATION Model CH-S09FVX2-NG CH-S12FVX2-NG CH-S18FVX2-NG cooling 3.52 Capacity heating 5.33 Power supply ~ 220–240V/50Hz/1Ph cooling 0.70 0.926 1.445 Rated capacity heating 0.73 0.960 1.545 500/430/410/370/ 600/520/480/440/ 750/670/600/520/ Air flow rate m /h 330/280/250 400/360/280 470/430/350 IDU (min/ mid/ db( )
  • Page 44 *Cooper&Hunter is constantly working on improvement by pouring their products, so what information given in this manual, may be changed- without prior notice to consumers. 2023/8...
