- Page 1 Air To Water Heat Pump CH-HP5.0UIMPRK...
- Page 2 Appliance filled with flammable gas R32. Caution, risk of fire Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
- Page 3 Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture. Should repair be necessary, contact your nearest authorized Service Centre. Any repairs carried out by unqualified personnel may be dangerous. The appliance shall be stored in a room without continuously operating ignition sources.
- Page 4 Annex CC (informative) Transportation, marking and storage for units that employ flammable refrigerants The following information is provided for units that employ flammable refrigerants. ● CC.1 Transport of equipment containing flammable refrigerants Attention is drawn to the fact that additional transportation regulations may exist with respect to equipment containing flammable gas.
-
Page 5: Table Of Contents
Content Operation Instructions Precautions........................1 Parts Name........................6 Function And Wired Controller..................7 Operation Instructions....................11 Maintenance........................15 Malfunction Analysis....................16 Specifications........................18 Installation Instructions Installation Notice......................19 Installation Drawing.......................24 Installation of The Unit....................25 Commissioning......................36 Servicing........................37 Maintenance Safety Precautions................39... - Page 6 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 7: Precautions
Precautions Information for users In order to use this product safely, please read this Instruction carefully and pay special attention to cautions before and during installation. If the unit is not used in winter, please keep 24hr power supply for the unit. If the power is cut off, the water system may freeze and the unit may fail when it is started again. - Page 8 Precautions WARNING Indicates a potentially hazardous situation which if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which if not avoided, may result in minor or moderate injury. It is also used to alert against unsafe practices. NOTICE Indicates situations that could only result in accidental equipment or property damage.
- Page 9 Precautions • Make certain that all electrical work is carried out by qualified personnel according to the local laws and regulations and this manual using a separate circuit. Insufficient capacity of the power supply circuit or improper electrical construction may lead to electric shocks or fire. •...
- Page 10 Precautions • Do not install the unit in the following places: - Where there is mist of mineral oil, oil spray or vapors. - Where corrosive gases (such as sulphurous acid gas) are produced. - Where there is machinery which emits electromagnetic waves. - Where flammable gases may leak, where carbon fiber or ignitable dust is suspended in the air or where volatile flammables such as paint thinner or gasoline are handled.
- Page 11 Precautions • Product installation should be fixed firmly. Take reinforcement measures, when necessary. NOTICE • About Fluoridated Gases - This air-conditioning unit contains fluoridated gases. For specific information on the type of gas and the amount, please refer to the relevant label on the unit itself.
-
Page 12: Parts Name
Parts Name Wired controller PUMP DEFROST ANTI-ICE Outdoor unit Note: Actual product may be different from above graphics, please refer to actual products. -
Page 13: Function And Wired Controller
Function And Wired Controller • Do not install or remove the wired controller by yourself. If necessary, please contact the after- sales serviceman. • Do not install the wired controller in the humid area or under direct sunlight. • Do not beat, toss, or frequently assemble/disassemble the wired controller. •... - Page 14 Function And Wired Controller 3. Installation of Wired Controller The simple installation step of wired controller is as shown on the figure, please notice below issues: • Pull out the 4 core twisted pair wire from the mounting hole and pass this line through the oblong hole located at the bottom of the wired controller.
-
Page 15: Liquid Crystal Display
Function And Wired Controller Liquid crystal display Overview PUMP DEFROST ANTI-ICE Display Explanation ANTI-ICE PUMP DEFROST Icon Description Powerful Mode Quiet Mode Eco Mode Child Lock Memory Cooling Heating... - Page 16 Function And Wired Controller Temperature Setting Timer Setting Dry Concrete function PUMP Air purge function DEFROST Defrost running ANTI ICE Anti-icing running Buttons Explanation Button Icon Description Mode Setting Up/Increase Function Setting On/Off Button Down/Decrease Timer Notice: After 20s for no operation, the LCD will go into low brightness state. Any operation will awake the LCD to high brightness state and then can be allowed to set functions or parameters.
-
Page 17: Operation Instructions
Operation Instructions On/Off Press the button to turn on or off the unit. Notice: In on-state, after 5s that has no operation, the actual temperature will display on. Mode Setting After press , unit is on-state, press to select Cooling or Heating mode. - Page 18 Operation Instructions Notice: Setting 00:00 and confirm that is regarded as quit countdown timer. After setting countdown timer successfully, press again is regarded as exit countdown timer and all relevant icons are extinguished. In countdown timer setting page ,press will also quit setting. Countdown timer will NOT memory when power off.
-
Page 19: Dry Concrete
Operation Instructions Dry Concrete The dry concrete function is used for drying out the screed of an underfloor heating system during the construction of the building. Operation and display: In Off-state, continually press button for 3s that will show up . -
Page 20: Status Display
Operation Instructions Notice: To avoid misunderstanding of operation, when child lock is active, any operation will NOT respond and the icon will flash to remind this function is under running. Notice: When sterilizing function is actived, the electrical heater will turn on dependently. After sterilizing is finish, the electrical heater will turn back to previous setting. -
Page 21: Maintenance
Maintenance • Turn off the unit and disconnect the power before cleaning the unit to avoid electric shock. • Do not wash the unit with water to avoid electric shock. • Do not use volatile liquid to clean the unit. Cleaning before use-season 1. -
Page 22: Malfunction Analysis
Malfunction Analysis Error Code When error happens to the unit, the error code will be shown on the wired controller. When multiple errors simultaneously happen, the error codes will circularly show up. When error occurs, please immediately shut down the unit and contact service center Error Code Description High discharge temp. - Page 23 Malfunction Analysis Error Code Description PFC protection ODU jumper cap error Communication error between ODU main control board and driver board Communication error between ODU main control board and fan motor driver board Outdoor ambient temperature sensor error Outdoor evaporator temperature sensor error Discharge temperature sensor error Compressor IPM temperature senseor error Liquid pipe temperature sensor error...
-
Page 24: Specifications
Specifications Model VWV-S18A3B(O) Heating capacity 5100 Cooling capacity 5000 220-240V～ 50Hz Power supply — 1400 Heating power input Cooling power input 1250 Rated input 2000 Rated current Climate Type — Isolation — Ⅰ Moisture Protection IPX4 — Refrigerant and charge volume R32/0.65kg —... -
Page 25: Installation Notice
Installation Notice Safety operation of flammable refrigerant Qualification requirement for installation and maintenance man ● All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant. - Page 26 Installation Notice Power supply cord and Inter connection cord 18K:H07RN-F 3G1.5 mm²; Inter connection cord:4G 0.75 mm² Welding ● If you should cut or weld the refrigerant system pipes in the process of maintaining, please follow the steps as below: a.
- Page 27 Installation Notice Safety precautions for installing and relocating the unit To ensure safety, please be mindful of the following precautions. ● When installing or relocating the unit, be sure to keep the refrigerant circuit free from air or substances other than the specified refrigerant. Any presence of air or other foreign substance in the refrigerant circuit will cause system pressure rise or compressor rupture, resulting in injury.
-
Page 28: Safety Precaution
Installation Notice 1. The place with strong heat sources, vapors, flammable or explosive gas, or volatile objects spread in the air. 2. The place with high-frequency devices (such as welding machine, medical equipment). 3. The place near coast area. 4. The place with oil or fumes in the air. 5. -
Page 29: Grounding Requirement
Installation Notice Please notice that the unit is filled with flammable gas R32. Inappropriate treatment of the unit involves the risk of severe damages of people and material. Details to this refrigerant are found in chapter “refrigerant”. Grounding requirement ● The air conditioner is the first class electric appliance. It must be properly grounding with specialized grounding device by a professional. -
Page 30: Installation Drawing
Installation Drawing Installation space requirements Mind the spacing guidelines: ≥500 ≥500 The outdoor unit is following ambient temperatures: Cooling Mode 15~52℃ Heating Mode -27~30℃ Mind the measurement guidelines: Maximum distance between outdoor unit and external backup heater kit Unit: mm Code Dimensions 323.5... -
Page 31: Installation Of The Unit
Installation of The Unit ● Check the strength and level of the installation ground so that the unit may not cause any vibrations or noise during its operation. 1.Mounting the outdoor unit To provide the installation structure INFOTMATION The recommended height of the upper protruding part of the bolts is 20 mm. -
Page 32: Piping Installation
Installation of The Unit Opening and closing the unit DANGER: RISK OF ELECTROCUTION DANGER: RISK OF BURNING/SCALDING Open the electrical box cover and to connect the power supply cords and field supply components. Piping installation WARNING 1. A new G1" and 0.7Mpa (7bar) safety unit protected from freezing and in accordance with local standards must be installed on the inlet of the water heater. - Page 33 Installation of The Unit ▪ Pipe specifications Water pipe Specification Outlet Water pipe G1" Inlet Water pipe G1" ▪ Water pressure The maximum water pressure is 0.7Mpa (7bar) . Provide adequate safe guards in the water circuit to ensure that the maximum pressure is not exceeded. Installation Diagram NOTICE •...
- Page 34 Installation of The Unit To check the water volume and flow rate Minimum water volume Check that the total water volume in the installation is higher than the minimum water volume, the internal water volume of the outdoor unit NOT included: If…...
- Page 35 Installation of The Unit Connecting water piping To connect the water piping NOTICE Do NOT use excessive force when connecting the field piping and make sure the piping is aligned properly. Deformation of the piping can cause malfunctioning of the unit. NOTICE When connecting the field piping, hold the nut on the inside of the unit in place using a spanner to provide extra leverage.
- Page 36 Installation of The Unit To fill the water circuit To fill the water circuit, use a field supply filling kit. Make sure you comply with the applicable legislation. NOTICE The unit contains a manual air purge valve. Make sure it is closed. Only open it when performing an air purge.
- Page 37 Installation of The Unit This process is accelerated by the presence of copper and high temperatures. The acidic uninhibited glycol attacks metal surfaces and forms galvanic corrosion cells that cause severe damage to the system. Therefore it is important that: ▪...
- Page 38 Installation of The Unit INFOTMATION ▪ Protection against bursting: the glycol will prevent the piping from bursting, but NOT the liquid inside the piping from freezing. ▪ Protection against freezing: the glycol will prevent the liquid inside the piping from freezing. NOTICE ▪...
-
Page 39: Finishing The Outdoor Unit Installation
Installation of The Unit To insulate the water piping The piping in the complete water circuit must be insulated to prevent reduction of the water heating capacity. Outdoor water piping insulation NOTICE Make sure the outside piping is insulated as instructed to protect against hazards. -
Page 40: Electrical Installation
Installation of The Unit 4.Electrical installation DANGER: RISK OF ELECTROCUTION WARNING • ALWAYS use cable for power supply cables. • Make sure to turn off the power before removing the cover to prevent any injury or electric shock risk. • Upstream of the appliance, the electrical installation must have an all-pole cut-out device (circuit-breaker, fuse) in accordance with the applicable local installation rules (30mA earth-leakage circuit-breaker). -
Page 41: Power Supply
Installation of The Unit To connect the main power supply 1. Open the electrical box cover. 2. Connect the wires to the appropriate terminals, and fix the cables with cable ties. Power Supply 3. Fix the cables with cable ties to the cable tie mountings. warning OTHER THERMAL... -
Page 42: Commissioning
Commissioning INFOTMATION • General commissioning checklist. The general commissioning checklist is complementary to the instructions in this chapter and can be used as a guideline and reporting template during the commissioning and hand-over to the user. • The software is equipped with protective functions, such as room anti-frost. The unit automatically runs these functions when necessary. -
Page 43: Hand-Over To The User
Commissioning NOTICE If the outdoor temperature is outside the range of operation, the unit may NOT operate or may not deliver the required capacity. Hand-over to the user Once the test run is finished and the unit operates properly, please make sure the following is clear for the user: ▪... - Page 44 Servicing Maintenance of Unit ▪Periodically check air inlet/outlet of unit for blockage. If blockage, clean it immediately. ▪Periodically check pipeline between main unit and water tank, waterway at user side, pipe joint and valve body for damage, blockage or water leakage of each joint. If there is, handle them immediately.
-
Page 45: Maintenance Safety Precautions
Maintenance Safety Precautions Information on servicing ● Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system. - Page 46 Maintenance Safety Precautions ● Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
- Page 47 Maintenance Safety Precautions Repairs to sealed components ● During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
- Page 48 Maintenance Safety Precautions Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. Leak detection methods The following leak detection methods are deemed acceptable for systems containing flammable refrigerants.
-
Page 49: Charging Procedures
Maintenance Safety Precautions Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system. - Page 50 Maintenance Safety Precautions • Recovery equipment and cylinders conform to the appropriate standards. d) Pump down refrigerant system, if possible. e) If a vacuum is not possible, make a manifold so that refrigerant can be removed. From various parts of the system. f) Make sure that cylinder is situated on the scales before recovery takes place.
- Page 51 Maintenance Safety Precautions The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant.
