Manuale Installazione - Service Manual

Ice Makers with paddles for Commercial Use

Mod. K23nano / K23 / K25 / K30 / K36 / K45 / K50 / K62 / K80 / K95 / K150

Mod. K23nano F / K23 F / K25 F / K30 F / K36 F / K45 F / K50 F / K62 F / K80 F / K95 F / K150 F

da/from vers. 7.0

(NOUGAT)

da/from vers. 12.0

Table of Contents

Need help?

Do you have a question about the K23nano and is the answer not in the manual?

Questions and answers

Summary of Contents for Icematic K23nano

Page 1 Mod. K23nano / K23 / K25 / K30 / K36 / K45 / K50 / K62 / K80 / K95 / K150 Mod. K23nano F / K23 F / K25 F / K30 F / K36 F / K45 F / K50 F / K62 F / K80 F / K95 F / K150 F da/from vers.
Page 2: Table Of Contents
SUMMARY 14�2b Language settings ��48 1 WARNINGS ��6 14�3 User Menu Interface ��49 2 FOREWORD ��8 14�4 Starting/Stopping the ice cycle ��50 2�1 Machine operation ��8 14�6 Bin probe adjustment ��51 2�2 Warranty ��9 14�7 Clock synchronisation ��51 3 INSTALLATION ��9 14�8 Starting ice production in kg ��52 3�1 Transportation ��9 14�9 Starting programmed ice production ��53...
Page 5 THE OPERATIONS HIGHLIGHTED WITH THIS SYMBOL ARE STRICTLY RESERVED TO THE AUTHORISED TECHNICAL DEPARTMENT. In particular, they are: Electrical connections, Water connections, Installation of the machine, Testing of the machine, Repairs on all com- ponents and parts of the machine, Disassembly of the machine and/or its components, Adjustment and calibration, Maintenance and cleaning of the machine related to parts and components (electrical, electronic, mechanical, refrigerators) This user manual is part of the ice maker and provides all the necessary information for proper installa-...
Page 6: Warnings ��6 14�2B Language Settings
1 WARNINGS table sockets or portable power supplies on the back of the appliance. • This appliance was designed to be used for household and similar applica- • The machine is designed for profes- tions, such as: sional use and therefore only qualified - the kitchen area intended for commer- persons may use it.
Page 7 • must be installed in places where it can • In the event of abnormal operation of be checked by qualified personnel. the appliance or the appearance of alarms, • it must not be installed outdoors or in disconnect the machine from the electric- dusty environments (Fig.
Page 8: 2�1 Machine Operation ��8 14�4 Starting/Stopping The Ice Cycle
serial number plate. The type of refriger- it operates for a long period of time without causing problems� If you need to contact the manufacturer or ant gas present in the refrigerating cir- a designated representative, always quote the model cuit of the device is shown in the identi- and serial number of our device (fig.10).
Page 9: 3�3 Positioning ��9 14�10 Washing Cycle - Sanitation
2.2 Warranty (Fig� 3)� If the devices are not levelled, their operation and For the general conditions of the warranty, please condensation discharge might be compromised� contact your local official distributor. In case of replacement of components, always ask for original Before commissioning the ice maker, spare parts�...
Page 10: Commissioning ��10 14�12 Info Service
tener on the water supply to prevent limescale from forming in the water circuit� Note: For a perfect water outflow from the de- - In order to avoid that the ice absorbs unpleasant vice, provide a minimum 3% slope of the pipe check- odours and flavours, never keep in the bin food, bot- ing that it is not subject to bottlenecks or siphoning�...
Page 11: 4�1 Bin Probe Adjustment
5.2 Operations to be performed by the en- with the power supply disconnected� • Check that there are no abnormal vibrations due abled installer to loosened screws� • In case of intervention due to water leaks, tight- ening of screws or other, always stop the machine Hereinafter we present a list of routine mainte- first.
Page 12: Malfunction
To guarantee good cleaning of the ice maker, it is inserting the bottle tube all the way into the appropri- recommended performing a cleaning cycle at least ate hole (fig. 14) and drain all the previously prepared 3-4 times a year depending on the hardness of the mixture, by pressing the bottle with your hands�...
Page 13: List Of Alarms ��13 16�9 Service Data
7 LIST OF ALARMS THE FOLLOWING OPERATIONS SHOULD BE PERFORMED EXCLUSIVELY BY QUALIFIED AND AUTHORISED PERSONNEL. IN CASE OF INCORRECT OPERATION, IT IS RECOMMENDED TO DISCONNECT THE MACHINE FROM THE ELECTRICAL AND HYDRAULIC SUPPLY NETWORK. The illuminated button has a combination of white and red colours, which indicate the operating or alarm status, which are summarised below: Signal / Alarm WHITE...
Page 14: 7�1 Troubleshooting ��14 16�10 Performance Data
7.1 Troubleshooting THE FOLLOWING OPERATIONS SHOULD BE PERFORMED EXCLUSIVELY BY QUALIFIED AND AUTHORISED PERSONNEL. IN CASE OF INCORRECT OPERATION, IT IS RECOMMENDED TO DISCONNECT THE MACHINE FROM THE ELECTRICAL AND HYDRAULIC SUPPLY NETWORK. Alarm Machine status Solution (AL01) Alarm: cold cycle Machine stops in standby;...
Page 15 Alarm Machine status Solution (AL10) High pressure The machine stops, the condenser Check cleanliness and ventilation of condenser, alarm fan remains on to lower the condenser check that the condenser fan is turning, check temperature, or the water valve remains position of condenser probe;...
Page 16: Technical Specifications
8 TECHNICAL SPECIFICATIONS Model 23 nano 8.1 Drawings and measurements pag� 16 71504167-0-000...
Page 17 Model 23 pag� 17 71504167-0-000...
Page 18 Model - 25 pag� 18 71504167-0-000...
Page 19 Model - 30 pag� 19 71504167-0-000...
Page 20 Model - 36 pag� 20 71504167-0-000...
Page 21 Model - 45 pag� 21 71504167-0-000...
Page 22 Model - 50 pag� 22 71504167-0-000...
Page 23: Model
Model - 62 pag� 23 71504167-0-000...
Page 24 Model - 80 pag� 24 71504167-0-000...
Page 25: Model
Model - 95 pag� 25 71504167-0-000...
Page 26 Model - 150 pag� 26 71504167-0-000...
Page 27: 8�2 Hydraulic Circuit
8.2 Hydraulic circuit (solo versioni condensate ad acqua) (only water condenser version ) (uniquement versions refroidies par eau) 8.3 Refrigerating circuit pag� 27 71504167-0-000...
Page 28: 8�4 Operation Data
8.4 Operation Data Dati medi a 32°C Temp. ambiente / 21°C Temp. acqua Average data at 32 ° C Ambient T°/ 21 ° C Water T° pag� 28 71504167-0-000...
Page 29 Dati medi a 32°C Temp. ambiente / 21°C Temp. acqua Average data at 32 ° C Ambient T°/ 21 ° C Water T° pag� 29 71504167-0-000...
Page 30: 8�5 Schema Elettrico
8.5 Schema elettrico pag� 30 71504167-0-000...
Page 31: 8�6 Schema Scheda Elettronica
8.6 Schema scheda elettronica pag� 31 71504167-0-000...
Page 32: Summary Of Alarm Signals
9 SUMMARY OF ALARM SIGNALS WHITE Alarm Machine status Problem solution Check cleanliness and ventilation of condenser, check for (AL01) Alarm: cold Machine stops in standby; a simple 1 x 0.5" 1 x 3.0" gas leaks, check operation of vane gearmotor, check defrost cycle too long press of the button restarts the machine.
Page 33: 9�1 Capacitive Key Light Signals
9.1 Capacitive key light signals. pag� 33 71504167-0-000...
Page 34: Capacitive Key Commands
10 CAPACITIVE KEY COMMANDS 10.1 Commands with repeated touches of the capacitive key Start State ACTION Action - Arrival State 3 TOUCHES STANDBY SETTING SET BIN PROBE (IF E05 NON = 0) 10 TOUCHES STANDBY DEFAULT PARAMETERS SET RELOAD 5 TOUCHES WAIT - START DELETE START WAIT TIME (TAA) WAIT-START...
Page 35: 10�2 Commands With Prolonged Touch Of The Capacitive Key �34 11
11 OPERATING LOGIC DIAGRAM 11.1 Ice production cycle diagram pag� 35 71504167-0-000...
Page 36: Model
11.2 Washing cycle diagram pag� 36 71504167-0-000...
Page 37: Ice Production Data
12 ICE PRODUCTION DATA (KG/24H) 12.1 Ice production versions with R290 gas (Propane) Mod. 23 nano R290 Temp. Aria Temp. Acqua Temp. Acqua Peso Cubetto/Weight Ice Air Temp. Water Temp. Water Temp. °C 32° 21° 15° 10° 32° 21° 15° 10°...
Page 38 Mod. 45 R290 Mod. 50 R290 Temp. Aria Temp. Aria Temp. Acqua Temp. Acqua Temp. Acqua Temp. Acqua Air Temp. Air Temp. Water Temp. Water Temp. Water Temp. Water Temp. °C 32° 21° 15° 10° 32° 21° 15° 10° °C 32°...
Page 39: 12�2 Ice Production Versions With R34A Gas
12.2 Ice production versions with R34a gas Mod. 23 nano R134a Temp. Aria Temp. Acqua Temp. Acqua Peso Cubetto/Weight Ice Air Temp. Water Temp. Water Temp. °C / kg 32° 21° 15° 10° 32° 21° 15° 10° °F / lbs 90°...
Page 40 Mod. 45 R134a Mod. 50 R134a Temp. Aria Temp. Aria Temp. Acqua Temp. Acqua Temp. Acqua Temp. Acqua Air Temp. Air Temp. Water Temp. Water Temp. Water Temp. Water Temp. °C 32° 21° 15° 10° 32° 21° 15° 10° °C 32°...
Page 41: Components List
13 COMPONENTS LIST 13.1 Water inlet valve list 2,5 l/m 3,7 l/m 3,7 l/m 2,5 l/m 2,5 l/m 1,2 l/m 2,0 l/m 1,2 l/m 0,8 l/m 1,2 l/m 0,6 l/m Model 23 nano A R134a 23 nano W R134a 23 nano A R290 23 nano W R290...
Page 42: 13�2 Summary Of Evaporators
13.2 Summary of Evaporators pag� 42 71504167-0-000...
Page 43: 13�3 Summary Of Programmed Board Codes
13.3 Summary of programmed board codes Codice - code IT - R134a GB - R134a CM25780234-0 SCHEDA ALLGAS K23NF A R134a 230/50 PROGRAMM� PC BOARD - K23NF A R134a 230/50 CM25780235-0 SCHEDA ALLGAS K23NF W R134a 230/50 PROGRAMM� PC BOARD - K23NF W R134a 230/50 CM25780236-0 SCHEDA ALLGAS K23F A R134a 230/50 PROGRAMM�...
Page 44 pag� 44 71504167-0-000...
Page 45: Model
from vers. 7.0 from vers. 12.0 (NOUGAT) CAUTION! ONLY ONE DEVICE (SMARTPHONE, TABLET, ETC.) CAN BE CONNECTED TO A MACHINE EQUIPPED WITH GATEWAY; ANY OTHER DEVICES THAT ARE CONNECTED WILL INDICATE THAT THE MACHINE IS NOT CONNECTED. TO CONNECT WITH ANOTHER DEVICE, IT IS NECESSARY TO DISCONNECT THE CURRENT ONE BY SIMPLY CLOSING THE APP.
Page 46: Machine Monitoring Via App
14 MACHINE MONITORING VIA APP An APP called AGS (All Gas System) has been created to allow the customer to access the daily settings required for the ice maker (ice bin level, production programming, cleaning cycle, etc.) and also to help Service view ma- chine operation (alarm, ice production level, performance, synoptic, etc.) during maintenance and adjust the pa- rameters if necessary.
Page 47: 14�2 Accessing The Machine Via App - Pairing
14.2 Accessing the machine via APP - Pair- By comparing the last 4 numbers of each machine with the last 4 numbers of the available MAC ADDRESS , identify Once the conditions indicated in paragraph 1�1 have been the machine to be selected for the connection and press met, one or more ice makers can be connected to the APP�...
Page 48: Language Settings
14.2b Language settings To change the language used in the APP, press the configuration key (X) and a list of options will appear; press (Y)� fig. 1.2d Once acquired, the machine will be automatically recognised and the status will go from ADD to PAIRED fig.
Page 49: 14�3 User Menu Interface
14.3 User Menu Interface Below is a description of the meaning of the keys and graphic symbols found in the end user menu: Key to change BlueTooth connection machine status with machine name Connection Active Machine Machine NOT connected name Machine connected in Alarm Key to go back to ma- chine list...
Page 50 14.4 Starting/Stopping the ice cycle If the machine is in standby, to start the ice production, press and hold (08) for 3 seconds 3" Once the ice production has started, the accessory function keys (09) will be disabled, as they cannot be used during an ice production cycle�...
Page 51: 14�7 Clock Synchronisation
14.6 Bin probe adjustment As the ambient temperature changes throughout the year, To increase the ice level in the bin, press (18), to reduce it it may be necessary to change the bin probe set, which press (17)� After adjusting the cube, press (20) to confirm determines the maximum level of ice contained in it�...
Page 52: 14�8 Starting Ice Production In
14.8 Starting ice production in kg If you want to produce a certain amount of ice in kg (ob- viously, if this amount exceeds the bin capacity, the ma- chine will stop when the bin is full), it is necessary to put the machine in standby first, if it is not already, by pressing (22).
Page 53: 14�9 Starting Programmed Ice Production
14.9 Starting programmed ice production If you want fresh and intact ice, close to the time you intend to use it, it is not enough to define the quantity, but the time must be defined too. In this way, it will be possible to make the machine produce ice close to the set time and not many hours before, thus preventing the ice from melting and being contaminated in the bin�...
Page 54 If you want to produce a certain amount of ice in kg (obviously, if this amount exceeds the bin capacity, the machine will stop when the bin is full), for a certain time over the next 3 days, it is necessary to put the machine in standby first, if it is not already, by pressing (22).
Page 55 If the available time does not allow for the set amount of ice to be produced, the following error message will ap- pear: In this case, there are two possibilities: 1) Press (A) and set the values again (time and kg) to al- low the cycle to start�...
Page 56 14.10 Washing cycle - Sanitation A message will appear, telling you to insert the sanitis- ing-descaling liquid in the evaporator bowl; once this has been done, press (39) to start the cycle or (40) to interrupt For further information, see also the it�...
Page 57: 14�11 Manual Ozone Sanitisation Cycle (Optional)
14.11 Manual Ozone Sanitisation Cycle The following message will appear, reminding you that to make the ozone action less dangerous and more effective, (Optional) the bin door must be closed� Once it has been closed, start the cycle by pressing (42)� For further information, see also the paragraph “Ozone Activation”...
Page 58: Info Service
14.12 Info Service Once the change has been made, confirm by pressing (48) To retrieve service and machine information, press (45)� After changing it, the machine will be indicated with its new The screen shown in fig. 1.12a will appear. name in all the screens or lists in which it appears�...
Page 59: View Alarms List
15 VIEW ALARMS LIST For each alarm, it is possible to access a screen describ- ing the alarm, its causes and the possible solutions; simply tap on the alarm in question (47)� CAUTION! MAINTENANCE OPERATIONS REPAIRS MUST ONLY BE CARRIED OUT BY QUALIFIED AND LICENSED SERVICE PERSONNEL! CAUTION! Remember that, for more accurate alarm dates and times, the internal clock must be periodically...
Page 60: Service Area Access
16 SERVICE AREA ACCESS CAUTION! The operations listed below can ONLY be carried out by specialist and trained personnel, and all the warnings in chapter 1 must be observed. It is possible to access the service area menu� By pressing the key (49)�...
Page 61: 16�2 Output Forcing Test
The values read by the board inputs will be initially dis- played; to access the board output values, press the item (53)� To force the individual output, press the "Launch" button relative to the load concerned (56)� The load will be acti- vated for a limited time of a few seconds (the key will turn orange)�...
Page 62: 16�4 Modify Parameters
The following screen is shown� To access the description of the parameter involved, press the side expansion arrow (62) or move the key (62b) until it turns green� Pressing one of the keys (60) will decide the sending method� To enter parameter modification, press the pencil symbol (63) which will allow viewing of the following screen�...
Page 63: 16�6 Start Manual Defrost
16.5 Modify parameter library 16.6 Start manual defrost If ice has accumulated on the evaporator, in order to de- CAUTION! The operations listed below can ONLY be frost it quickly, select a manual defrost, if the conditions carried out by specialist and trained personnel. Lack exist, by pressing the key (70)�...
Page 64: 16�7 View Of Temperature Probes Graphs
16.7 View of temperature probes graphs During defrosting, the following circular graph will appear, informing about the progress of the defrosting:to stop the defrost early, press the key (74), instead to reduce the win- To view the temperature trend of the probes installed in the dow, press the cross (73) , to return to the defrost screen machine, press the key (76)�...
Page 65: 16�8 Machine Synoptic View
16.8 Machine synoptic view 16.9 Service data It is possible to view the status of the machine on a ded- To enter the service data which can then be viewed in the icated synoptic� To access it, simply press the key (79)� service info (par�9�11), press the key (81)�...
Page 66: Performance Data
16.10 Performance data The machine keeps the performance data of the last 24H� To display them simply press the key (84)� pag� 66 71504167-0-000...
Page 67: First Installation Test
17 FIRST INSTALLATION TEST When the machine detects that a complete ice production cycle has been performed, it will prompt weighing of the ice produced and entering it as information in the window CAUTION! The operations listed below can ONLY be shown below�...
Page 68: Software Update
18 SOFTWARE UPDATE Here are the operations to perform to update the Software of the equipment� 1) Save the update file on a USB stick, in the root folder (not within a directory). The file name also features the software revision level, represented by the bold text: U005_palette_V �enc...
Page 69: 18�1 Download All Operating Data
18.1 Download ALL Operating Data To download ALL the operating data, use a EMPTY USB stick, and follow the same steps mentioned to update the SW� When the operation is complete, the USB stick will contain the following data: 18.4 CS_DataLoggers Directory 18.2 Info.csv file This directory may contain the following excel files: This excel file contains the main machine and service in-...
Page 70: Parameter Lists
19 PARAMETER LISTS 19.1 R290 AIR condensed version parameters Here is the parameters list for each machine model� Param. Label Descrizione U.M. Condenser probe type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Condenser probe calibration -10�0 10�0 °C Evaporator probe Type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Evaporator probe calibration -10�0...
Page 71 K23N A ZP K23 A ZP K25 A ZP K30 A ZP K36 A ZP K45 A ZP K50 A ZP K62 A ZP K80 A ZP K95 A ZP K150 A ZP 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3...
Page 72 Fan switch-off delay time after compressor With E27=1 if it cycles during the cold cycle, the defrost only starts after the 0�0 55�0 °C fan has stopped and Tc ° has been reached equal to E45 Cycles performed after presence of Bin probe error flag Condenser temperature for condenser cleaning pre-alarm (AL14) 30�0...
Page 73 1050 1050 1600 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 pag� 73 71504167-0-000...
Page 74: Model - 62 19�2 R290 Water Condensed Version Parameters
19.2 R290 WATER condensed version parameters Here is the parameters list for each machine model� Param. Label Descrizione U.M. Condenser probe type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Condenser probe calibration -10�0 10�0 °C Evaporator probe Type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Evaporator probe calibration -10�0...
Page 75 K23N W ZP K23 W ZP K25 W ZP K30 W ZP K36 W ZP K45 W ZP K50 W ZP K62 W ZP K80 W ZP K95 W ZP K150 W ZP 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3...
Page 76 Fan switch-off delay time after compressor With E27=1 if it cycles during the cold cycle, the defrost only starts after the 0�0 55�0 °C fan has stopped and Tc ° has been reached equal to E45 Cycles performed after presence of Bin probe error flag Condenser temperature for condenser cleaning pre-alarm (AL14) 30�0...
Page 77 1050 1050 1600 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 pag� 77 71504167-0-000...
Page 78: Model - 80 19�3 R134A Air Condensed Version Parameters
19.3 R134a AIR condensed version parameters Here is the parameters list for each machine model� Param. Label Descrizione U.M. Condenser probe type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Condenser probe calibration -10�0 10�0 °C Evaporator probe Type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Evaporator probe calibration -10�0...
Page 79 K23NF A K23F A K25F A K30F A K36F A K45F A K50F A K62F A K80F A K95F A K150F A 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 pag� 79 71504167-0-000...
Page 80 With E27=1 if it cycles during the cold cycle, the defrost only starts after the 0�0 55�0 °C fan has stopped and Tc ° has been reached equal to E45 Cycles performed after presence of Bin probe error flag Condenser temperature for condenser cleaning pre-alarm (AL14) 30�0 90�0 °C...
Page 81 1050 1050 1600 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 pag� 81 71504167-0-000...
Page 82: Model - 95 19�4 R134A Water Condensed Version Parameters
19.4 R134a WATER condensed version parameters Here is the parameters list for each machine model� Param. Label Descrizione U.M. Condenser probe type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Condenser probe calibration -10�0 10�0 °C Evaporator probe Type (0=No , 1=Ntc , 2=Ptc , 3=Pt1000) flag Evaporator probe calibration -10�0...
Page 83 K23NF W K23F W K25F W K30F W K36F W K45F W K50F W K62F W K80F W K95F W K150F W 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 1�3 pag� 83 71504167-0-000...
Page 84 With E27=1 if it cycles during the cold cycle, the defrost only starts after the 0�0 55�0 °C fan has stopped and Tc ° has been reached equal to E45 Cycles performed after presence of Bin probe error flag Condenser temperature for condenser cleaning pre-alarm (AL14) 30�0 90�0 °C...
Page 85 1050 1050 1600 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 0�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 6�5 pag� 85 71504167-0-000...
Page 86: Electronic Board Replacement
20 ELECTRONIC BOARD REPLACEMENT If the board must be replaced, in addition to inserting the updated software, it is necessary to select the correct param- eter list for the ice maker model (see parameter table and PAR-XX abbreviations)� There will be two modes depending on whether or not the display kit is present�...
