Two-stage gas furnaces
Table of Contents

Advertisement

Quick Links

These furnaces comply with requirements
embodied in the American National
Standard / National Standard of Canada
ANSI Z21.47·CSA-2.3 Gas Fired Central
Furnaces.
INSTALLER: Affix all manuals adjacent to the unit.
As a professional installer you have an obligation to know
the product better than the customer. This includes all safety
precautions and related items.
Prior to actual installation, thoroughly familiarize yourself with
this Instruction Manual. Pay special attention to all safety
warnings. Often during installation or repair it is possible to
place yourself in a position which is more hazardous than
when the unit is in operation.
Remember, it is your responsibility to install the product safely
and to know it well enough to be able to instruct a customer
in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific good safety
practices...follow them.
The precautions listed in this Installation Manual are intended
as supplemental to existing practices. However, if there is
a direct conflict between existing practices and the content
of this manual, the precautions listed here take precedence.
This furnace may be paired with a cooling unit that uses R-32
refrigerant. If the cooling unit paired with this furnace does
not use R-32, the R-32 function in the furnace control board
needs to be turned off. please see the electrical and the R-32
sections for more details.
Refrigerant systems other than R-410A or R32 may
require an additional mitigation control board. Refer to
the installation manual of the indoor evaporator coil to
determine installation requirements for that supplier's
refrigerant detection system.
IOG-2038B
12/2024
*R9T96 & *D9T96
Two-Stage Gas Furnaces
(Type FSP CATEGORY IV Direct
or Non Direct Vent Air Furnace)
(Type FSP CATÉGORIE IV Direct
ou four á air souffl‫ י‬non direct)
WARNING
19001 Kermier Rd. Waller, TX 77484
www.goodmanmfg.com • www.amana-hac.com
© 2024 Daikin Comfort Technologies Manufacturing, L.P.
is a registered trademark of Maytag Corporation or its related companies and is used under
NOTE: Please contact your distributor or our website for
*
the applicable Specification Sheet referred to in this manual.
Only personnel that have been trained to install, adjust,
service, maintenance or repair (hereinafter, "service")
the equipment specified in this manual should service the
equipment.
This equipment is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the equipment.
The manufacturer will not be responsible for any injury
or property damage arising from improper supervision,
service or service procedures. If you service this unit, you
assume responsibility for any injury or property damage
which may result. In addition, in jurisdictions that require
one or more licenses to service the equipment specified in
this manual, only licensed personnel should service the
equipment. Improper supervision, installation, adjustment,
servicing, maintenance or repair of the equipment specified
in this manual, or attempting to install, adjust, service
or repair the equipment specified in this manual without
proper supervision or training may result in product
damage, property damage, personal injury or death.
Do not bypass safety devices.
90% HEX
license. All rights reserved.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION.
WARNING
WARNING
DO NOT LIFT
PRODUCT USING
HEAT EXCHANGER

Advertisement
