Heating Input: 60,000-100,000 BTU/h
Standard Features
• Integrated communicating ComfortBridge™ technology
• Two-stage gas valve provides quiet,
economical heating
• Commissioning and diagnostics via on board
Bluetooth with the CoolCloud™ phone and
tablet application
• Efficient and quiet variable-speed ECM
circulator motor gently ramps up or down
according to heating or cooling demand
• SureStart® Silicon Nitride igniter
designed for long igniter life
• Self-diagnostic control board with constant memory
fault code history output to a triple 7-segment display
• Low constant fan speed circulates air
throughout the home
• Quiet, two-speed induced draft blower
• California Low NOx emissions-compliant
models available
• For installation in California's South Coast Air
Quality Management District (SCAQMD) only:
This furnace does not meet the SCAQMD
Rule 1111 14 ng/J NOx emission limit, and
thus is subject to a mitigation fee of up to
$450. This furnace is not eligible for the
SCAQMD Clean Air Furnace Rebate
Program: www.CleanAirFurnaceRebate.com.
• AHRI Certified; ETL Listed
SS-AMVC80/ACVC80
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
AMVC80(A) / ACVC80(A)
Cabinet Features
• Fully insulated, heavy-gauge steel cabinet
with durable baked-enamel finish
• Multi-position installation:
AMVC80: upflow, horizontal left or right
ACVC80: downflow, horizontal left or right
• Removable bottom for side- or
bottom-return applications
• Convenient left or right connection
for gas/electric service
• Cabinet air leakage ≤ 2%
• Coil and furnace fit flush
for most installations
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the
Lifetime Unit Replacement Limited Warranty (good for as long as you own your home) and 10-Year Parts
Limited Warranty, online registration must be completed within 60 days of installation. Online registration
is not required in California or Quebec.
www.amana-hac.com
Two-Stage, Variable-Speed
ECM Gas Furnace
80% AFUE
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 5
Airflow Data ........................................... 7
Accessories ............................................ 8
Wiring Diagram ................................... 10
6/19
Supersedes 4/19
Advertisement
Table of Contents
Related Manuals for Maytag Amana AMVC80
Summary of Contents for Maytag Amana AMVC80
-
Page 1: Table Of Contents
Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec. SS-AMVC80/ACVC80 www.amana-hac.com 6/19 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas. Supersedes 4/19... -
Page 2: Nomenclature
Nomenclature 7,8,9 13,14 Brand Engineering A - Amana® Brand Major /Minor Revisions * Not used for inventory control. Configuration M - Upflow/Horizontal N - Natural Gas C - Downflow/Horizontal X - Low NOx Motor Cabinet Width V - Variable Speed ECM / ComfortBridge™ A - 14"... -
Page 3: Product Specifications
Specifications AMVC80 AMVC80 AMVC80 AMVC80 AMVC80 AMVC80 AMVC80 0603B*A 0604B*A 0803B*A 0804C*A 0805C*A 0805D*A 1005C*A Heating Capacity High Fire Input (BTU/h)¹ 60,000 60,000 80,000 80,000 80,000 80,000 100,000 High Fire Output (BTU/h)¹ : Natural Gas 48,000 48,000 64,000 64,000 64,000 64,000 80,000 LP Gas... - Page 4 Specifications ACVC80 ACVC80 ACVC80 ACVC80 0603B*A 0803B*A 0805C*A 1005C*A Heating Capacity High Fire Input (BTU/h)¹ 60,000 80,000 80,000 100,000 High Fire Output (BTU/h)¹ Natural Gas 48,000 64,000 64,000 80,000 LP Gas 48,000 64,000 64,000 80,000 Low Fire Input (BTU/h)¹ 42,000 56,000 56,000 70,000...
-
Page 5: Dimensions
AMVC80 Dimensions Alternate Gas Inlet Alt. Flue Outlet — Horizontal Left 1¾” 1 ⁄ ” 19½” ➤ 33⅜” Alt. Gas Inlet 27⅞” 20” 23 ⁄ ” Alt. High Voltage High-Voltage Inlet 15” 13¼” Low-Voltage Inlet Alt. Low Voltage 23” ➤ 28”... - Page 6 ACVC80 Dimensions ” ⅝” High-Voltage Electrical Low-Voltage Electrical ⅜” Gas Inlet ⅜” ⅜” Dimensions Heights Model ACVC800603B** 17½” 28” 33⅜" 17½” 16” ACVC800803B** 17½” 28” 33⅜" 17½” 16” ACVC800805C** 21” 28” 33⅜" 21” 19½” ACVC801005C** 21” 28” 33⅜" 21” 19½” Minimum Clearances to Combustible Materials Vent ²...
-
Page 7: Airflow Data
Airflow Data MODEL/TEMP RISE RANGE ACVC800603BXA* ACVC800603BXA* ACVC800805CXA* ACVC801005CXA* AMVC800603B*A* AMVC800604B*A* (MID RISE) 25-55 (40) 30-60 (45) 25-55 (40) 20-50 (35) 15-45 (30) 20-50 (35) RISE RISE RISE RISE RISE RISE Recommended cfm for high heat / 1100 1325 1470 2090 1400 1275... -
Page 8: Accessories
Airflow Data (cont.) ACVC Continuous Fan Speeds Furnace Continuous Model Maximum CFM Fan Speed ACVC800603BXBX 1,400 350-1,400 ACVC800803BXBX 1,400 350-1,400 ACVC800805CXBX 2,200 550-2,200 ACVC801005CXBX 2,200 550-2,200 ACVC8 Minimum Filter Sizes Model # ACVC800603BX, ACVC80803BX ACVC800805CX ACVC801005CX Filter Size (in²) (2) 10 x 20 or (1) 16 x 25 (Top Return) (2) 14 x 20 or (1) 20 x 25 (Top Return) Note: Other size filters of equal or greater surface area may be used;... - Page 9 Temperature Rise Range Chart SS-AMVC80/ACVC80 www.amana-hac.com...
-
Page 10: Wiring Diagram
BLACK Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Our continuing commitment to quality products may mean a change in specifications without notice. © 2019 Goodman Company, L.P. • Houston, Texas • Printed in the USA.
