Oki C6150 Maintenance Manual
Second tray unit
Hide thumbs
Also See for C6150:
- User manual (286 pages) ,
- Reference manual (104 pages) ,
- Guia do usuário (312 pages)
Advertisement
Quick Links
No.01
C6150/C6050/C5950/C5850/C5750/C5650
C6100/C5900/C5800/C5700/C5600/C5500
BOM
Use for
Rev
Date
DCO No.
2
2008-04-01
SAB-0090
Approval
Yujiro Iida
.....................................................................................................
Check
.....................................................................................................
Date
2006-05-10
C5550MFP
Second Tray Unit
Maintenance Manual
[Rev. 2]
Contents
Add product name
Design
Takemasa Ishikuro
Oki Data CONFIDENTIAL
Certification Body
Design
Koji Aida
Name
C6150/C6050/C5950/C5850/C5750/C5650
C6100/C5900/C5800/C5700/C5600/C5500
C5550MFP
Second Tray Unit
Maintenance Manual
Drawing No.
43347601TH
Approval
Koji Aida
1
8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Oki C6150
Summary of Contents for Oki C6150
- Page 1 Oki Data CONFIDENTIAL No.01 C6150/C6050/C5950/C5850/C5750/C5650 C6100/C5900/C5800/C5700/C5600/C5500 C5550MFP Second Tray Unit Maintenance Manual [Rev. 2] Use for Certification Body Date DCO No. Contents Design Approval 2008-04-01 SAB-0090 Add product name Koji Aida Koji Aida Approval Design Name Yujiro Iida Takemasa Ishikuro .....................
- Page 2 Oki Data CONFIDENTIAL Document Revision History Corrected items Person in Rev.No. Date charge Page Description of change 2006-05-10 ISSUE MD12 T. Ishikuro 2008-04-01 Add product name CSFD11 K.Aida 43347601TH Rev.2...
- Page 3 • In preparing the document, efforts have been made to ensure that the information in it is accurate. However, errors may be crept into the document. Oki Data assumes no responsibility for any damage resulting from, or claimed to be the results of, those repairs, adjustments or modifica- tions to the printers which are made by users using the manual.
-
Page 4: Parts Replacement
Oki Data CONFIDENTIAL PARTS REPLACEMENT This section describes the procedures for removing and reinstalling of assemblies and units in the field. The procedures provided here are for removal, and for reinstallation, perform procedures basically in reverse order from removing. Precautions for Replacing Parts (1) Before disassembling or reassembling second tray unit, turn off the printers in which they are installed and, from the printers, remove them. - Page 5 Oki Data CONFIDENTIAL Parts Replacement (1) Unscrew the six screws 1 to remove the plate-top 2. (2) Remove the cover-side R 3. (3) Remove the connectors (at five places), then uninstall the PCB-V7Y-2 4. (4) Remove the cover - 2nd tray 5.
- Page 6 Oki Data CONFIDENTIAL Frame Assy- Hopping (1) Remove the PCB (see section 1.1). (2) Remove the three screws 1 to uninstall the hopping assy 2. (3) Unscrew the two screws 3 to remove the cover assy - front 4. (4) Unscrew the four screws 5 to remove the motor 6.
- Page 7 Oki Data CONFIDENTIAL Cleaning the Pick-up Roller and the Pad Clean the feed roller and the pad when [392: Paper Jam] appears frequently. (1) Remove the paper cassette. (2) Clean the two feed rollers with tightly wrung wet cloth or an LED lens cleaner.
-
Page 8: Principle Of Operation
Oki Data CONFIDENTIAL Principle of Operation Clutch Transfer roller Planet gear 2 Paper Hopping gear Planet gear 1 Sub roller Hopping roller (with one-way clutch) Feed roller (1) Hopping Drive a hopping roller with a pulse motor revolving to ‘a’ direction and a sub roller with the movement of the planet gear 1.
